Huayuan Laidong 4L30F 102 hp 3L China IV Diesel Engine
EXW
Export quote
Huayuan Laidong L Series engine
Main model photos
2 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Huayuan Laidong 4L30F 102 hp 3L China IV Diesel Engine | 102hp / China IV | ||
| Huayuan Laidong 3L16CF 57 hp 1.62L China IV Diesel Engine | 57hp / China IV | ||
| Huayuan Laidong 4L18CF 68hp 1.8L China IV Diesel Engine | 68hp / China IV | ||
| Huayuan Laidong 4L22CR 90 hp 2.16L China III diesel engine | 90hp / China III / Euro III | ||
| Huayuan Laidong 4L22BZ 70hp 2.16L China II Diesel Engine | 70hp / China II/Euro II |
Huayuan Laidong 3L16CF 57 hp 1.62L China IV Diesel Engine
EXW
Export quote
Huayuan Laidong 4L18CF 68hp 1.8L China IV Diesel Engine
EXW
Export quote
Huayuan Laidong 4L22CR 90 hp 2.16L China III diesel engine
EXW
Export quote
Huayuan Laidong 4L22BZ 70hp 2.16L China II Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: L Series
Engine manufacturer: Shandong Huayuan Laidong Internal Combustion Engine Co., Ltd.
Suitable Range: light truck, mini truck, SUV, MPV and other fields / light truck, mini truck / Low-speed truck and mini truck
Intake type: Naturally aspirated
Min. fuel consumption at full load: ≤218 / ≤220 / 225 / 220 / 228 / 238 / 264g/kW.h
Engine net weight: 242 / 220 / 255kg
Engine Dimensions: 840x658x720 / 730x570x660 / 830x565x630 / 800x620x660 / 687x532x620 / 687x494x620 / 695x494x620mm
Bore × Stroke: 96x105 / 85x95 / 85x90mm
Valves per cylinder: 4pcs
Engine Brand: Huayuan Laidong
Engine Model: 4L30F / 3L16CF / 4L18CF / 4L22CR / 4L22BZ / 4L22B / 4L22
Number of cylinders: 4 / 3cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 3.04 / 1.617 / 1.809 / 2.156L
Emission standard: China IV / China III / Euro III / China II/Euro II
Max output power: 75 / 42 / 50 / 66 / 52 / 39.3 / 41kW
Max hp: 102 / 57 / 68 / 90 / 70 / 53 / 55Horsepower
Max torque: 264 / 130 / 170 / 206 / 175 / 120 / 125N·m
Max torque speed: 2200 / 2000-2400 / 2520rpm
Rated speed: 3200 / 3600rpm
Engine Type: Direct injection high-pressure common rail, turbocharged & intercooled, EGR (intercooled), aftertreatment (DOC) / Vertical, inline, water-cooled, four-stroke, direct injection, turbocharged intercooled / Inline 4-cylinder, forced cooling, direct injection / Inline 4-cylinder, forced cooling, swirl combustion chamber
FAQ
What kind of truck is Huayuan Laidong Huayuan Laidong L Series engine?
Huayuan Laidong Huayuan Laidong L Series is an export-oriented engine lineup with about 7 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Huayuan Laidong L Series engine cover?
Huayuan Laidong L Series engine mainly covers: Horsepower: 57 hp / 68 hp / 70 hp / 90 hp / 102 hp; Emission: China II/Euro II / China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Huayuan Laidong L Series engine?
For Huayuan Laidong L Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Huayuan Laidong L Series engine include?
Huayuan Laidong L Series engine currently lists about 7 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Huayuan Laidong L Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
