WLYWLY9W85 9-Speed Manual Transmission

Export reference
MSRP N/A
Max input torque:: 850N·m
1st gear ratio:: 12.58
synchronizer:: Yes
WLYWLY9W85 9-Speed Manual Transmission exterior
View more photos (1)
Transmission Model: WLY9W85
Transmission Brand: WLY
Features: Front single, rear dual, full synchronizer

Overview

The WLYWLY9W85 9-Speed Manual Transmission is a parts product with spec WLY9W85.

Model Specs

Legend: ● Standard　○ Optional　- N/A

Transmission Parameters
Transmission Brand: WLY
Transmission series: WLY 9 series
Features: Front single, rear dual, full synchronizer
Max input torque: 850N·m
1st gear ratio: 12.58
synchronizer: Yes
Main box center distance: 123mm
2nd gear ratio: 9.05
3rd gear ratio: 6.62
4th gear ratio: 4.83
5th gear ratio: 3.53
6th gear ratio: 2.56
7th gear ratio: 1.88
8th gear ratio: 1.37
Reverse Gear 1 Ratio: 12.48
Transmission weight: 190kg
9th gear ratio:
Transmission oil capacity: 12L
Number of gears: 9Gear
shift type: Manual
Transmission Model: WLY9W85
shift method: Manual
Forward gears: 9Gear
Number of Reverse Gears:

Photos

Exterior1

WLYWLY9W85 9-Speed Manual Transmission Exterior (1) | 86Trucks

1 photos

FAQ

What transport jobs is WLYWLY9W85 9-Speed Manual Transmission suited for?

Match WLYWLY9W85 9-Speed Manual Transmission to your job using drive, horsepower and emission on this page. Include use case, destination and quantity in your quote request.

How does WLYWLY9W85 9-Speed Manual Transmission differ from other variants in the same series?

WLYWLY9W85 9-Speed Manual Transmission belongs to WLY WLY9-speed series (transmission). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for WLYWLY9W85 9-Speed Manual Transmission?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export WLYWLY9W85 9-Speed Manual Transmission?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
