Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand)

Export reference
From $105,556
MSRP ¥76M CNY
Fuel: Diesel
Drive: 4X2 (6 wheels)
Wheelbase:: 5600mm
Model code (announced):: SMQ5201THB
Pumping displacement:: 115m³/h
Overall Dimensions: L×W×H:: 10×2.5×3.94m
Curb Weight: 20.3ton
Horsepower 340
Max output power: 249kW
Emission China IV

Overview

The Senyuan Heavy Industry Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand) is a concrete pump truck featuring 20.3ton GVW, 340 hp, 249kW power and 4X2 (6 wheels) drive. On the powertrain side, it comes with China IV emissions and Diesel fuel.

China IV 340 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SMQ5201THB
Pumping displacement: 115m³/h
Drive type: 4X2
Wheelbase: 5600mm
Overall Dimensions: L×W×H: 10×2.5×3.94m
Curb Weight: 20.3ton
Chassis Specs
Axle Count:
Chassis Series: SinotrukHOWO
Chassis Model: ZZ5207N561D1
Pumping system
Pumping displacement (low/high): 115/75m³/h
Pumping pressure (low/high): 6.3/10.2MPa
Pumping strokes (low/high): 23/15Times/min
Delivery cylinder: bore × stroke: 230×2000mm
Engine parameters
Injection System: Common Rail
Engine Model: DongfengISLe340 40
fuel type: Diesel
Displacement: 8.9L
Emission standard: China IV
Max output power: 249kW
Max hp: 340Horsepower
Rated speed: 2100rpm
Boom Outriggers
Boom Vertical Height: 26.5m
Boom Section Count: 4
Outrigger spread width: front/rear: 5.6/2.9/6.5mm

Photos

Exterior3

3 photos

FAQ

What is the export price of Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand), and what does it include?

Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand) export reference is about From $105,556; MSRP is ¥76M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand) use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand)?

Key specs of Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand): Drive: 4x2; Horsepower: 340 hp; Emission: China IV; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand) suited for?

Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand) is a concrete pump truck model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand) differ from other variants in the same series?

Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand) belongs to Senyuan Heavy Industry Sinotruk HOWO chassis (concrete pump truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sinotruk HOWO 340 hp 4X2(6 wheels) 27m Concrete Pump Truck (Senyuan Brand)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
