LONGGONG LG6225E Crawler Excavator
EXW
Export quote
LONGGONG LONGGONG Crawler Excavator
Main model photos
9 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| LONGGONG LG6225E Crawler Excavator | — | ||
| LONGGONG LG6220D Crawler Excavator | — | ||
| LONGGONG LG6075 Crawler Excavator | — |
LONGGONG LG6220D Crawler Excavator
EXW
Export quote
LONGGONG LG6075 Crawler Excavator
EXW
Export quote
Series Specs
Basic Info
Model: LG6225E / LG6220D / LG6075
Engine Model: crawler excavator / CumminsB5.9-C / YANMAR 4TNV98-SSU
Product power: Conventional Power
Bucket type: backhoe
Tonnage: 22 / 7ton
Bucket capacity: 1 / 0.3cubic meter
Operating weight: 21.8 / 7.68ton
boom length: 5675mm
Arm Length: 2920mm
Machine dimensions: 6.194×2.2×2.664mm
Track shoe width: 450mm
Track gauge: 2130mm
Counterweight ground clearance: 804mm
Min ground clearance: 356cm
Rear Overhang Radius: 1800mm
hydraulic system
Max flow of main pump: 208x2 / 156.2L/min
Working hydraulic circuit: 27.4
Oil capacity
Fuel Tank Capacity: 380 / 143L
hydraulic oil tank: 280 / 119L
performance specs
Travel speed: 3.33/5.54 / 2.3/4.5km/h
Bucket digging force: 135/158 / 56kN
Arm Digging Force: 103/106 / 38kN
Operating Range
Max digging radius: 6330mm
Max digging depth: 4040mm
Max digging height: 7140mm
Max unloading height: 5095mm
Engine parameters
Max output power: 145 / 112 / 47.4kW
FAQ
What kind of truck is LONGGONG LONGGONG LONGGONG Crawler Excavator excavator?
LONGGONG LONGGONG LONGGONG Crawler Excavator is an export-oriented excavator lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is excavator typically used for?
excavator specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does LONGGONG LONGGONG Crawler Excavator include?
LONGGONG LONGGONG Crawler Excavator currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for LONGGONG LONGGONG Crawler Excavator?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
