Dongfeng H5 Chuangfu Edition 330hp 4X2(6 wheels) Fast Gear 8-speed AMT Automatic 6.8m Refrigerated Truck
EXW
From $28,194
Export quote
Dongfeng H5 Heavy Truck Refrigerated Truck
Main model photos
1,993 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng H5 Chuangfu Edition 330hp 4X2(6 wheels) Fast Gear 8-speed AMT Automatic 6.8m Refrigerated Truck | 4x2 / 330hp / China VI | From $28,194 | |
| Dongfeng H5 Chuangfu Edition 330hp 4X2(6 wheels) Fast Gear 8-speed AMT Automatic 6.8m Refrigerated Truck | 4x2 / 330hp / China VI | From $28,194 | |
| Dongfeng H5 Chuangfu Edition 330hp 4X2(6 wheels) Fast Gear 9-Speed 6.8m Refrigerated Truck | 4x2 / 330hp / China VI | From $26,250 | |
| Dongfeng H5 Chuangfu Edition 330hp 4X2(6 wheels) Fast Gear 9-Speed 6.8m Refrigerated Truck | 4x2 / 330hp / China VI | From $26,250 | |
| Dongfeng H5 Chuangfu Edition 350hp 4X2(6 wheels) Fast Gear 9-Speed AMT Automatic 6.8m Refrigerated Truck | 4x2 / 350hp / China VI | From $28,500 |
Dongfeng H5 Chuangfu Edition 330hp 4X2(6 wheels) Fast Gear 8-speed AMT Automatic 6.8m Refrigerated Truck
EXW
From $28,194
Export quote
Dongfeng H5 Chuangfu Edition 330hp 4X2(6 wheels) Fast Gear 9-Speed 6.8m Refrigerated Truck
EXW
From $26,250
Export quote
Dongfeng H5 Chuangfu Edition 330hp 4X2(6 wheels) Fast Gear 9-Speed 6.8m Refrigerated Truck
EXW
From $26,250
Export quote
Dongfeng H5 Chuangfu Edition 350hp 4X2(6 wheels) Fast Gear 9-Speed AMT Automatic 6.8m Refrigerated Truck
EXW
From $28,500
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Liuqi Chenglong H5 240 hp 4X2(6 wheels) 7.8m Refrigerated Truck (Dongkang) | 4x2 / 240hp / China VI | From $22,903 | |
| Dongfeng Liuqi Chenglong H5 320hp 4X2(6 wheels) 9.6m AMT Automatic Refrigerated Truck | 4x2 / 320hp / China VI | From $32,778 | |
| Dongfeng Liuqi Chenglong H5 heavy truck 290 hp 6X2(8 wheels) 9.6m refrigerated truck | 6x2 / 290hp / China VI | From $39,014 | |
| Dongfeng Liuqi Chenglong H5 350 hp 8X4(12 wheels) 9.4m Refrigerated Truck | 8x4 / 350hp / China V | From $46,125 | |
| DongfengLiuqi Chenglong H5 270hp 6X2(8 wheels) 9.4m Refrigerated Truck | 6x2 / 270hp / China V | From $35,694 |
Dongfeng Liuqi Chenglong H5 240 hp 4X2(6 wheels) 7.8m Refrigerated Truck (Dongkang)
EXW
From $22,903
Export quote
Dongfeng Liuqi Chenglong H5 320hp 4X2(6 wheels) 9.6m AMT Automatic Refrigerated Truck
EXW
From $32,778
Export quote
Dongfeng Liuqi Chenglong H5 heavy truck 290 hp 6X2(8 wheels) 9.6m refrigerated truck
EXW
From $39,014
Export quote
Dongfeng Liuqi Chenglong H5 350 hp 8X4(12 wheels) 9.4m Refrigerated Truck
EXW
From $46,125
Export quote
DongfengLiuqi Chenglong H5 270hp 6X2(8 wheels) 9.4m Refrigerated Truck
EXW
From $35,694
Export quote
Series Specs
Basic Info
Cab dimensions: 9.2×2.6×4 / 10.7×2.6×4 / 12×2.6×4 / 10.3×2.6×4 / 9.2×2.55×4 / 10.2×2.55×4 / 10.2×2.6×4 / 12×2.55×4m
Truck Type: Refrigerated Truck
Drive type: 4X2 / 6X2
Vehicle origin: Liuzhou, Guangxi
Wheelbase: 5100 / 6300 / 7100 / 2050+5350 / 2050+4050 / 5700mm
Front track width: 1916 / 2040/2040mm
rear track: 1800 / 1860mm
Curb Weight: 8.6 / 8.105 / 8.4 / 9.88 / 10.6 / 11.28 / 8.67ton
Rated payload: 9.27 / 9.765 / 9.7 / 9.47 / 7.99 / 14.77 / 13.59 / 9.2ton
GVWR: 18 / 25.5 / 25ton
Max. speed: 89km/h
Front/rear suspension: 1.445/2.655 / 1.445/2.955 / 1.345/2.755 / 1.445/3.455 / 1.525/3.075 / 1.512/2.688 / 1.512/3.088 / 1.525/2.575 / 1.445/3.055 / 1.525/3.375m
Energy Type: Diesel / LNG (liquefied natural gas)
Engine parameters
Engine Model: D7.0NS6B330 / D7.0NS6B350 / D4.5NS6B260 / D4.5NS6B240 / D6.7NNS6B280 / D6.7NS6B320 / B6.2NS6B290 / YCK08320N-60 / YCS07L300-66 / YCS07350-66 / YCS07330-66 / YCS05260-66 / YCS04240-66 / YCA07280N-60
Number of cylinders: 6 / 4cylinder
Displacement: 7 / 4.5 / 6.7 / 6.2 / 7.698 / 6.442 / 6.89 / 4.593 / 4.295 / 6.871L
Emission standard: China VI
Max output power: 243 / 257 / 191 / 176 / 205 / 232 / 213 / 235 / 221 / 255 / 173 / 206kW
Max hp: 330 / 350 / 260 / 240 / 280 / 320 / 290 / 300Horsepower
Max torque: 1200 / 1400 / 850 / 1100 / 1150 / 1300 / 1000N·m
Rated speed: 2300rpm
Engine Type: DOC+DPF+SCR+ASC
Cargo box parameters
Cargo box dimensions: 6.8×2.44×2.65 / 6.8×2.44×2.6 / 8.3×2.44×2.6 / 9.6×2.44×2.6 / 9.7×2.44×2.6 / 7.8×2.45×2.55 / 9.45×2.45×2.55 / 7.8×2.44×2.6m
Cargo box width: 2.44 / 2.45m
Cargo box height: 2.65 / 2.6 / 2.55m
Body Parameters
Vehicle certification code: LZ5180XLCH5AC2 / LZ5180XLCH5AC1 / LZ5182XLCH5AC1 / LZ5180XLCM3AC1 / LZ5180XLCH5AM1 / LZ5180XLCH5AC3 / LZ5261XLCH5CM01 / LZ5251XLCH5CC1 / LZ5181XLCH5AC101
Body Brand: Chenglong brand / Dongfeng
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: ChenglongH5
Chassis Model: LZ1180H5ACT / LZ5180XXYH5ACT / LZ1180M3ACT / LZ5181XXYH5ACT / LZ1180H5AMT / LZ1261H5CMT / LZ1251H5CCT / LZ1181H5AC10T
Front axle description: 3.6T / 4.2T / 2*4.5T / 4.5T
Frame Dimensions: 231(6) / 264(6)mm
rear axle description: 9T / 8T modified / 400 rear axle
Axle ratio: 3.889 / 3.7 / 4.333 / 4.111 / 4.444
Leaf spring count: 8/9+5 / 8/7+6 / 3/4+3 / 3/- / 3/3/- / 3/3/4+3 / 11/12+9
Transmission Parameters
Number of gears: 8 / 9 / 10Gear
Transmission Model: F8JZ130AM / 9JS119TA / F9JZ140A / 10JSD120TB / 8JS85C / 8JSX110TC / F9JZ120A / WLY10AG120 / 8JSX110TM / WLY10AG140 / 8JSQX120TM
Cab parameters
Cab: H57S / H53S / H57S extended cab
fuel tank
Fuel tank capacity: 600 / 280 / 450 / 400L
Tire
Tire Size: 275/80R22.5 18PR / 12R22.5 18PR
FAQ
What kind of truck is Dongfeng Dongfeng H5 Heavy Truck Refrigerated Truck?
Dongfeng Dongfeng H5 Heavy Truck is an export-oriented Refrigerated Truck lineup with about 118 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng H5 Heavy Truck Refrigerated Truck?
Dongfeng H5 Heavy Truck Refrigerated Truck export reference is about $21,028 – $54,167. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng H5 Heavy Truck Refrigerated Truck cover?
Dongfeng H5 Heavy Truck Refrigerated Truck mainly covers: Drive: 4x2 / 6x2 / 8x4; Horsepower: 240 hp / 270 hp / 290 hp / 320 hp / 330 hp / 350 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng H5 Heavy Truck Refrigerated Truck?
For Dongfeng H5 Heavy Truck Refrigerated Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does Dongfeng H5 Heavy Truck Refrigerated Truck include?
Dongfeng H5 Heavy Truck Refrigerated Truck currently lists about 118 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng H5 Heavy Truck Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
