JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck

Export reference
From $17,361
MSRP ¥12.5M CNY
Emission: China V
Fuel: Diesel
Transmission: Fast Gear
Curb Weight:: 5.465ton
Wheelbase:: 3600mm
Tire Size:: 8.25R16LT 18PR
Rated payload: 4.995ton
Drive 4X2 (6 wheels)
Horsepower 170
Cargo box type: Rear-dump body

Overview

The JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck is a Light Truck featuring 4.995t payload, 11.2t GVW, Rear-dump body cargo body and 4X2 (6 wheels) drive. On the powertrain side, it comes with a Yunnei PowerYNF40E1 engine, 170 hp, China V emissions and Fast Gear transmission.

China V 170 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HFC3110P91K1C4NV
Drive type: 4X2
Wheelbase: 3600mm
engine: Yunnei PowerYNF40E1
transmission: Fast Gear8JS75C
Cab length: 5.995m
Cab width: 2.18m
Cab height: 2.42m
Front track width: 1695mm
rear track: 1785mm
Curb Weight: 5.465ton
Rated payload: 4.995ton
GVWR: 11.2ton
Origin: Hefei, Anhui
tonnage class: Light Truck
Approach angle: 22°
departure angle: 23°
Remarks: Tilt cab, pneumatic drum brakes, power steering, exhaust brake, wide-angle and blind-spot mirrors, clutch booster, steering wheel (entertainment button module), overhead storage box, solid paint
Version: Transport type
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power
Engine Model: Yunnei PowerYNF40E1
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 3.92L
Emission standard: China V
Max output power: 125kW
Max hp: 170Horsepower
Max torque: 600N·m
Max torque speed: 1300-1900rpm
Rated speed: 2600rpm
Engine Type: 4-valve, centrally mounted injector, centrally mounted camshaft, high-pressure common rail fuel injection, rear-mounted gear train
Transmission Parameters
Transmission Model: Fast Gear8JS75C
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Rear-dump body
Cargo box type: Rear-dump body
Cargo box length: 4.15m
Cargo box width: 2.3m
Cargo box height: 0.55m
Cab parameters
Cab: Single Row
Cab width: 2071mm
fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 120L
Chassis Specs
Front axle description: 2.7T
Front axle allowable load: 4000kg
Frame Dimensions: 200×865×6+4mm
rear axle description: 7.2T
rear axle allowable load: 7200kg
Leaf spring count: 9/9+7
Tire
Tire Size: 8.25R16LT 18PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
AC control type: Manual
Power Windows:
Electric Heated Rearview Mirror:
Reverse Camera:
Electronic Central Lock:
Service brake
Parking brake: Spring brake

Photos

0 photos

FAQ

What is the export price of JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck, and what does it include?

JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck export reference is about From $17,361; MSRP is ¥12.5M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck?

Key specs of JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck: Drive: 4x2; Horsepower: 170 hp; Emission: China V; Fuel: Diesel; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck suited for?

JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck differ from other variants in the same series?

JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck belongs to JAC G light truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export JAC Junling G Series V6 Transport Type 170 hp 4X2(6 wheels) 4.15 m dump truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
