Foton Times Xiaoyun 3 115hp 4X2(6 wheels) 3.67m Dump Truck
EXW
From $11,861
Export quote
Foton Times Xiaoyun Light Truck Dump Trucks
Main model photos
54 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Times Xiaoyun 3 115hp 4X2(6 wheels) 3.67m Dump Truck | 4x2 / 115hp / China VI | From $11,861 | |
| Foton Times Xiaoyun 115hp 4X2(6 wheels) 3.67m Dump Truck | 4x2 / 115hp / China VI | ||
| Foton Times Xiaoyun 3 115 hp 4X2(6 wheels) 3.25m Dump Truck | 4x2 / 115hp / China VI | From $12,972 | |
| Foton Times Xiaoyun 3 115 hp 4X2(6 wheels) 3.25m Dump Truck | 4x2 / 115hp / China VI | From $12,847 | |
| Foton Times Xiaoyun 3 115hp 4X2(6 wheels) 3.67m Dump Truck | 4x2 / 115hp / China VI | From $12,708 |
Foton Times Xiaoyun 115hp 4X2(6 wheels) 3.67m Dump Truck
EXW
Export quote
Foton Times Xiaoyun 3 115 hp 4X2(6 wheels) 3.25m Dump Truck
EXW
From $12,972
Export quote
Foton Times Xiaoyun 3 115 hp 4X2(6 wheels) 3.25m Dump Truck
EXW
From $12,847
Export quote
Foton Times Xiaoyun 3 115hp 4X2(6 wheels) 3.67m Dump Truck
EXW
From $12,708
Export quote
Series Specs
Basic Info
Model code (announced): BJ3045D9JBA-02 / BJ3045D9PBA-02 / BJ3045D9JB5-52 / BJ2046Y7JBA-FA / BJ3046D9PBA-FD / BJ3046D9JBA-FD / BJ3046D8ABA-FD / BJ3042D9PB3-FA
Drive type: 4X2
Wheelbase: 2850 / 2600mm
Engine Model: QuanchaiQ23-115E60 / QuanchaiQ23-115C60 / Quanchai4A2-82C50 / Quanchai4A2-88C50
Transmission Model: WLYWLY540CHF / WLYWLY7TS40 / WLYWLY5T26
Rear Axle Ratio: 4.33 / 3.909 / 4.875
Cab length: 5.47 / 5.49 / 5.08m
Cab width: 1.94 / 1.735 / 1.73 / 1695 / 1780m
Cab height: 2.21 / 2.185 / 2.22m
Front track width: 1495 / 1345 / 1415 / 1475mm
rear track: 1435 / 1292mm
Curb Weight: 2.72 / 2.5 / 2ton
Rated payload: 1.645 / 1.495 / 1.995ton
GVWR: 4.495 / 4.125ton
Origin: Shandong Zhucheng
tonnage class: Light Truck
Approach angle: 20 / 16 / 23°
departure angle: 16 / 18 / 17°
Remarks: Power steering, clutch booster / Optional air conditioning
Energy Type: Diesel
Engine parameters
Engine Brand: Quanchai
Number of cylinders: 4cylinder
Displacement: 2.3 / 2.27L
Emission standard: China VI / China V
Max output power: 85 / 60 / 65kW
Max hp: 115 / 82 / 88Horsepower
Max torque: 320 / 220 / 240N·m
Max torque speed: 2000rpm
Rated speed: 3000 / 3200rpm
Engine Type: Inline 4-cylinder, water-cooled, 4-stroke, turbocharged with intercooler, high-pressure common rail / Longitudinal mounting
Transmission Parameters
Transmission Brand: WLY
shift method: Manual
Forward gears: 5 / 7Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Dump type / Rear-dump body
Cargo box length: 3.67 / 3.25 / 3.3 / 2.71 / 2.93m
Cargo box width: 1.81 / 1.61 / 1.6m
Cargo box height: 0.4 / 0.36m
Cab parameters
Cab: Single Row / Sleeper cab / Double cab / Xiaoyun 7
Cab tilting: Electric
FAQ
What kind of truck is Foton Foton Times Xiaoyun Light Truck Dump Trucks?
Foton Foton Times Xiaoyun Light Truck is an export-oriented Dump Trucks lineup with about 12 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Foton Times Xiaoyun Light Truck Dump Trucks?
Foton Times Xiaoyun Light Truck Dump Trucks export reference is about $9,444 – $12,972. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Foton Times Xiaoyun Light Truck Dump Trucks cover?
Foton Times Xiaoyun Light Truck Dump Trucks mainly covers: Drive: 4x2; Horsepower: 115 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton Times Xiaoyun Light Truck Dump Trucks?
For Foton Times Xiaoyun Light Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Foton Times Xiaoyun Light Truck Dump Trucks include?
Foton Times Xiaoyun Light Truck Dump Trucks currently lists about 12 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton Times Xiaoyun Light Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
