WLY 545 5-speed Manual Transmission

Export reference
MSRP N/A
Max input torque:: 470N·m
1st gear ratio:: 6.3
synchronizer:: Yes
Transmission Model: WLY545
Transmission Brand: WLY
Features: Single countershaft, with synchronizer

Overview

The WLY 545 5-speed Manual Transmission is a parts product with spec WLY545.

Model Specs

Legend: ● Standard ○ Optional - N/A

Transmission Parameters
Transmission Brand: WLY
Transmission series: WLY 5-Speed Series
Features: Single countershaft, with synchronizer
Max input torque: 470N·m
1st gear ratio: 6.3
synchronizer: Yes
Main box center distance: 121mm
2nd gear ratio: 3.447
3rd gear ratio: 2.11
4th gear ratio: 1.32
5th gear ratio:
Reverse Gear 1 Ratio: 6.6
Transmission weight: 118kg
Transmission oil capacity: 5.5L
Number of gears: 5Gear
shift type: Manual
Transmission Model: WLY545
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
