Hongyan Teba 336 hp 8X4(12 wheels) 9.9m Dump Truck
EXW
From $45,639
Export quote
SAIC Hongyan Tuba Heavy Truck Dump Trucks
Main model photos
21 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Hongyan Teba 336 hp 8X4(12 wheels) 9.9m Dump Truck | 8x4 / 336hp / China III / Euro III | From $45,639 | |
| Hongyan Teba 310 hp 8X4(12 wheels) 8m Dump Truck | 8x4 / 310hp / China III / Euro III | From $43,972 | |
| Hongyan Teba 290 hp 8X4(12 wheels) 6.7m Dump Truck | 8x4 / 290hp / China III / Euro III | From $44,278 | |
| Hongyan Teba 375 hp 8X4(12 wheels) Dump Truck | 8x4 / 375hp / China III / Euro III | From $47,208 | |
| Hongyan Teba 336 hp 8X4(12 wheels) 6.2m Dump Truck | 8x4 / 336hp / China III / Euro III | From $43,972 |
Hongyan Teba 310 hp 8X4(12 wheels) 8m Dump Truck
EXW
From $43,972
Export quote
Hongyan Teba 290 hp 8X4(12 wheels) 6.7m Dump Truck
EXW
From $44,278
Export quote
Hongyan Teba 375 hp 8X4(12 wheels) Dump Truck
EXW
From $47,208
Export quote
Hongyan Teba 336 hp 8X4(12 wheels) 6.2m Dump Truck
EXW
From $43,972
Export quote
Series Specs
Basic Info
Model code (announced): CQ3314STG336 / CQ3314SMG396 / CQ3314SMG306 / CQ3314STHG466 / CQ3314SRHG276 / CQ3314SRHG306 / CQ3254SRG294 / CQ3254SMG364 / CQ3254SMG324 / CQ3254STHG494 / CQ3254STHG364 / CQ3254SMHG414 / CQ3314STG426 / CQ3254STG384 / CQ3254SMG384
Drive type: 8X4 / 6X4
Wheelbase: 1800+3300+1350 / 1800+3900+1350 / 1800+3000+1350 / 1800+4600+1350 / 1800+2700+1350 / 2925+1350 / 3600+1350 / 3225+1350 / 4975+1350 / 4125+1350 / 1800+4200+1350 / 3825+1350mm
Engine Model: WeichaiWP10.336 / WeichaiWP10.310E32 / WeichaiWP10.290 / SinotrukWD615.96E / SinotrukWD615.95E / SinotrukWD615.93E / WeichaiWP10.270 / WeichaiWP10.340E32 / WeichaiWP10.290E32 / SinotrukWD615.92E
Transmission Model: Fast Gear12JS160T / Fast Gear9JS135 / Fast Gear9JS119 / Fast GearRT-11509C
Rear Axle Ratio: 4.8 / 5.73
Cab length: 9.92 / 10.81 / 9.55 / 11.96 / 9.07 / 9.45 / 7.34 / 8.19 / 7.62 / 10.085 / 9.135 / 10.91 / 8.55 / 8.45 / 8.4m
Cab width: 2.5m
Cab height: 3.35 / 3.51 / 3.6m
Front track width: 2006/2006 / 2006mm
rear track: 1850/1850 / 1850mm
Curb Weight: 15.05 / 15.27 / 15 / 15.45 / 14.87 / 12 / 12.12 / 12.06 / 12.5 / 12.01 / 12.25 / 15.37 / 25 / 12.17ton
Rated payload: 15.82 / 15.6 / 15.87 / 15.42 / 16 / 12.87 / 12.75 / 12.8 / 12.37 / 12.86 / 12.62 / 15.5 / 12.7ton
GVWR: 31 / 25ton
Origin: Chongqing
tonnage class: Heavy truck
Approach angle: 25 / 23°
departure angle: 16 / 17 / 12 / 20 / 19 / 15 / 18°
Remarks: .Optional covered cargo box, cover mass 250 kg; with cover curb weight 12260 kg, without cover curb weight 12010 kg; 2. Optional front mask; 3. Optional mining dump body. / 1. Without optional covered cargo box, cargo box dimensions: 4800×2300×1389 (mm), 5000×2300×1300 (mm), 5200×2300×1290 (mm); with optional covered cargo box, cover weight per cargo box length: 200, 220, 240 kg; after covering, cargo box dimensions: 4800×2300×1300 (mm), 5000×2300×1300 (mm), 5200×2300×1250 (mm); 2. Optional front grille; 3. Optional mining dump body. Dump body unloading method: rear dump. / 1. Optional front mask; 2. This model can also be used without a trailer / 1. Optional covered cargo body, cover weight corresponding to body length: 270, 290, 310 kg; with cover: body length 5600mm,5800mm, height 1100mm; length 6200mm, height 1000mm; without cover: body length corresponding to height 1190mm,1150mm,1100mm; 2. Optional front grille; 3. Optional mining body / 1. Optional covered cargo body, cover weight corresponding to body length: 270, 290, 310, 250 kg; 2. Optional front grille; 3. Optional mining body; 4. Dump type: rear dump; 5. Without cover: body length 5400mm, max height 1200mm; length 5600mm, max height 1190mm; length 5800mm, max height 1150mm; length 6200mm, max height 1085mm. With cover: body length 5400mm, max height 1100mm; length 5600mm, max height 1100mm; length 5800mm, max height 1100mm; length 6200mm, height 1000mm. Other specs: floor 16mm, side 12mm, side plate ribs 8mm or full channel steel, four longitudinal beams, four tail seats, full welding, lift system: HYVA FC150; / 1. Optional covered cargo body, cover weight corresponding to body length: 270, 290, 310, 250 kg; 2. Optional front grille; 3. Optional mining body; 4. Dump type: rear dump; 5. Without cover: body length 5400mm, max height 1200mm; length 5600mm, max height 1190mm; length 5800mm, max height 1150mm; length 6200mm, max height 1085mm. With cover: body length 5400mm, max height 1100mm; length 5600mm, max height 1100mm; length 5800mm, max height 1100mm; length 6200mm, height 1000mm. / 1. Optional covered cargo body, cover weight corresponding to body length: 270, 290, 310 kg; 2. Optional front grille; 3. Optional mining body; 4. Dump type: rear dump; 5. Without cover: body length 5800mm, max height 1150mm; length 6200mm, max height 1085mm. With cover: body length 5600mm, max height 1100mm; length 5800mm, max height 1100mm; length 6200mm, height 1000mm.
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai / Sinotruk
Number of cylinders: 6cylinder
Displacement: 9.726L
Emission standard: China III / Euro III
Max output power: 247 / 228 / 213 / 276 / 199 / 250 / 196kW
Max hp: 336 / 310 / 290 / 375 / 270 / 340 / 266Horsepower
Max torque: 1250 / 1160 / 1500 / 1350 / 1100N·m
Max torque speed: 1200-1600 / 1100-1600 / 1400-1600rpm
Rated speed: 2200rpm
Engine Type: Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled / Water-cooled, 4-stroke, with exhaust brake, direct injection, turbocharged intercooled / Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, electronic fuel injection pump, EGR / Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, electronic fuel injection pump
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 12 / 9Gear
Number of Reverse Gears: 2 / 1pcs
Cargo box parameters
Unloading Type: Rear-dump body / Dump type
Cargo box length: 9.92 / 8 / 6.7 / 9.5 / 6.2 / 4.8 / 5.6 / 7.3 / 5.4 / 6.5 / 5.8m
Cargo box width: 2.5 / 2.3m
Cargo box height: 3.35 / 1 / 1.24 / 0.88 / 1.3 / 1.39 / 1.5 / 1.389 / 0.9 / 1.25 / 1.15 / 1.8 / 1.19 / 1.2m
fuel tank
Fuel tank capacity: 350 / 280L
Chassis Specs
Frame Dimensions: 865/317*(8+8)mm
FAQ
What kind of truck is SAIC Hongyan SAIC Hongyan Tuba Heavy Truck Dump Trucks?
SAIC Hongyan SAIC Hongyan Tuba Heavy Truck is an export-oriented Dump Trucks lineup with about 18 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SAIC Hongyan Tuba Heavy Truck Dump Trucks?
SAIC Hongyan Tuba Heavy Truck Dump Trucks export reference is about $37,028 – $47,208. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SAIC Hongyan Tuba Heavy Truck Dump Trucks cover?
SAIC Hongyan Tuba Heavy Truck Dump Trucks mainly covers: Drive: 8x4; Horsepower: 290 hp / 310 hp / 336 hp / 375 hp; Emission: China III / Euro III; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SAIC Hongyan Tuba Heavy Truck Dump Trucks?
For SAIC Hongyan Tuba Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SAIC Hongyan Tuba Heavy Truck Dump Trucks include?
SAIC Hongyan Tuba Heavy Truck Dump Trucks currently lists about 18 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SAIC Hongyan Tuba Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
