Sinotruk V2-X 4.3L Diesel 200hp 4X2(6 wheels) Fast Gear 8-Speed 3.94m Short Cab Dump Truck
EXW
Export quote
Sinotruk V2-X Medium Truck Dump Trucks
Main model photos
14 photos
Models
On sale
Sinotruk V2-X 3L Diesel 170 hp 4X2(6 wheels) Fast Gear 8-Speed 3.94m Semi-row Dump Truck
EXW
Export quote
Sinotruk V2-X 3L Diesel 170 hp 4X2(6 wheels) Fast Gear 8-Speed 3.94m Semi-row Dump Truck
EXW
Export quote
Sinotruk V2-X 3L Diesel 170 hp 4X2(6 wheels) Fast Gear 8-Speed 3.94m Semi-row Dump Truck
EXW
Export quote
Sinotruk V2-X 3L Diesel 170hp 4X2(6 wheels) Fast Gear 10-Speed 3.8m Short-Cab Dump Truck
EXW
Export quote
Series Specs
Basic Info
Model code (announced): CDW3122A1R6 / CDW3113A1R6 / CDW3184K35EFA / CDW3181A2Q6 / CDW3121A1R6
Drive type: 4X2
Wheelbase: 3350mm
Engine Model: YuchaiYCS04200-66 / WeichaiWP3NQ170E62 / YCS04200-66 / WP3NQ170E62
Transmission Model: Fast Gear 8-speed / 10-speed MT / 8-speed
Rear Axle Ratio: 6.5
Cab length: 6.135 / 5.995m
Cab width: 2.36 / 2.26m
Cab height: 2.7 / 2.755 / 2.78 / 2.72 / 2.64m
Front track width: 1790 / 1810 / 1740mm
rear track: 1725 / 1750 / 1640 / 1600mm
Curb Weight: 6.805 / 5.61 / 5.8 / 7.81 / 6.1ton
Rated payload: 4.995 / 12.005 / 9.995 / 5.7ton
GVWR: 11.995 / 10.8 / 18ton
Origin: Chengdu, Sichuan
tonnage class: Light Truck / Heavy truck / Medium-duty truck
Approach angle: 17°
departure angle: 17 / 15°
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai / Weichai
Number of cylinders: 4cylinder
Displacement: 4.295 / 2.97L
Max output power: 147 / 125kW
Max hp: 200 / 170Horsepower
Max torque: 520N·m
Rated speed: 2800rpm
Engine Type: Common Rail+DOC+DPF+SCR
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8 / 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type / Rear dump
Cargo box length: 3.94 / 3.8m
Cargo box width: 2.2 / 2.1m
Cargo box height: 0.8m
Cab parameters
Cab: 757 cab / V26X / V26X Cab / V26X New Cab
seating capacity: 3Personnel
Chassis Specs
Front axle description: 145 front axle / 1090 front axle / 3T drum front axle
Front axle allowable load: 4800 / 4300 / 6500kg
rear axle description: 153 rear axle / 153 Single Shortened Rear Axle / 153 secondary shortened rear axle / 9T drum single rear axle
FAQ
What kind of truck is Sinotruk Sinotruk V2-X Medium Truck Dump Trucks?
Sinotruk Sinotruk V2-X Medium Truck is an export-oriented Dump Trucks lineup with about 5 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Sinotruk V2-X Medium Truck Dump Trucks cover?
Sinotruk V2-X Medium Truck Dump Trucks mainly covers: Drive: 4x2; Horsepower: 170 hp / 200 hp; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk V2-X Medium Truck Dump Trucks?
For Sinotruk V2-X Medium Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk V2-X Medium Truck Dump Trucks include?
Sinotruk V2-X Medium Truck Dump Trucks currently lists about 5 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk V2-X Medium Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
