FAW Jiefang Qingdao JK6 6.4L Diesel 300hp 6X2(8 wheels) Fast Gear 12-Speed 5.2m Dump Truck
EXW
From $41,667
Export quote
FAW Jiefang QingdaoJK6 Dump Trucks
Main model photos
674 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Qingdao JK6 6.4L Diesel 300hp 6X2(8 wheels) Fast Gear 12-Speed 5.2m Dump Truck | 6x2 / 300hp / China VI | From $41,667 | |
| FAW Jiefang Qingdao JK6 300 hp 4X2(6 wheels) 5.5m dump truck | 4x2 / 300hp / China VI | From $50,000 | |
| FAW Jiefang Qingdao JK6 300 hp 4X2(6 wheels) 5.3m dump truck | 4x2 / 300hp / China VI | From $49,306 | |
| FAW Jiefang Qingdao JK6 300hp 4X2(6 wheels) 5.2m dump truck | 4x2 / 300hp / China VI | From $48,611 | |
| FAW Jiefang Qingdao JK6 300hp 4X2(6 wheels) 5m dump truck | 4x2 / 300hp / China VI | From $47,222 |
FAW Jiefang Qingdao JK6 300 hp 4X2(6 wheels) 5.5m dump truck
EXW
From $50,000
Export quote
FAW Jiefang Qingdao JK6 300 hp 4X2(6 wheels) 5.3m dump truck
EXW
From $49,306
Export quote
FAW Jiefang Qingdao JK6 300hp 4X2(6 wheels) 5.2m dump truck
EXW
From $48,611
Export quote
FAW Jiefang Qingdao JK6 300hp 4X2(6 wheels) 5m dump truck
EXW
From $47,222
Export quote
Series Specs
Basic Info
Model code (announced): CA3250P28K8L1T2E6A90 / CA3181P28K8L3E6A90 / CA3312P28K15L2T4E6A80 / CA3310P28K15L2T4E6A80 / CA3311P28K2L4T4E6A80 / CA3311P28K15L4T4E6A80 / CA3312P28K15L1T4E6A80
Drive type: 6X2 / 4X2 / 8X4
Wheelbase: 2900+1300 / 4500 / 4200 / 4000 / 1900+2500+1350 / 1900+2700+1350 / 1900+3200+1350mm
Engine Model: YuchaiYCS06300-61 / WeichaiWP8.350E62 / WeichaiWP7H320E62 / DachaiCA6DK2C35E65 / XichaiCA6DK2C35E65 / YCS06300-61
Transmission Model: Fast Gear12JSD160T / Fast Gear12JSD160 / Fast Gear12JSD160TA / FAW Jiefang 10-speed / Fast Gear10JSD140TB / Fast Gear10JSD140T / 12JSD160T
Rear Axle Ratio: 5.263 / 5.921 / 5.143 / 4.769
Cab length: 7.6 / 7.98 / 7.88 / 7.68 / 7.38 / 7.48 / 8.56 / 9.01 / 9.36m
Cab width: 2.55 / 2300m
Cab height: 3.3m
Front track width: 1950 / 1951/1951mm
rear track: 1878 / 1878/1878mm
Curb Weight: 10.995 / 8.3 / 12.8 / 11 / 12.1ton
Rated payload: 13.875 / 9.57 / 18.07 / 19.87 / 18.77ton
GVWR: 25 / 18 / 31ton
Origin: Qingdao
tonnage class: Heavy truck
Approach angle: 20°
departure angle: 18 / 35°
Version: Highway Lightweight Version / Highway standard edition / Standard version / Lightweight version
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai / Weichai / Dachai / Xichai
Number of cylinders: 6cylinder
Displacement: 6.442 / 7.8 / 6.8 / 7.751L
Emission standard: China VI
Max output power: 221 / 257 / 220kW
Max hp: 300 / 350 / 320Horsepower
Max torque: 1200 / 1400 / 1300N·m
Max torque speed: 1200-1600 / 1300-1700rpm
Rated speed: 2100rpm
Engine Type: High-pressure common rail + DOC + DPF + SCR
Transmission Parameters
Transmission Brand: Fast Gear / FAW Jiefang
shift method: Manual
Forward gears: 12 / 10Gear
Number of Reverse Gears: 2pcs
Housing Material: aluminum housing
Cargo box parameters
Unloading Type: Dump type
Cargo box type: square box / U-shaped box / Dump type
Cargo box length: 5.2 / 5.5 / 5.3 / 5 / 4.7 / 4.8 / 5.6 / 6.2 / 6.5m
Cargo box width: 2.4 / 2.35m
Body Parameters
Lifting type: Front lift
FAQ
What kind of truck is FAW Jiefang Qingdao FAW Jiefang QingdaoJK6 Dump Trucks?
FAW Jiefang Qingdao FAW Jiefang QingdaoJK6 is an export-oriented Dump Trucks lineup with about 12 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Jiefang QingdaoJK6 Dump Trucks?
FAW Jiefang QingdaoJK6 Dump Trucks export reference is about $41,667 – $55,556. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Jiefang QingdaoJK6 Dump Trucks cover?
FAW Jiefang QingdaoJK6 Dump Trucks mainly covers: Drive: 4x2 / 6x2; Horsepower: 300 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Jiefang QingdaoJK6 Dump Trucks?
For FAW Jiefang QingdaoJK6 Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FAW Jiefang QingdaoJK6 Dump Trucks include?
FAW Jiefang QingdaoJK6 Dump Trucks currently lists about 12 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Jiefang QingdaoJK6 Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
