NanJun New Hongyun 140hp 4X2(6 wheels) 4.3m dump truck
EXW
From $23,611
Export quote
NanJun New Hongyun Light Truck Dump Trucks
Main model photos
9 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| NanJun New Hongyun 140hp 4X2(6 wheels) 4.3m dump truck | 4x2 / 140hp / China V | From $23,611 | |
| NanJun New Hongyun 160hp 4X2(6 wheels) 4.3m dump truck | 4x2 / 160hp / China V | From $23,611 | |
| NanJun New Hongyun 160hp 4X2(6 wheels) 4.5m dump truck | 4x2 / 160hp / China V | From $23,611 | |
| NanJun New Hongyun 140hp 4X2(6 wheels) 4.1m dump truck | 4x2 / 140hp / China V | From $23,611 | |
| NanJun New Hongyun 160 hp 4X2(6 wheels) 4.4m dump truck | 4x2 / 160hp / China IV | From $22,222 |
NanJun New Hongyun 160hp 4X2(6 wheels) 4.3m dump truck
EXW
From $23,611
Export quote
NanJun New Hongyun 160hp 4X2(6 wheels) 4.5m dump truck
EXW
From $23,611
Export quote
NanJun New Hongyun 140hp 4X2(6 wheels) 4.1m dump truck
EXW
From $23,611
Export quote
NanJun New Hongyun 160 hp 4X2(6 wheels) 4.4m dump truck
EXW
From $22,222
Export quote
Series Specs
Basic Info
Model code (announced): CNJ3060GPA37V / CNJ3120ZGP38M / CNJ3140GPA34M
Drive type: 4X2
Wheelbase: 3700 / 3850 / 3400mm
Engine Model: YuchaiYC4E140-56A / YuchaiYC4E160-45 / YuchaiYC4D130-41 / YuchaiYC4E140-42 / YuchaiYC4E160-56
Transmission Model: WLYWLY6HQ-53DY2KQ / WLY6HQ-53DY3KQ / WLYWLY6-53 / Fast Gear 8-speed
Rear Axle Ratio: 6.833 / 6.41 / 6.83
Cab length: 6.7 / 6.9 / 6.5 / 6.75 / 6.45 / 6.99m
Cab width: 2.3 / 2.4 / 2.46 / 2.38m
Cab height: 2.74 / 2.9 / 2.75m
Front track width: 1780 / 1900 / 1750mm
rear track: 1750 / 1860 / 1700mm
Curb Weight: 3.365 / 6.7 / 6.55ton
Rated payload: 1.995 / 4.99 / 6.99ton
GVWR: 5.555 / 11.885 / 13.735ton
Origin: Ziyang, Sichuan
tonnage class: Light Truck
Approach angle: 28 / 35°
departure angle: 24 / 18°
Remarks: Max speed: 80 km/h
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Number of cylinders: 4cylinder
Displacement: 4.26 / 4.214L
Emission standard: China V / China IV
Max output power: 103 / 118 / 96kW
Max hp: 140 / 160 / 130Horsepower
Max torque: 450 / 600 / 550 / 420 / 430N·m
Max torque speed: 1300-1600 / 1400-1800rpm
Rated speed: 2600 / 2800rpm
Engine Type: Vertical, inline, water-cooled, four-stroke / Vertical, inline 4-cylinder, water-cooled, 4-stroke, electronic direct injection / Electronic unit pump SCR
Transmission Parameters
Transmission Brand: WLY / Fast Gear
Forward gears: 6 / 8Gear
Number of Reverse Gears: 1 / 2pcs
Cargo box parameters
Unloading Type: Dump type / Rear-dump body
Cargo box length: 4.3 / 4.5 / 4.1 / 4.4 / 3.95 / 4.7m
Cargo box width: 2.2 / 2.3 / 2.1m
Cargo box height: 0.8m
fuel tank
Fuel tank capacity: 164L
Chassis Specs
Front axle allowable load: 2110 / 4460 / 4940kg
rear axle description: 457 rear axle / 153N3
FAQ
What kind of truck is NanJun NanJun New Hongyun Light Truck Dump Trucks?
NanJun NanJun New Hongyun Light Truck is an export-oriented Dump Trucks lineup with about 7 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for NanJun New Hongyun Light Truck Dump Trucks?
NanJun New Hongyun Light Truck Dump Trucks export reference is about $17,083 – $23,611. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does NanJun New Hongyun Light Truck Dump Trucks cover?
NanJun New Hongyun Light Truck Dump Trucks mainly covers: Drive: 4x2; Horsepower: 140 hp / 160 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in NanJun New Hongyun Light Truck Dump Trucks?
For NanJun New Hongyun Light Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does NanJun New Hongyun Light Truck Dump Trucks include?
NanJun New Hongyun Light Truck Dump Trucks currently lists about 7 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for NanJun New Hongyun Light Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
