Foton Dajingang 1 150hp 4X2(6 wheels) 3.67m single-row dump truck
EXW
From $15,667
Export quote
Foton Big King 1 Dump Trucks
Main model photos
24 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Dajingang 1 150hp 4X2(6 wheels) 3.67m single-row dump truck | 4x2 / 150hp / China VI | From $15,667 | |
| Foton Big King Kong 1 2021 model 150hp 4X2(6 wheels) 3.67m single-row dump truck | 4x2 / 150hp / China VI | From $16,111 | |
| Foton Dajingang 1 150hp 4X2(6 wheels) 3.67m single-row dump truck | 4x2 / 150hp / China VI | From $15,278 | |
| Foton Big Diamond 1 150 hp 4X2(6 wheels) 2.8m double-row dump truck | 4x2 / 150hp / China VI | From $15,556 | |
| Foton Big King Kong 1 95 hp 4X2(6 wheels) 3m Semi-Cab Dump Truck | 4x2 / 95hp / China V | From $11,431 |
Foton Big King Kong 1 2021 model 150hp 4X2(6 wheels) 3.67m single-row dump truck
EXW
From $16,111
Export quote
Foton Dajingang 1 150hp 4X2(6 wheels) 3.67m single-row dump truck
EXW
From $15,278
Export quote
Foton Big Diamond 1 150 hp 4X2(6 wheels) 2.8m double-row dump truck
EXW
From $15,556
Export quote
Foton Big King Kong 1 95 hp 4X2(6 wheels) 3m Semi-Cab Dump Truck
EXW
From $11,431
Export quote
Series Specs
Basic Info
Model code (announced): BJ3073DEJBA-01 / BJ3043D9JBA-03 / BJ3043D8ABA-03 / BJ3046D9JDA-FE / BJ3046D9JDA-FA
Drive type: 4X2
Wheelbase: 2850 / 3050 / 2800 / 2600mm
Engine Model: Yunnei PowerD25TCIF1 / Yunnei PowerYN27CRE1
Transmission Model: WLYWLY545CHF / WLY5-speed / 5-speed transmission / WLYWLY538ZHF
Rear Axle Ratio: 5.375
Cab length: 5.44 / 5.625 / 4.93 / 5.18 / 4.88m
Cab width: 1.96 / 1.93 / 1695m
Cab height: 2.31 / 2.265 / 2.07 / 2.3m
Front track width: 1495 / 1530mm
rear track: 1500 / 1485 / 1490mm
Curb Weight: 2.94 / 2.72ton
Rated payload: 4.29 / 1.645 / 1.45ton
GVWR: 7.36 / 4.495ton
Origin: Shandong Zhucheng
tonnage class: Light Truck
Approach angle: 25 / 21°
departure angle: 21 / 19 / 20 / 18°
Remarks: Transmission optional 545CHF
Version: 2021 Model
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power
Number of cylinders: 4cylinder
Displacement: 2.5 / 2.672L
Emission standard: China VI / China V
Max output power: 110 / 70kW
Max hp: 150 / 95Horsepower
Max torque: 400 / 250N·m
Max torque speed: 1400-2400 / 1600-2600rpm
Rated speed: 3000 / 3200rpm
Engine Type: Electronic control common rail system HEGR + DOC + DPF + SCR + ASC / 4-cylinder inline, 8-valve, turbocharged intercooled, high-pressure common rail fuel injection
Transmission Parameters
Transmission Brand: WLY
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
hydraulic cylinder brand & model: 80 double lift cylinders
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 3.67 / 2.8 / 3 / 3.3m
Cargo box width: 1.81 / 1.8 / 1.8/1.75m
Cargo box height: 0.4 / 0.45 / 0.6m
FAQ
What kind of truck is Foton Foton Big King 1 Dump Trucks?
Foton Foton Big King 1 is an export-oriented Dump Trucks lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Foton Big King 1 Dump Trucks?
Foton Big King 1 Dump Trucks export reference is about $11,306 – $16,111. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Foton Big King 1 Dump Trucks cover?
Foton Big King 1 Dump Trucks mainly covers: Drive: 4x2; Horsepower: 95 hp / 150 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton Big King 1 Dump Trucks?
For Foton Big King 1 Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Foton Big King 1 Dump Trucks include?
Foton Big King 1 Dump Trucks currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton Big King 1 Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
