JAC Gallop A5W III Heavy Truck 400hp 8X4(12 wheels) 6.8m Dump Truck
EXW
From $56,319
Export quote
JAC Gallop A5 Heavy Truck Dump Trucks
Main model photos
1,408 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Gallop A5W III Heavy Truck 400hp 8X4(12 wheels) 6.8m Dump Truck | 8x4 / 400hp / China VI | From $56,319 | |
| JAC Gallop A5W III Heavy Truck 400hp 8X4(12 wheels) 6.5m Dump Truck | 8x4 / 400hp / China VI | From $56,319 | |
| JAC Gallop A5W III Heavy Truck 375hp 8X4(12 wheels) 6.8m Dump Truck | 8x4 / 375hp / China VI | From $55,903 | |
| JAC Gallop A5W III Heavy Truck 375hp 8X4(12 wheels) 6.5m Dump Truck | 8x4 / 375hp / China VI | From $55,903 | |
| JAC Gallop A5LⅢ 200hp 4X2(6 wheels) 5m Dump Truck (459 Rear Axle) | 4x2 / 180hp / China VI | From $27,431 |
JAC Gallop A5W III Heavy Truck 400hp 8X4(12 wheels) 6.5m Dump Truck
EXW
From $56,319
Export quote
JAC Gallop A5W III Heavy Truck 375hp 8X4(12 wheels) 6.8m Dump Truck
EXW
From $55,903
Export quote
JAC Gallop A5W III Heavy Truck 375hp 8X4(12 wheels) 6.5m Dump Truck
EXW
From $55,903
Export quote
JAC Gallop A5LⅢ 200hp 4X2(6 wheels) 5m Dump Truck (459 Rear Axle)
EXW
From $27,431
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Gallop A5L Value Edition 270 hp 6X4(10 wheels) 4.8m Dump Truck (China VI) | 6x4 / 270hp / China VI | ||
| JAC Gallop A5L III 290hp 8X4(12 wheels) 6m Dump Truck | 8x4 / 290hp / China V | From $37,222 | |
| JAC Gallop A5 260 hp 8X2(10 wheels) 6.8m Dump Truck | 8x2 / 260hp / China V | From $36,111 | |
| JAC Gallop A5L III 220 hp 6X2(8 wheels) 5.6m Dump Truck | 6x2 / 220hp / China V | From $26,917 | |
| JAC Gallop A5L III 220 hp 6X2(8 wheels) 5m Dump Truck | 6x2 / 220hp / China V | From $27,444 |
JAC Gallop A5L Value Edition 270 hp 6X4(10 wheels) 4.8m Dump Truck (China VI)
EXW
Export quote
JAC Gallop A5L III 290hp 8X4(12 wheels) 6m Dump Truck
EXW
From $37,222
Export quote
JAC Gallop A5 260 hp 8X2(10 wheels) 6.8m Dump Truck
EXW
From $36,111
Export quote
JAC Gallop A5L III 220 hp 6X2(8 wheels) 5.6m Dump Truck
EXW
From $26,917
Export quote
JAC Gallop A5L III 220 hp 6X2(8 wheels) 5m Dump Truck
EXW
From $27,444
Export quote
Series Specs
Basic Info
Model code (announced): HFC3311P1K6H25WS / HFC3181P3K3A35S / HFC3311P3K4H23S / HFC3311P3K3H23S / HFC3251P3K3E32S / HFC3251P3K3D43S / HFC3241P3K3D25S / HFC3311P3K3G24S
Drive type: 8X4 / 4X2 / 6X4 / 6X2 / 8X2
Wheelbase: 2100+2900+1350 / 3900 / 1950+2300+1350 / 1950+3300+1350 / 3600+1350 / 3200+1350 / 1950+4800 / 1950+4300 / 1950+2500 / 1950+2700+1350 / 1950+3500+1300 / 1950+2450+1300mm
Engine Model: WeichaiWP10H400E62 / WeichaiWP10H375E62 / YuchaiYCS04180-68 / YuchaiYCS06290-61 / YuchaiYCS06270-60 / YuchaiYCS06245-60 / YuchaiYCK05240-60 / YuchaiYCS06270-60A / YuchaiYCK05260-61
Transmission Model: Fast Gear12JSD200 / Fast Gear8JS85F-C / Fast Gear10JSD120B / Fast Gear10JS90A-B / SinotrukHW95510C / Fast Gear12JSD200+QH70 / Fast Gear8JS85F-C+QD40L / Fast Gear10JSD120B+QH50 / Fast Gear10JS90A-B+QD40E
Rear Axle Ratio: 6.166
Cab length: 9.645 / 9.445 / 7.355 / 7.255 / 7.155 / 7.055 / 6.955 / 8.475 / 8.275 / 10.305 / 10.175 / 7.375 / 7.275 / 10.575 / 10.375 / 9.975 / 9.575 / 9.275 / 7.575 / 7.475 / 10.075 / 9.875 / 9.845 / 10.125 / 9.925 / 9.725 / 9.325 / 9.025 / 8.525m
Cab width: 2.55 / 2.42 / 2.4 / 2.5 / 2295m
Cab height: 3.25 / 2.95 / 3.18 / 2.98m
Front track width: 2040/2040 / 1840 / 2020/2020 / 2020 / 1940/1940mm
rear track: 1860/1860 / 1800 / 1780/1780 / 1860 / 1890/1860mm
Curb Weight: 15.45 / 7.875 / 10.5 / 13.99 / 11.5 / 11.85 / 10.8 / 9.8 / 9.6ton
Rated payload: 15.42 / 9.995 / 20.305 / 16.815 / 13.37 / 14.37 / 12.955 / 14.005 / 14.505 / 14.07 / 21.27ton
GVWR: 31 / 18 / 25 / 24.5ton
Origin: Hefei, Anhui
tonnage class: Heavy truck / Medium-duty truck
Approach angle: 16 / 15 / 17°
departure angle: 15 / 20 / 18°
Remarks: Optional: Side-tipping dump / Standard: Economy switch, engine protection cover, 4G-Tbox
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai / Yuchai
Number of cylinders: 6 / 4cylinder
Displacement: 9.5 / 4.16 / 6.442 / 6.23 / 5.13 / 6.2L
Emission standard: China VI
Max output power: 294 / 276 / 132 / 213 / 199 / 180 / 176 / 191kW
Max hp: 400 / 375 / 180 / 290 / 270 / 245 / 240 / 260Horsepower
Max torque: 1900 / 1800 / 650 / 1050 / 850 / 900N·m
Max torque speed: 1200-1300 / 1000-1400 / 1200-1900 / 1200-1700 / 1200-1600rpm
Rated speed: 1900 / 2300 / 2200rpm
Engine Type: Inline, direct injection, water-cooled, 4-stroke, turbocharged, intercooled, electronically controlled high-pressure common rail, Hi+SCR / CR+DOC+DPF+Hi_SCR / High-pressure common rail + EGR + DOC + DPF + SCR + ASC
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 10 / 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type / Rear-dump body / Side-dump tipper.
Cargo box length: 6.8 / 6.5 / 5 / 4.8 / 4.7 / 4.5 / 4.2 / 6 / 5.8 / 7.6 / 7.4 / 5.4 / 4.6 / 7.8 / 7.2m
Cargo box width: 2.35 / 2.3 / 2.25m
Cargo box height: 1 / 0.8 / 1.2m
Cab parameters
Cab: A5W III Mid-High Roof with Raised Floor / A5LⅢ Flat Roof / A5L III Semi-High Roof / Sleeper cab
Cab tilting: Electric
FAQ
What kind of truck is JAC Gallop JAC Gallop A5 Heavy Truck Dump Trucks?
JAC Gallop JAC Gallop A5 Heavy Truck is an export-oriented Dump Trucks lineup with about 306 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JAC Gallop A5 Heavy Truck Dump Trucks?
JAC Gallop A5 Heavy Truck Dump Trucks export reference is about $20,722 – $66,667. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JAC Gallop A5 Heavy Truck Dump Trucks cover?
JAC Gallop A5 Heavy Truck Dump Trucks mainly covers: Drive: 4x2 / 6x2 / 6x4 / 8x2 / 8x4; Horsepower: 180 hp / 220 hp / 260 hp / 270 hp / 290 hp / 375 hp / 400 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JAC Gallop A5 Heavy Truck Dump Trucks?
For JAC Gallop A5 Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does JAC Gallop A5 Heavy Truck Dump Trucks include?
JAC Gallop A5 Heavy Truck Dump Trucks currently lists about 306 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JAC Gallop A5 Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
