Sinotruk Hohan J7B 340 hp 6X4(10 wheels) 7.99m³ concrete mixer truck chassis

Export reference
MSRP N/A
Curb Weight:: 13.42ton
Wheelbase:: 1800+3050+1350mm
Tire Size:: 11.00R20,12.00R20
Cab dimensions:: 9.075×2.52×3.25m
Truck Type:: Concrete mixer truck
Front/rear track width:: Front track: 1930/1930mm; Rear track: 1800/1800mm
Drive 8X4 (12 wheels)
Horsepower 340
Emission China V
Fuel Diesel

Overview

The Sinotruk Hohan J7B 340 hp 6X4(10 wheels) 7.99m³ concrete mixer truck chassis is a concrete mixer truck featuring 13.42ton GVW, 8X4 (12 wheels) drive and H16 cab. On the powertrain side, it comes with 340 hp, China V emissions and Diesel fuel.

China V 340 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 9.075×2.52×3.25m
Drive type: 8X4
Truck Type: Concrete mixer truck
Wheelbase: 1800+3050+1350mm
Front/rear track width: Front track: 1930/1930mm; Rear track: 1800/1800mm
Vehicle origin: Jinan, Shandong
Curb Weight: 13.42ton
Max. speed: 82km/h
Front/rear suspension: 1.55/2.2m
Body Parameters
Mixing drum capacity: 7.99m³
Vehicle certification code: ZZ5315GJBN3066E1
Body Brand: Sinotruk
Engine parameters
Injection System: Common Rail (China V)
Engine Model: SinotrukD10.34-50
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 9.726L
Emission standard: China V
Max output power: 249kW
Max hp: 340Horsepower
Rated speed: 1900rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail
Chassis Specs
Chassis Series: Hohan J7B
Chassis Model: ZZ1315N3066E1
Front axle description: H153
Frame Dimensions: 850×300×80×(8+8)mm
rear axle description: ST16
Axle ratio: 4.42
Leaf spring count: 4/4/5
Transmission Parameters
Number of gears: 10Gear
Transmission Model: SinotrukHW19710
Cab parameters
Cab: H16
Tire
Tire Size: 11.00R20,12.00R20
Number of tires: 12pcs

Photos

Exterior1
