Sinotruk Hohan J7B 380 hp 6X4(10 wheels) 7.99m³ concrete mixer truck chassis
EXW
Export quote
Sinotruk J7B Heavy Truck concrete mixer truck
Main model photos
262 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Hohan J7B 380 hp 6X4(10 wheels) 7.99m³ concrete mixer truck chassis | 8x4 / 380hp / China V | ||
| Sinotruk Hohan J7B 340 hp 6X4(10 wheels) 7.99m³ concrete mixer truck chassis | 8x4 / 340hp / China V | ||
| Sinotruk Haohan J7B 380hp 8X4(12 wheels) 6.9m³ Concrete Mixer Truck Chassis | 8x4 / 380hp / China V | From $51,208 | |
| Sinotruk Haohan J7B 340hp 8X4(12 wheels) 6.9m³ Concrete Mixer Truck Chassis | 8x4 / 340hp / China V | From $49,403 | |
| Sinotruk Haohan J7B 380hp 8X4(12 wheels) 6.9m³ Concrete Mixer Truck Chassis | 8x4 / 380hp / China V | From $48,847 |
Sinotruk Hohan J7B 340 hp 6X4(10 wheels) 7.99m³ concrete mixer truck chassis
EXW
Export quote
Sinotruk Haohan J7B 380hp 8X4(12 wheels) 6.9m³ Concrete Mixer Truck Chassis
EXW
From $51,208
Export quote
Sinotruk Haohan J7B 340hp 8X4(12 wheels) 6.9m³ Concrete Mixer Truck Chassis
EXW
From $49,403
Export quote
Sinotruk Haohan J7B 380hp 8X4(12 wheels) 6.9m³ Concrete Mixer Truck Chassis
EXW
From $48,847
Export quote
Series Specs
Basic Info
Cab dimensions: 9.075×2.52×3.25 / 9.9×2.496×3.13 / 8.125×2.496×3.13 / 9.2×2.496×3.13 / 8.925×2.496×3.13 / 8.735×2.496×3.13 / 7.825×2.496×3.13m
Drive type: 8X4 / 6X4
Truck Type: Concrete mixer truck
Front/rear track width: Front track: 1930/1930mm; Rear track: 1800/1800mm / Front track: 2022/2022mm; Rear track: 1830/1830 / Front track: 2022mm; Rear track: 1830/1830mm / Front track: 2022mm; Rear track: 1830/1830 / Front track: 2020/2020mm; Rear track: 1830/1830mm
Wheelbase: 1800+3050+1350 / 1800+3600+1350 / 4325+1350 / 4125+1350 / 3825+1350 / 1800+3200+1350 / 3625+1350mm
Vehicle origin: Jinan, Shandong
Curb Weight: 13.42 / 10.41 / 9 / 10.36 / 8.78 / 8.86 / 8.76 / 8.7ton
Max. speed: 82km/h
Front/rear suspension: 1.55/2.2 / 1.55/1.6 / 1.55/1.71 / 1.55/1.3 / 1.55/1.7 / 1.55/1.4m
Body Parameters
Mixing drum capacity: 7.99 / 6.9 / 5.4 / 7.1 / 4.9m³
Vehicle certification code: ZZ5315GJBN3066E1 / ZZ1315N3666E1L / ZZ1255N4346E1L / ZZ1315N3666D1 / ZZ1315N3266D1 / ZZ1255N4346D1B / ZZ1255N4146D1 / ZZ1255N3846D1 / ZZ1255N3646D1 / ZZ1315N3066E1
Body Brand: Sinotruk
Others: Axle ratio optional 5.73; gas cylinder 450L / Optional ratios 4.8, 5.73; gas cylinder 450L / Optional ratios 4.875, 5.833; gas cylinder 450L / Axle ratio optional 5.73, fuel tank capacity 300L / Optional ratios 4.8, 5.73; fuel tank capacity 300L / Optional ratios 4.8, 5.73; fuel tank capacity 260L / Optional ratios 4.875, 5.833; fuel tank 300L
Engine parameters
Injection System: Common Rail (China V) / Natural gas
Engine Model: SinotrukD10.38-50 / SinotrukD10.34-50 / SinotrukT12.38-50 / SinotrukT10.34-50 / SinotrukD10.38-40 / SinotrukD10.34-40
Number of cylinders: 6cylinder
fuel type: Diesel / LNG (liquefied natural gas)
Displacement: 9.726 / 11.596L
Emission standard: China V / China IV
Max output power: 276 / 249 / 279 / 250 / 278kW
Max hp: 380 / 340Horsepower
Rated speed: 1900 / 2200 / 2000 / 1900rpm / 2000rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail / Inline, 4-stroke, turbocharged intercooled, water-cooled, electronically controlled gas system, spark plug ignition, lean burn / Electric AC compressor, spark plug ignition
Chassis Specs
Chassis Series: Hohan J7B
Front axle description: H153 / HF9 (drum) / 153 / HF7 (drum)
Frame Dimensions: 850×300×80×(8+8) / 850×300×80×(8+8+8)mm
rear axle description: ST16 / HC16 / H457
Axle ratio: 4.42 / 4.8 / 4.444
Leaf spring count: 4/4/5 / 4/4/-，11/11/-，11/11/12 / 4/-，4/5，4/12，9/-，9/12 / 11/11/12
Transmission Parameters
Number of gears: 10 / 12Gear
Transmission Model: SinotrukHW19710 / SinotrukHW19712
Cab parameters
Cab: H16
Tire
Tire Size: 11.00R20,12.00R20 / 12.00R20(11.00R20/12R22.5/315) / 11.00R20(12.00R20/12R22.5/315) / 11.00R20(12.00R20) / 12.00R20(11.00R20)
FAQ
What kind of truck is Sinotruk Sinotruk J7B Heavy Truck concrete mixer truck?
Sinotruk Sinotruk J7B Heavy Truck is an export-oriented concrete mixer truck lineup with about 40 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk J7B Heavy Truck concrete mixer truck?
Sinotruk J7B Heavy Truck concrete mixer truck export reference is about $36,347 – $51,208. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk J7B Heavy Truck concrete mixer truck cover?
Sinotruk J7B Heavy Truck concrete mixer truck mainly covers: Drive: 8x4; Horsepower: 340 hp / 380 hp; Emission: China V; Fuel: Diesel / LNG (liquefied natural gas). Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk J7B Heavy Truck concrete mixer truck?
For Sinotruk J7B Heavy Truck concrete mixer truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk J7B Heavy Truck concrete mixer truck include?
Sinotruk J7B Heavy Truck concrete mixer truck currently lists about 40 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk J7B Heavy Truck concrete mixer truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
