Proton Auto Urban Standard Load Version 8X4(12 wheels) 5.6m Pure Electric Dump Truck CATL 400.61kWh
EXW
From $101,389
Export quote
Proton Auto Dechuang Battery-Electric Truck
Main model photos
244 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Proton Auto Urban Standard Load Version 8X4(12 wheels) 5.6m Pure Electric Dump Truck CATL 400.61kWh | 8x4 | From $101,389 | |
| Proton Auto Highway Enhanced Edition 8X4(12 wheels) 7.8m Electric Dump Truck CATL 400.61kWh | 8x4 | From $95,722 | |
| Proton Auto Highway Enhanced Edition 8X4(12 wheels) 7.6m Electric Dump Truck CATL 400.61kWh | 8x4 | From $95,722 | |
| Proton Auto Highway Super Edition 8X4(12 wheels) 8m Electric Dump Truck CALB 400.6kWh | 8x4 | From $92,556 | |
| Proton Auto Highway Super Edition 8X4(12 wheels) 8m Electric Dump Truck CATL 400.61kWh | 8x4 | From $97,000 |
Proton Auto Highway Enhanced Edition 8X4(12 wheels) 7.8m Electric Dump Truck CATL 400.61kWh
EXW
From $95,722
Export quote
Proton Auto Highway Enhanced Edition 8X4(12 wheels) 7.6m Electric Dump Truck CATL 400.61kWh
EXW
From $95,722
Export quote
Proton Auto Highway Super Edition 8X4(12 wheels) 8m Electric Dump Truck CALB 400.6kWh
EXW
From $92,556
Export quote
Proton Auto Highway Super Edition 8X4(12 wheels) 8m Electric Dump Truck CATL 400.61kWh
EXW
From $97,000
Export quote
Inventory
Proton Auto Charging Edition 31T 8X4(12 wheels) 5.8m Battery Electric Dump Truck 426.59kWh
EXW
From $97,083
Export quote
Proton Auto Charging Edition 31T 8X4(12 wheels) 5.8m Battery Electric Dump Truck 400.619kWh
EXW
Export quote
Proton Auto charging version 25T 6X4(10 wheels) 6m pure electric dump truck 264.29kWh
EXW
Export quote
Proton Auto Charging Edition 31T 8X4(12 wheels) 7.2m Electric Dump Truck 256kWh
EXW
Export quote
Series Specs
Basic Info
Model code (announced): SX3317MF406XBEV2 / SX3317MF506XBEV6 / SX3317MF506XBEV5 / SX3317MF506XSEV7 / SX3317MF446XBEV4 / SX3317MF426XBEV5 / SX3317MF346XBEV7 / SX3317MF346XBEV2 / SX3257MF444XBEV1 / SX3317MF406XBEV1
Drive type: 8X4 / 6X4
Wheelbase: 1800+3175+1400 / 1800+4975+1400 / 1800+5175+1400 / 1800+4775+1400 / 1800+4375+1400 / 1800+3375+1400 / 4375+1400 / 1800+3975+1400 / 1800+4575+1400mm
Cab length: 9.4 / 11.7 / 11.5 / 11.9 / 11.1 / 9.6 / 9 / 10.4 / 11m
Cab width: 2.55m
Cab height: 3.65 / 3.6 / 3.5m
CLTC range: 280 / 320 / 340 / 200km
Curb Weight: 16 / 24.5 / 23.8 / 25 / 20.7 / 18.9 / 20.1 / 21.1ton
Rated payload: 14.87 / 6.37 / 7.07 / 5.87 / 10.17 / 11.97 / 4.17 / 10.77 / 9.77ton
GVWR: 31 / 25ton
Max. speed: 89 / 80km/h
Origin: Xi'an, Shaanxi
tonnage class: Heavy truck
Energy Type: Electric
electric motor
Motor 1 Brand: Suzhou Green Control / Zhide / Xi'an Zhide
Motor 1 Model: TZ460XS-LKM3002 / TZ380XS030 / TZ380XS002
Motor Type: Permanent magnet synchronous motor
total rated power: 360 / 290 / 250kW
Peak power: 550 / 430 / 360kW
total rated torque: 1750N·m
total peak torque: 2800 / 2500N·m
Motor 1 Peak Power: 550kW
Battery/Charging
Charging method: Fast Charge
Battery Brand: CATL / CALB / Rongchu / Juwan / Guangzhou Juwang
Battery type: Lithium Iron Phosphate Battery / NMC lithium battery pack
fast charge time:
Battery capacity: 400.61 / 400.6 / 400.619 / 600.92 / 400.62 / 426.59 / 264.29 / 256kWh
Transmission Parameters
Number of gears: 4 / 6Gear
shift type: AMT manual/auto
Transmission Model: J4S280+QH708 / 4.0E+280
Transmission Brand: Fast Gear
Forward gears: 4Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Dump type
Cargo box length: 5.6 / 7.8 / 7.6 / 8 / 8.6 / 8.2 / 8.8 / 5.8 / 6 / 6.5 / 7.2m
Cargo box width: 2.35 / 2.3m
Cargo box height: 0.9 / 1.5m
Cab parameters
Cab: Standard Cab / M medium-length flat roof / E3-M Medium Long Flat Top
seating capacity: 2Personnel
Seat rows: Sleeper cab
FAQ
What kind of truck is Proton Auto Dechuang Battery-Electric Truck electric dump truck?
Proton Auto Dechuang Battery-Electric Truck is an export-oriented electric dump truck lineup with about 36 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Proton Auto Dechuang Battery-Electric Truck?
Proton Auto Dechuang Battery-Electric Truck export reference is about $89,028 – $114,653. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Proton Auto Dechuang Battery-Electric Truck cover?
Proton Auto Dechuang Battery-Electric Truck mainly covers: Drive: 6x4 / 8x4. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Proton Auto Dechuang Battery-Electric Truck?
For Proton Auto Dechuang Battery-Electric Truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is electric dump truck typically used for?
electric dump truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Proton Auto Dechuang Battery-Electric Truck include?
Proton Auto Dechuang Battery-Electric Truck currently lists about 36 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Proton Auto Dechuang Battery-Electric Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
