YANMAR Vio17 Crawler Excavator

Export reference
MSRP N/A
Model:: Vio17
Engine Model:: crawler excavator
Tonnage:: 2ton
Bucket capacity:: 0.05cubic meter
Machine dimensions:: 3.45×1.28×2.37mm
Track shoe width:: 230mm
YANMAR Vio17 Crawler Excavator exterior
View more photos (3)
Operating weight: 1.8ton
Bucket type: backhoe
Fuel Tank Capacity: 20L
Product power: Conventional Power

Overview

The YANMAR Vio17 Crawler Excavator is a excavator featuring 1.8ton GVW, backhoe bucket capacity, 20L tank capacity and Conventional Power power. On the powertrain side, it comes with a crawler excavator engine.

Model Specs

Legend: ● Standard　○ Optional　- N/A

Basic Info
Model: Vio17
Engine Model: crawler excavator
Product power: Conventional Power
Bucket type: backhoe
Tonnage: 2ton
Bucket capacity: 0.05cubic meter
Operating weight: 1.8ton
Machine dimensions: 3.45×1.28×2.37mm
Track shoe width: 230mm
Track gauge: 1050mm
Rear Overhang Radius: 640mm
Min ground clearance: 175cm
hydraulic system
Max flow of main pump: 17.6×2+13.2L/min
Oil capacity
Fuel Tank Capacity: 20L
performance specs
Travel speed: 4.3/2.1km/h
Bucket digging force: 15.2kN
Operating Range
Max digging radius: 3810mm
Max digging depth: 2310mm
Max digging height: 3690mm
Max unloading height: 2630mm
Max vertical digging depth: 2200mm
Engine parameters
Engine Model: YANMAR3TNV70-XBV
Max output power: 10.1kW

Photos

Exterior3

YANMAR Vio17 Crawler Excavator Exterior (1) | 86Trucks YANMAR Vio17 Crawler Excavator Exterior (2) | 86Trucks YANMAR Vio17 Crawler Excavator Exterior (3) | 86Trucks

3 photos

FAQ

What transport jobs is YANMAR Vio17 Crawler Excavator suited for?

YANMAR Vio17 Crawler Excavator is a excavator model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does YANMAR Vio17 Crawler Excavator differ from other variants in the same series?

YANMAR Vio17 Crawler Excavator belongs to YANMAR Crawler Excavator (excavator). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for YANMAR Vio17 Crawler Excavator?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export YANMAR Vio17 Crawler Excavator?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
