WLY WLY5TS32 (4.71) 5-Speed Manual Transmission

Export reference
MSRP N/A
Max input torque:: 320N·m
1st gear ratio:: 4.71
synchronizer:: Yes
Transmission Model: WLY5TS32
Transmission Brand: WLY
Features: Forward gears fully synchronized, with shift/gear selection positioning mechanism.

Overview

The WLY WLY5TS32 (4.71) 5-Speed Manual Transmission is a parts product with spec WLY5TS32.

Model Specs

Legend: ● Standard ○ Optional - N/A

Transmission Parameters
Transmission Brand: WLY
Transmission series: WLY 5-Speed Series
Features: Forward gears fully synchronized, with shift/gear selection positioning mechanism.
Max input torque: 320N·m
1st gear ratio: 4.71
synchronizer: Yes
2nd gear ratio: 2.47
3rd gear ratio: 1.65
4th gear ratio:
5th gear ratio: 0.72
Reverse Gear 1 Ratio: 4.51
Transmission weight: 62kg
Transmission oil capacity: 3.1L
Number of gears: 5Gear
shift type: Manual
Transmission Model: WLY5TS32
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:

Photos

0 photos

FAQ

What transport jobs is WLY WLY5TS32 (4.71) 5-Speed Manual Transmission suited for?

Match WLY WLY5TS32 (4.71) 5-Speed Manual Transmission to your job using drive, horsepower and emission on this page. Include use case, destination and quantity in your quote request.

How does WLY WLY5TS32 (4.71) 5-Speed Manual Transmission differ from other variants in the same series?

WLY WLY5TS32 (4.71) 5-Speed Manual Transmission belongs to WLY 5-Speed Series (transmission). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for WLY WLY5TS32 (4.71) 5-Speed Manual Transmission?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export WLY WLY5TS32 (4.71) 5-Speed Manual Transmission?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
