Qichi 8TS1600 Overdrive (11.58) 8-Speed Manual Transmission
EXW
Export quote
Qichi 6-speed series transmission
Main model photos
5 photos
Models
On sale
Qichi 8TS1600 Overdrive (6.38) 8-Speed Manual Transmission
EXW
Export quote
Qichi 8TS1600 8-Speed Manual Transmission
EXW
Export quote
Qichi 8TS1300 8-Speed Manual Transmission
EXW
Export quote
Qichi 4S-150GP Overdrive 2 8-Speed Manual Transmission
EXW
Export quote
Series Specs
Transmission Parameters
Transmission Brand: Qichi
Transmission series: 8-speed series
Features: Truck-specific, 8TS1600 is a fully synchronized 8-speed combined mechanical transmission. / Truck-specific, 8TS1300 is a fully synchronized 8-speed combined mechanical transmission. / Full-synchronizer 8-speed compound manual transmission, consisting of a three-shaft countershaft main transmission and a planetary gear auxiliary transmission, with eight forward gears and one reverse gear
Matching Range: Suitable for various heavy dump trucks, truck cranes, etc.
Max input torque: 1600 / 1300N·m
1st gear ratio: 11.58 / 6.38 / 13.17 / 10.76 / 10.49 / 9.37 / 11.67 / 13.15
synchronizer: Yes
2nd gear ratio: 6.86 / 4.653 / 9.68 / 8.31 / 6.71 / 8.32 / 9.37
3rd gear ratio: 4.58 / 3.429 / 6.71 / 5.95 / 4.4 / 5.96
4th gear ratio: 3.83 / 2.824 / 4.58 / 4.4 / 3.33 / 3.3
5th gear ratio: 2.53 / 1.859 / 3.11 / 2.65 / 2.38 / 2.13 / 2.99
6th gear ratio: 1.5 / 1.357 / 2.11 / 1.89 / 1.53 / 2.13
7th gear ratio: 1 / 1.46 / 1.35 / 1.52
8th gear ratio: 0.84 / 0.82 / 1 / 0.75
Reverse Gear 1 Ratio: 9.37 / 9.25 / 11.73 / 16.91 / 15
Transmission weight: 310kg
Transmission oil capacity: 13L
Odometer drive ratio: 1.545 / 1.545/2.0 (secondary drive unit can be added per customer request)
Control type: Dual H control / "Double H" operation
Number of gears: 8Gear
shift type: Manual
Transmission Model: 8TS1600 / 8TS1300 / 4S-150GP / S8-110 / S8-120 / S8-135
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears:
FAQ
What kind of truck is Qichi Qichi 6-speed series transmission?
Qichi Qichi 6-speed series is an export-oriented transmission lineup with about 20 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is transmission typically used for?
For transmission, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Qichi 6-speed series transmission include?
Qichi 6-speed series transmission currently lists about 20 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Qichi 6-speed series transmission?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
