GAC HINO 700 Series 350 hp 6X4(10 wheels) 4m³ Concrete Mixer Truck Chassis
EXW
Export quote
GAC Leader GAC HINO700 Heavy Truck concrete mixer
Main model photos
355 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| GAC HINO 700 Series 350 hp 6X4(10 wheels) 4m³ Concrete Mixer Truck Chassis | 6x4 / 350hp / China V | ||
| GAC HINO 700 Series 350 hp 6X4(10 wheels) 4.7m³ Concrete Mixer Truck Chassis | 6x4 / 350hp / China V | ||
| GAC HINO 700 Series 325 hp 8X4(12 wheels) 7.3m³ Concrete Mixer Truck Chassis | 6x4 / 325hp / China V | ||
| GAC HINO 700 Series 350 hp 8X4(12 wheels) 7m³ Concrete Mixer Truck Chassis | 8x4 / 350hp / China V | ||
| GAC HINO 700 Series 325 hp 6X4(10 wheels) 6 m³ Concrete Mixer Truck Chassis | 6x4 / 325hp / China V | From $60,597 |
GAC HINO 700 Series 350 hp 6X4(10 wheels) 4.7m³ Concrete Mixer Truck Chassis
EXW
Export quote
GAC HINO 700 Series 325 hp 8X4(12 wheels) 7.3m³ Concrete Mixer Truck Chassis
EXW
Export quote
GAC HINO 700 Series 350 hp 8X4(12 wheels) 7m³ Concrete Mixer Truck Chassis
EXW
Export quote
GAC HINO 700 Series 325 hp 6X4(10 wheels) 6 m³ Concrete Mixer Truck Chassis
EXW
From $60,597
Export quote
Series Specs
Basic Info
Cab dimensions: 8.69×2.495×3.115 / 9.42×2.5×3.97 / 10.15×2.5×3.95 / 10.75×2.5×4 / 7.51×2.49×3.115 / 10.9×2.5×3.995 / 9×2.5×3.86 / 10.9 / 8.38×2.5×3.9 / 8.38×2.5×3.74 / 8.94×2.5×3.9m
Drive type: 6X4 / 8X4
Truck Type: concrete mixer truck
Front/rear track width: Front track: 2060mm; Rear track: 1855/1855mm / Front track: 2075/2075mm; Rear track: 1855/1855mm / Front track: 2060/2060mm; Rear track: 1855/1855mm / Front track: 2075mm; Rear track: 1855/1855 / Front track: 2060/2060 Rear track: 1855/1855 / Front track: 2060, Rear track: 1855/1855mm / Front track: 2060/2060, Rear track: 1855/1855 / Front track: 2060; Rear track: 1855/1855
Vehicle origin: Guangzhou / Shanghai / Guangdong / Guangzhou, Guangdong
Wheelbase: 4020+1410 / 3640+1410 / 1850+3400+1410 / 3350+1410 / 3.995 / 3300+1410mm
Curb Weight: 9.8 / 14.3 / 14.73 / 15.59 / 8.18 / 16.37 / 14.12 / 13.7 / 12.9ton
Rated payload: 10.57 / 16.14 / 15.28 / 14.63 / 10.75 / 11.97 / 11.17ton
Max. speed: 80 / 90km/h
Front/rear suspension: 1.46/1.8 / 1.46/1.59 / 1.46/2.03 / 1.46/2.63 / 1.46/1.29 / 1.41/1.31 / 1.41/2.54 / 1.41/2.83 / 1.41/2.48 / 1.41/2.26 / 1.41/1.21m
Body Parameters
Water tank capacity: 500L
Mixing drum capacity: 4 / 4.7 / 7.3 / 7 / 6m³
Slump: 50mm
Drum rotation speed: 0-17r/min
Feed rate: 3 / ≥3 / 2.7m³/min
Discharge speed: 2 / ≥2 / 0.65m³/min
Discharge residue rate:
Filling Rate: 64%
water supply method: Air pressure water supply
hydraulic system: Closed hydraulic circuit / Full hydraulic closed-loop system
Vehicle certification code: YC5310GJBFY2PU / HDJ5250GJBGH / YC5310GJFY2PU / YC5250GJBFS2PM4 / YC5250GJBFS2PK4 / YC1250FS2PM4 / YC1250FS3PK
Body Brand: GAC HINO
Others: 280L iron fuel tank, cab four-point full floating, electro-hydraulic tiltable cab / Side and rear guards: material Q345A, bolted connection; rear guard section 140mm×70mm, ground clearance 457mm. / comprehensive fuel consumption 30.1L/100km / dry single-plate Φ430mm / Cab four-point suspension, electronically controlled hydraulic cab tilting system / Transmission also available: DC12J150T.
Engine parameters
Engine Model: Shanghai HinoP11C-WC / Shanghai HinoP11C-WB / Shanghai Hino P11C-UJ / HINO P11C-UJ / Shanghai Hino P11C-VA / Shanghai Hino P11C-VK
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 10.52L
Emission standard: China V / China III / Euro III / China IV
Max output power: 259 / 240kW
Max hp: 350 / 325Horsepower
Rated speed: 1900 / 2100rpm
Engine Type: SCR / Denso electronic common rail, turbocharged intercooled / Inline
Chassis Specs
Chassis Series: GAC HINO700 Series / GAC HINO700
Chassis Model: YC2250FS2PN5 / YC2250FS2PM5 / YC2310FY2PU5 / YC2311FY2PU5 / YC2250FS2PL5 / YC1310GJBFY2PU / YC1250FS2PM / YC1250FS2PM4 / YC1250FS2PK4 / YC1250FS3PK
Front axle description: 6500+6500 / 8T
rear axle description: 18000+18000 / Tandem axle / 13T grade dual rear axle
Axle ratio: 4.875 / 4.625 / 5.285
Leaf spring count: 11/13 / 11/13,10/13 / 3/3/4 / 11/11/13 / 3/4 / 10/13,11/13,10/14,11/14
Transmission Parameters
Number of gears: 9 / 12Gear
Transmission Model: Fast GearRT-11509C / Fast GearRTD11509C / Fast Gear12JSD160TA / Fast Gear RTO-11509C / Datong DC12J150T / Dachi DC12J150T
FAQ
What kind of truck is GAC Leader GAC HINO700 Heavy Truck concrete mixer truck?
GAC Leader GAC HINO700 Heavy Truck is an export-oriented concrete mixer truck lineup with about 15 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for GAC Leader GAC HINO700 Heavy Truck concrete mixer?
GAC Leader GAC HINO700 Heavy Truck concrete mixer export reference is about From $60,597. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does GAC Leader GAC HINO700 Heavy Truck concrete mixer cover?
GAC Leader GAC HINO700 Heavy Truck concrete mixer mainly covers: Drive: 6x4 / 8x4; Horsepower: 325 hp / 350 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in GAC Leader GAC HINO700 Heavy Truck concrete mixer?
For GAC Leader GAC HINO700 Heavy Truck concrete mixer: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does GAC Leader GAC HINO700 Heavy Truck concrete mixer include?
GAC Leader GAC HINO700 Heavy Truck concrete mixer currently lists about 15 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for GAC Leader GAC HINO700 Heavy Truck concrete mixer?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
