FAW Jiefang Qingdao Tian V heavy truck 350 hp 8X4(12 wheels) 9.5m stake cargo truck
EXW
From $42,375
Export quote
FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks
Main model photos
239 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Qingdao Tian V heavy truck 350 hp 8X4(12 wheels) 9.5m stake cargo truck | 8x4 / 350hp / China V | From $42,375 | |
| FAW Jiefang Qingdao Tian V Heavy Truck 320 hp 8X4(12 wheels) 9.5m Stake Truck | 8x4 / 320hp / China V | From $42,778 | |
| FAW Jiefang Qingdao Tian V Heavy Truck 460hp 6X2(8 wheels) 9.65m Van Cargo Truck | 6x2 / 460hp / China V | From $36,667 | |
| FAW Jiefang Qingdao TianV heavy truck 350 hp 8X4(12 wheels) 9.5m stake truck (long wheelbase) | 8x4 / 350hp / China V | From $42,639 | |
| FAW Jiefang Qingdao TianV heavy truck 350 hp 8X4(12 wheels) 9.5m stake truck (long wheelbase) | 8x4 / 350hp / China V | From $42,639 |
FAW Jiefang Qingdao Tian V Heavy Truck 320 hp 8X4(12 wheels) 9.5m Stake Truck
EXW
From $42,778
Export quote
FAW Jiefang Qingdao Tian V Heavy Truck 460hp 6X2(8 wheels) 9.65m Van Cargo Truck
EXW
From $36,667
Export quote
FAW Jiefang Qingdao TianV heavy truck 350 hp 8X4(12 wheels) 9.5m stake truck (long wheelbase)
EXW
From $42,639
Export quote
FAW Jiefang Qingdao TianV heavy truck 350 hp 8X4(12 wheels) 9.5m stake truck (long wheelbase)
EXW
From $42,639
Export quote
Series Specs
Basic Info
Model code (announced): CA5313CCYP2K2L7T4E5A80-1 / CA5311CCYP2K2L7T4E5A80 / CA5251XXYP2K2L7T2E5A80 / CA1313P2K2L7T4E5A80 / CA5310CCYP2K2L7T4E5A80-1 / CA1313P2K2L7T4BE5A80 / CA5250XXYP2K2L7T3E5A80-3 / CA5313CCYP2K2L7T4E4A80-1 / CA1167PK2L2E4A80
Type: stake truck / enclosed cargo truck / Cargo Trucks / Chassis
Drive type: 8X4 / 6X2 / 4X2
Wheelbase: 1860+4430+1350 / 1900+4500+1350 / 6200+1350 / 1860+4500+1350 / 1860+4660+1350 / 1860+5600 / 5270mm
Box length class: 9.5 / 9.6 / 6.8m
Engine Model: WeichaiWP10.350E53 / DachaiCA6DK1-32E5 / XichaiCA6DM2-46E51 / XichaiCA6DL2-35E5 / XichaiCA6DM2-39E51 / WeichaiWP10.310E53 / XichaiCA6DL1-32E5 / DachaiCA6DK1-28E5 / XichaiCA6DL1-29E5 / XichaiCA6DL2-35E4 / WeichaiWP10.300E40 / XichaiCA6DF4-18E4 / XichaiCA6DL1-32E4
Transmission Model: Fast Gear12JSD160TA / Fast Gear8JS125TA / FAW JiefangCA12TAX210A / FAW JiefangCA10TAX160M / Fast Gear12JSD200TA / Fast Gear9JSD135A / Fast GearRTOD-11509F / Fast Gear9JS135A / FAW JiefangCA12TAX160M / FAW Jiefang CA10TAX130M overdrive / Fast Gear12JSD / FAW JiefangCA10TAX130M / Fast Gear9JS119A / Fast Gear8JS75C
Rear Axle Ratio: 4.111 / 4.1 / 3.583 / 4.875 / 4.444 / 3.7 / 4.333
Cab length: 11.993 / 11.995 / 11.845 / 8.475m
Cab width: 2.55 / 2.5 / 2.49 / 2.496m
Cab height: 3.9 / 3.995 / 3.62 / 3.55 / 4 / 3.99 / 2.9m
Front track width: 2020/2020 / 2042 / 2050/2050 / 1800 / 1964mm
rear track: 1847/1847 / 1878/1878 / 1872/1952 / 1880/1880 / 1847 / 1740mm
Curb Weight: 12.8 / 11.15 / 11.1 / 12.09 / 14.44 / 10 / 10.4 / 12.745 / 5.655ton
Rated payload: 18.005 / 19.72 / 13.77 / 18.715 / 16.43 / 14.47 / 18.06 / 9.95ton
GVWR: 31 / 25 / 15.8ton
Max. speed: 102 / 110 / 120 / 93km/h
Origin: Qingdao/Chengdu / Qingdao, Shandong
tonnage class: Heavy-duty cargo trucks / Medium-duty truck
Approach angle: 24 / 16 / 21°
departure angle: 10 / 12 / 13°
market segment: Agricultural product transport, LTL transport, green channel / Daily industrial goods transport, agricultural and sideline products transport, LTL transport, green channel / Agricultural product transport, logistics distribution, LTL transport, daily bulk cargo / Construction material transport, agricultural byproduct transport, energy minerals / Building materials, agricultural products
Remarks: Available ratio: 4.444; Front underrun protection, Bosch DeNOx 2.2 urea system, with water heater, electronically controlled silicone oil fan clutch / Front underrun protection, self-contained air supply system, extended engine oil change interval / Front underrun guard, Bosch DeNOx 2.2 urea system, electronically controlled silicone oil fan clutch / Optional ratio: 3.7 / With imported ECAS, electronically controlled air suspension, self-contained air supply system / With imported ECAS, electronically controlled air suspension / 11.00R20 16 ply steel tire, 600L aluminum fuel tank, front underrun protection, reinforced front/rear leaf springs, domestic ABS anti-lock braking system, electric tilting, electric windows, air compressor energy-saving boost valve, A/C.
Front/rear suspension: 1.515/2.838 / 1.515/2.728 / 1.515/2.93 / 1.515/2.608 / 1.515/3.02 / 1.375/2.87 / 1.312/2.243m
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai / Dachai / Xichai
Engine info: WeichaiWP10 / Dachai7.2L / Xichai11L / Xichai9L / Xichai8L / Xichai 6-cylinder
Number of cylinders: 6 / 4cylinder
Cylinder arrangement: Inline
Displacement: 9.726 / 7.146 / 11.05 / 8.6 / 7.7 / 6.74 / 8.57L
Emission standard: China V / China V (Beijing) / China IV
Max output power: 257 / 239 / 342 / 261 / 290 / 228 / 238 / 209 / 216 / 221 / 135kW
Max hp: 350 / 320 / 460 / 390 / 310 / 280 / 290 / 300 / 180Horsepower
Max torque: 1600 / 1200 / 2100 / 1500 / 1750 / 1250 / 1100 / 1150 / 1390 / 680N·m
Max torque speed: 1200-1600 / 1200-1700 / 1000-1400 / 1300-1470 / 1300-1400 / 1200-1500 / 1300-1700 / 1300-1500rpm
Rated speed: 1900 / 2300 / 2100rpm
Engine Type: Electronic high-pressure common rail + SCR / 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / Inline, 4-stroke, water-cooled, 4-valve, turbocharged intercooled / Inline 6-cylinder, electronically controlled high-pressure common rail + SCR / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled
Transmission Parameters
Transmission Brand: Fast Gear / FAW Jiefang
shift method: Manual
Forward gears: 12 / 8 / 10 / 9Gear
FAQ
What kind of truck is FAW Jiefang Qingdao FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks?
FAW Jiefang Qingdao FAW Jiefang Qingdao Tian V Heavy Truck is an export-oriented Cargo Trucks lineup with about 35 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks?
FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks export reference is about $22,292 – $43,972. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks cover?
FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks mainly covers: Drive: 6x2 / 8x4; Horsepower: 320 hp / 350 hp / 460 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks?
For FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Cargo Trucks typically used for?
Cargo Trucks covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks include?
FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks currently lists about 35 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Jiefang Qingdao Tian V Heavy Truck Cargo Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
