Chaochai CY4102-CE4B 136 hp 3.86L China IV Diesel Engine
EXW
Export quote
Chaochai 4102 series engine
Main model photos
26 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Chaochai CY4102-CE4B 136 hp 3.86L China IV Diesel Engine | 136hp / China IV | ||
| Chaochai CY4102-CE4N 143 hp 3.86L China IV Diesel Engine | 143hp / China IV | ||
| Chaochai CY4102-CE4M 156 hp 3.86L China IV Diesel Engine | 156hp / China IV | ||
| Chaochai CY4102-CE4A 170 hp 3.86L China IV Diesel Engine | 170hp / China IV | ||
| ChaochaiCY4102-CE4K 143hp 3.86L China IV Diesel Engine | 143hp / China IV |
Chaochai CY4102-CE4N 143 hp 3.86L China IV Diesel Engine
EXW
Export quote
Chaochai CY4102-CE4M 156 hp 3.86L China IV Diesel Engine
EXW
Export quote
Chaochai CY4102-CE4A 170 hp 3.86L China IV Diesel Engine
EXW
Export quote
ChaochaiCY4102-CE4K 143hp 3.86L China IV Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: 4102 Series / ChaochaiCY4SK
Engine manufacturer: Dongfeng Chaoyang Chaochai Power Co., Ltd.
Suitable Range: 4-6T cargo truck, 7-9m bus, city bus, and construction truck / 3-6 ton cargo truck, 7-9m bus, city bus, and construction vehicle / It is an ideal power source for economy cargo trucks, minibuses, construction machinery, and generator sets. / For 3-8 ton light and medium trucks, 6-9 m buses, etc. / For 3-8 ton light and medium trucks, 6-9 m buses / This product is widely applicable to 2-3 ton cargo trucks, various midibuses, city buses, and luxury tour buses. / CY4102BG / This series diesel engine is widely used in 2-3 ton cargo trucks, medium buses, and city buses. / This product is suitable for various 2-3 ton cargo trucks, 6-7 meter luxury bus chassis, and other cargo trucks and city buses from Dongfeng, JAC, and Nanjing Auto. / This series diesel engine is widely used in 2-3 ton cargo trucks, passenger cars, tour buses, and city buses.
Intake type: Turbocharged Air-to-Air Intercooling / Naturally aspirated / Turbocharged
Min. fuel consumption at full load: ≤200 / ≤198 / ≤205 / 210 / 205 / 330 / 209.4 / 209 / 216g/kW.h
Engine net weight: 430 / 350 / 340 / 221 / 330kg
Engine Dimensions: 910x680x820 / 869×782×816 / 814×464×818 / 963.1×693×820.8 / 820×651×751 / 921×651×751 / 810×660×813mm
noise at 1m: 114 / ≤116 / ≤89dB
Compression ratio: 17：1 / 17:1 / 17.5:1 / 16.5:1
Bore × Stroke: 102x118 / 105x118mm
Valves per cylinder: 4 / 2pcs
firing order: 1-3-4-2 / 1－3－4－2
Engine Brand: Chaochai
Engine Model: CY4102-CE4B / CY4102-CE4N / CY4102-CE4M / CY4102-CE4A / CY4102-CE4K / CY4102-CE4F / CY4102-CE4D / CY4102-CE4C / CY4102-E3F / CY4102-E3C / CY4102-C3D / CY4102-D3C / CY4102-CS5B / 4102-C3F / 4102-C3E / CY4102-C3A / CY4102-C3B / CY4102-C3C / CY4102BZLQ Turbocharged Intercooled / CY4102-C3G / CY4102BG / CY4105Q / CY4102BZQ / CY4102BQ
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 3.856 / 4.087L
Emission standard: China IV / China III / Euro III / China V / China II/Euro II
Max output power: 100 / 105 / 115 / 125 / 73 / 83 / 91 / 88 / 80 / 70 / 103 / 75 / 63 / 55 / 74 / 70.6kW
Max hp: 136 / 143 / 156 / 170 / 99 / 113 / 124 / 100 / 120 / 109 / 95 / 140 / 102 / 86 / 75 / 96Horsepower
Max torque: 420 / 500 / 600 / 235 / 300 / 345 / 425 / 392 / 245 / 265 / 324N·m
Max torque speed: 1300-1500 / 1400-1800 / 1800 / 1500 / 1200-2200 / 1600 / 2000 / 2200rpm
Rated speed: 2800 / 2600 / 3200 / 3000 / 2400rpm
Engine Type: Vertical in-line, water-cooled, 4-stroke, turbocharged & intercooled, electronic high-pressure common rail / Vertical in-line, 4-stroke, turbocharged & intercooled, electronic high-pressure common rail / Vertical inline, water-cooled, 4-stroke, turbocharged intercooled / Vertical inline, water-cooled, 4-stroke / Vertical water-cooled, four-stroke, turbocharged intercooled, electronic control high-pressure common rail / Water-cooled, 4-stroke, turbocharged intercooled / Vertical inline, water-cooled, 4-stroke, naturally aspirated / Vertical inline, water-cooled, 4-stroke, turbocharged
FAQ
What kind of truck is Chaochai Chaochai 4102 series engine?
Chaochai Chaochai 4102 series is an export-oriented engine lineup with about 24 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Chaochai 4102 series engine cover?
Chaochai 4102 series engine mainly covers: Horsepower: 136 hp / 143 hp / 156 hp / 170 hp; Emission: China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chaochai 4102 series engine?
For Chaochai 4102 series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Chaochai 4102 series engine include?
Chaochai 4102 series engine currently lists about 24 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chaochai 4102 series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
