Shantui Excavator JCM906D Crawler Excavator
EXW
Export quote
SUNWARD crawler excavator
Main model photos
24 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Shantui Excavator JCM906D Crawler Excavator | — | ||
| Shantui Excavator JCM907D Crawler Excavator | — | ||
| Shantui Excavator JCM913D Crawler Excavator | — | ||
| Shantui Excavator JCM913 Crawler Excavator | — | ||
| Shantui Excavator JCM921C Crawler Excavator | — |
Shantui Excavator JCM907D Crawler Excavator
EXW
Export quote
Shantui Excavator JCM913D Crawler Excavator
EXW
Export quote
Shantui Excavator JCM913 Crawler Excavator
EXW
Export quote
Shantui Excavator JCM921C Crawler Excavator
EXW
Export quote
Series Specs
Basic Info
Model: JCM906D / JCM907D / JCM913D / JCM913 / JCM921C / JCM924C
Engine Model: crawler excavator / YANMAR4TNV94L / CumminsCummins B3.3(Tier2) / CumminsCummins B3.9-c(Tier2) / CumminsCummins B5.9-C / CumminsCummins B5.9-c(Tier2)
Product power: Conventional Power
Bucket type: backhoe
Tonnage: 6 / 7 / 13 / 21 / 24ton
Bucket capacity: 0.22 / 0.28 / 0.55 / 0.9 / 1.2cubic meter
Operating weight: 5.85 / 7.1 / 12.8 / 20.5 / 24.1ton
Arm Length: 1600 / 1650 / 2500mm
Machine dimensions: 5.851×1.88×2.621 / 9.146×2.21×2.595 / 7.718×2.5×2.674 / 9.548×2.8×3.073mm
Track shoe width: 400 / 450 / 500 / 600mm
Track gauge: 1480 / 2000mm
Counterweight ground clearance: 708 / 775 / 912 / 1120mm
Min ground clearance: 302 / 332 / 425 / 470cm
Rear Overhang Radius: 1655 / 1750 / 2318 / 2905 / 3086mm
hydraulic system
Max flow of main pump: 2×60.5 / 2×74.8 / 2×108L/min
travel hydraulic circuit: 22 / 27.5 / 31.9Mpa
Swing Hydraulic Circuit: 21.5 / 23.5 / 25.5Mpa
Oil capacity
Fuel Tank Capacity: 110 / 170 / 238 / 360L
coolant: 10 / 20 / 25L
hydraulic oil tank: 90 / 100 / 120 / 250L
Engine Oil Capacity: 12 / 13 / 15 / 20L
performance specs
Travel speed: 2.23/4.62 / 3.14/5.26 / 3.61/5.59 / 3.3/5.4 / 3.2/4.9km/h
Bucket digging force: 29.3 / 53.6 / 73.5 / 115kN
Arm Digging Force: 39 / 39.9 / 60.8 / 92.5kN
Max tractive force: 67.7kN
Operating Range
Max digging radius: 6195 / 6326 / 9671mm
Max digging depth: 3858 / 4147 / 5537 / 6605mm
Max digging height: 5784 / 7118 / 8495 / 9281mm
Max unloading height: 3986 / 5110 / 6065 / 6480mm
Max vertical digging depth: 3786 / 3579 / 4907 / 5735mm
Engine parameters
Max output power: 35.5 / 45 / 86 / 112 / 133kW
FAQ
What kind of truck is SUNWARD SUNWARD crawler excavator excavator?
SUNWARD SUNWARD crawler excavator is an export-oriented excavator lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is excavator typically used for?
excavator specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does SUNWARD crawler excavator include?
SUNWARD crawler excavator currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SUNWARD crawler excavator?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
