Qingling Isuzu Giga 520hp 8X4(12 wheels) 4 Axle SANY 52m Concrete Pump Truck (China VI)
EXW
Export quote
SANY Group Isuzu chassis concrete pump truck
Main model photos
28 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Qingling Isuzu Giga 520hp 8X4(12 wheels) 4 Axle SANY 52m Concrete Pump Truck (China VI) | 8x4 / 520hp / China VI |
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SANY 56m concrete pump truck (Isuzu chassis) | 390hp / China III / Euro III | ||
| SANY 43m concrete pump truck (Isuzu chassis) | — | ||
| SANY 48m Concrete Pump Truck (Isuzu Chassis) | 390hp / China III / Euro III | ||
| SANY 32m Concrete Pump Truck (Isuzu Chassis) | — | ||
| SANY 28m Concrete Pump Truck (Isuzu Chassis) | — |
SANY 56m concrete pump truck (Isuzu chassis)
EXW
Export quote
SANY 43m concrete pump truck (Isuzu chassis)
EXW
Export quote
SANY 48m Concrete Pump Truck (Isuzu Chassis)
EXW
Export quote
SANY 32m Concrete Pump Truck (Isuzu Chassis)
EXW
Export quote
SANY 28m Concrete Pump Truck (Isuzu Chassis)
EXW
Export quote
Series Specs
Basic Info
Model code (announced): SYM5447THBF / SY5418THB 56E / SY5313THB43 / SY5385THB48Ⅲ / SY5230THB32W / SY5230THB28W
Pumping displacement: 170 / 120m³/h
Max pumping height: 52 / 56 / 43 / 48 / 32 / 28m
Drive type: 8X4
Wheelbase: 2100+4325+1370mm
Overall Dimensions: L×W×H: 13.95×2.55×4 / 13.760×2.5×4 / 11.52×2.5×3.99 / 13.31×2.5×4 / 10.6×2.5×3.85m
Max. travel speed: 85 / 80km/h
Curb Weight: 44 / 41.46 / 31.49 / 38 / 23.7 / 23.5ton
Body Parameters
Water tank capacity: 600L
Chassis Specs
Axle Count: 4 / 5
Chassis Series: Juka / Isuzu CYZ51Y / IsuzuCYZ51Q / IsuzuCYH51Y
Chassis Model: QL5440TZZW7VDHY
Pumping system
Pumping displacement (low/high): 120/170 / 67/120 / 100/140 / 120/70m³/h
Pumping pressure (low/high): 8.3 / 6.38/11.8 / 8.3/12 / 6.4/11.8
Pumping strokes (low/high): 12/17 / 13/24 / 14/20 / 24/14Times/min
Delivery cylinder: bore × stroke: 260×2200 / 230×2000mm
Oil pressure: 32Mpa
Delivery pipe diameter: 125mm
Boom Outriggers
Boom Horizontal Length: 51 / 38.8 / 44 / 28.1 / 24.1m
Boom Vertical Depth: 36.6 / 26.8 / 30 / 16.6 / 12.6m
Boom Section Count: 5-arm section / Four-arm section
Turntable Rotation Angle: 220 / 270 / 365°
Min unfolded length: 15.2 / 11.8 / 11 / 7.4m
Outrigger spread width: front/rear: 9300/11670 / 8480/8125 / 9300/10500 / 6000/5000mm
Boom Section 1 - Length: 11400 / 8455 / 9060 / 7900mm
first arm section angle: 90 / 93°
Boom Section 2 - Length: 9230 / 7060 / 8010 / 6700 / 5700mm
Boom Section 2 - Angle: 180°
Boom Section 3 - Length: 8750 / 6890 / 7800 / 6700 / 5700mm
Boom Section 3 - Angle: 180 / 260°
4th arm section length: 11060 / 8120 / 9465 / 6800 / 4820mm
Boom Section 4 - Angle: 240°
Engine parameters
Engine Model: Qingling Isuzu6WG1-TCG62 / 6WF1D / 6WF1A
fuel type: Diesel
Displacement: 15.681 / 14.256L
Emission standard: China VI / China III / Euro III
Max output power: 382 / 287 / 265kW
Max hp: 520 / 390Horsepower
Rated speed: 1800rpm
Transmission Parameters
Number of gears: 8Gear
FAQ
What kind of truck is SANY Truck SANY Group Isuzu chassis concrete pump truck?
SANY Truck SANY Group Isuzu chassis is an export-oriented concrete pump truck lineup with about 6 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does SANY Group Isuzu chassis concrete pump truck cover?
SANY Group Isuzu chassis concrete pump truck mainly covers: Drive: 8x4; Horsepower: 390 hp / 520 hp; Emission: China III / Euro III / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SANY Group Isuzu chassis concrete pump truck?
For SANY Group Isuzu chassis concrete pump truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is concrete pump truck typically used for?
concrete pump truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does SANY Group Isuzu chassis concrete pump truck include?
SANY Group Isuzu chassis concrete pump truck currently lists about 6 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SANY Group Isuzu chassis concrete pump truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
