Dongfeng Liuqi Chenglong M3 200 hp 4X2(6 wheels) Truck-mounted Crane
EXW
From $35,556
Export quote
Dongfeng M3 heavy truck truck-mounted crane
Main model photos
490 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Liuqi Chenglong M3 200 hp 4X2(6 wheels) Truck-mounted Crane | 4x2 / 200hp / China V | From $35,556 | |
| Dongfeng Liuqi Chenglong M3 180 hp 4X2(6 wheels) Truck-Mounted Crane | 4x2 / 180hp / China V | ||
| Dongfeng Liuqi Chenglong M3 180 hp 4X2(6 wheels) Truck-Mounted Crane | 4x2 / 180hp / China IV |
Dongfeng Liuqi Chenglong M3 180 hp 4X2(6 wheels) Truck-Mounted Crane
EXW
Export quote
Dongfeng Liuqi Chenglong M3 180 hp 4X2(6 wheels) Truck-Mounted Crane
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 9.0×2.55×3.78 / 9.0×2.5×3.55m
Type: truck-mounted crane
Drive type: 4X2
Wheelbase: 5100mm
Rated mass: 7.305 / 4.805 / 4.555ton
GVWR: 18 / 15.8 / 1.555ton
Front/rear suspension: 1.445/2.455 / 1.445/1.855m
Energy Type: Diesel
Body Parameters
Other special notes: Standard semi-floating cab suspension, manual hydraulic tilt, mechanical damping driver seat, power windows, remote central locking, AC, onboard terminal (tachograph + compatible with BeiDou GPS), external sun visor, multi-state switch, domestic valves, ABS (WABCO), automatic slack adjuster, maintenance-free battery, direct-drive fan, rotary FARIZON throttle, under-vehicle start/stop function
Vehicle certification code: LZ5180JSQM3AB / LZ5163JSQM3AB / LZ5161JSQRAPA
Body Brand: DongfengLiuqi
Engine parameters
Injection System: Common Rail
Engine Brand: Yuchai
Engine Model: YuchaiYC6JA200-50 / YuchaiYC6J180-50 / YuchaiYC6J180-46
Displacement: 6.87 / 6.494 / 6.49L
Emission standard: China V / China IV
Max output power: 147 / 132kW
Max hp: 200 / 180Horsepower
Max torque: 800 / 650 / 590N·m
Max torque speed: 1200-1800 / 1200-1700rpm
Rated speed: 2300 / 2500rpm
Chassis Specs
Chassis Brand: DongfengLiuqi
Chassis Series: ChenglongM3
Chassis Model: LZ1182M3ABT / LZ5163XXYM3ABT / LZ1161RAPAT
Frame Dimensions: 273(8+5)mm
rear axle description: 153
Axle ratio: 4.875 / 5.571
Leaf spring count: 11/12+9 / 11/12+9,2/2+1,2/3+2,3/3+2
clutch: Φ395
Transmission Parameters
Number of gears: 8Gear
Transmission Model: Fast Gear8JS85E
Cab parameters
Cab: Sleeper cab / M30 / M30 flat roof
Tire
Tire Size: 10.00R20 / 10.00R20 11R22.5 / 10.00-20,10.00R20,9.00R20,11R22.5,275/80R22.5
Number of tires: 6pcs
FAQ
What kind of truck is Dongfeng Dongfeng M3 heavy truck truck-mounted crane?
Dongfeng Dongfeng M3 heavy truck is an export-oriented truck-mounted crane lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng M3 heavy truck truck-mounted crane?
Dongfeng M3 heavy truck truck-mounted crane export reference is about From $35,556. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng M3 heavy truck truck-mounted crane cover?
Dongfeng M3 heavy truck truck-mounted crane mainly covers: Drive: 4x2; Horsepower: 180 hp / 200 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng M3 heavy truck truck-mounted crane?
For Dongfeng M3 heavy truck truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng M3 heavy truck truck-mounted crane include?
Dongfeng M3 heavy truck truck-mounted crane currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng M3 heavy truck truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
