Foton ISGe5-350 350 hp 12L China V Diesel Engine
EXW
Export quote
Foton ISG12 Series engine
Main model photos
20 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton ISGe5-350 350 hp 12L China V Diesel Engine | 350hp / China V | ||
| Foton ISGe5-510 510 hp 12L China V diesel engine | 510hp / China V | ||
| Foton ISGe5-490 490 hp 12L China V Diesel Engine | 490hp / China V | ||
| Foton ISGe5-460 460hp 12L China V Diesel Engine | 460hp / China V | ||
| Foton ISGe5-400 400 hp 12L China V Diesel Engine | 400hp / China V |
Foton ISGe5-510 510 hp 12L China V diesel engine
EXW
Export quote
Foton ISGe5-490 490 hp 12L China V Diesel Engine
EXW
Export quote
Foton ISGe5-460 460hp 12L China V Diesel Engine
EXW
Export quote
Foton ISGe5-400 400 hp 12L China V Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: ISG12 Series
Engine manufacturer: Foton Engine Co., Ltd., Beijing
Engine net weight: 792 / 831kg
Engine Dimensions: 1460X895X1050mm
Bore × Stroke: 132X144mm
firing order: 1-5-3-6-2-4
Engine Brand: Foton
Engine Model: ISGe5-350 / ISGe5-510 / ISGe5-490 / ISGe5-460 / ISGe5-400 / ISGe5-360 / ISGe5-380 / ISGe5-430 / ISGe4 490 / ISGe4 460 / ISGe4 430 / ISGe4 400 / ISGe4 380 / ISG12
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 11.8L
Emission standard: China V / China IV
Max output power: 257 / 375 / 360 / 331 / 294 / 265 / 279 / 316 / 382kW
Max hp: 350 / 510 / 490 / 460 / 400 / 360 / 380 / 430 / 512Horsepower
Max torque: 1800 / 2300 / 2100 / 1900 / 2000 / 2200 / 2035N·m
Max torque speed: 1000 / 1100-1400 / 1100-1300 / 1000-1300 / 1000-1400 / 1100rpm
Rated speed: 1900rpm
Engine Type: Inline, water-cooled, six-cylinder, air-to-air intercooled / Common Rail SCR / Cummins XPI Ultra-High Pressure Fuel System
FAQ
What kind of truck is Foton Foton ISG12 Series engine?
Foton Foton ISG12 Series is an export-oriented engine lineup with about 14 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Foton ISG12 Series engine cover?
Foton ISG12 Series engine mainly covers: Horsepower: 350 hp / 400 hp / 460 hp / 490 hp / 510 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton ISG12 Series engine?
For Foton ISG12 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Foton ISG12 Series engine include?
Foton ISG12 Series engine currently lists about 14 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton ISG12 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
