Dongfeng YuLong 270 hp 6X4(10 wheels) Truck-mounted Crane Transport Truck (DFZ5258JSQSZ5D)
EXW
From $34,444
Export quote
Dongfeng Yulong truck-mounted crane
Main model photos
101 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng YuLong 270 hp 6X4(10 wheels) Truck-mounted Crane Transport Truck (DFZ5258JSQSZ5D) | 6x4 / 270hp / China V | From $34,444 | |
| Dongfeng Yu Long 180 hp 4X2(6 wheels) 5.8m truck-mounted crane (EQ5161JSQZMB) | 4x2 / 180hp / China V | From $38,611 | |
| Dongfeng Yulong 270hp 6X4(10 wheels) 8.3m truck-mounted crane (EQ5250JSQL1) | 6x4 / 270hp / China V | From $45,139 | |
| Dongfeng Yulong 240hp 6X4(10 wheels) 8.3m truck-mounted crane (EQ5250JSQL1) | 6x4 / 240hp / China V | From $42,917 | |
| Dongfeng Yulong 240hp 6X4(10 wheels) 6.65m truck-mounted crane (EQ5250JSQL1) | 6x4 / 240hp / China V | From $36,458 |
Dongfeng Yu Long 180 hp 4X2(6 wheels) 5.8m truck-mounted crane (EQ5161JSQZMB)
EXW
From $38,611
Export quote
Dongfeng Yulong 270hp 6X4(10 wheels) 8.3m truck-mounted crane (EQ5250JSQL1)
EXW
From $45,139
Export quote
Dongfeng Yulong 240hp 6X4(10 wheels) 8.3m truck-mounted crane (EQ5250JSQL1)
EXW
From $42,917
Export quote
Dongfeng Yulong 240hp 6X4(10 wheels) 6.65m truck-mounted crane (EQ5250JSQL1)
EXW
From $36,458
Export quote
Series Specs
Basic Info
Cab dimensions: 12×2.5×3.98 / 9.0×2.5×3.85 / 11.95×2.49×3.85 / 10.6×2.49×3.85 / 12×2.49×3.85 / 12.0×2.49×3.85 / 10.05×2.49×3.85 / 8.5×2.55×3.65 / 11.95×2.55×3.65 / 10.65×2.55×3.65 / 7.35×2.5×3.85 / 1.005×2.49×3.85m
Type: Truck with crane / truck-mounted crane
Drive type: 6X4 / 4X2
Wheelbase: 5900+1300 / 5100 / 5850+1350 / 4350+1300mm
Rated mass: 8.605 / 4.225 / 9.935 / 8.62 / 9.835 / 8.575 / 9.995 / 8.515 / 6.595ton
GVWR: 25 / 16ton
Front/rear suspension: 1.45/3.3 / 1.25/2.65 / 1.25/3.3 / 1.25/3.15 / 1.25/2.15 / 1.25/3.2m
Energy Type: Diesel
Body Parameters
Crane model: SQS250,QYS-10,ZLC2500T,URV100,KS2304,DFSQ25000,SQ1004 / SPS15800,SQ114,QYS-6.3III,SQS-6.3III,URV630,nicoleV630 / QYS-10III,SQS-10III,URV1004,SPS25000,KS2305,nicoleV1004 / QYS-10,SQS250,URV1004,SPS25000,KS2305,nicoleV1004 / SQS10SK3Q
Lifting capacity: 12 / 4.5 / 6 / 10 / 14ton
crane self-weight: 4.2 / 2.102 / 4 / 4.95 / 4.3 / 5.322ton
Vehicle certification code: DFZ5258JSQSZ5D / EQ5161JSQZMB / EQ5250JSQL1 / EQ5250JSQL / EQ5250JSQL3 / EQ5168JSQZM / EQ5251JSQZM1
Body Brand: Dongfeng
Engine parameters
Injection System: Common Rail
Engine Brand: Yuchai / Dongfeng
Engine Model: YuchaiYC6A270-50 / YuchaiYC6JA180-50 / YuchaiYC6A240-50 / YuchaiYC6JA240-50 / DongfengISB180 40 / YuchaiYC6A260-46
Displacement: 7.52 / 6.87 / 5.9 / 7.255L
Emission standard: China V / China IV
Max output power: 199 / 132 / 177 / 191kW
Max hp: 270 / 180 / 240 / 260Horsepower
Max torque: 1100 / 700 / 1000 / 950 / 630N·m
Max torque speed: 1200-1800 / 1500 / 1300-1600rpm
Rated speed: 2300 / 2500rpm
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Yulong
Chassis Model: EQ1258GSZ5DJ / EQ1250GLJ / EQ1168GLJ3 / EQ1251GLJ10
Frame Dimensions: 300mm
rear axle description: 10T / 153
Axle ratio: 5.14 / 6.17
Leaf spring count: 9/10,9/13,3/-,8/- / 9/11+8,8/10+8,8/11+8,9/10+8,3/4+3 / 9/10,9/13 / 9/13
Transmission Parameters
Number of gears: 10 / 8 / 9Gear
Transmission Model: Fast Gear10JSD120A / Fast Gear 8-speed / Fast Gear 9-speed / Fast Gear8JS85E / Fast Gear9JS119A
Cab parameters
Cab: DongfengT702 / DongfengD702
Tire
Tire Size: 11.00R20 / 10.00R20 16PR / 11.00-20 18PR,11.00R20 18PR / 10.00R20
Number of tires: 10 / 6pcs
FAQ
What kind of truck is Dongfeng Dongfeng Yulong truck-mounted crane?
Dongfeng Dongfeng Yulong is an export-oriented truck-mounted crane lineup with about 13 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng Yulong truck-mounted crane?
Dongfeng Yulong truck-mounted crane export reference is about $34,444 – $56,667. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng Yulong truck-mounted crane cover?
Dongfeng Yulong truck-mounted crane mainly covers: Drive: 4x2 / 6x4; Horsepower: 180 hp / 240 hp / 270 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng Yulong truck-mounted crane?
For Dongfeng Yulong truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng Yulong truck-mounted crane include?
Dongfeng Yulong truck-mounted crane currently lists about 13 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng Yulong truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
