SAIC Hongyan Jingang Heavy Truck 310hp 6X4(10 wheels) 5.6m Dump Truck
EXW
From $44,861
Export quote
SAIC Hongyan King Kong Heavy Truck Dump Trucks
Main model photos
47 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SAIC Hongyan Jingang Heavy Truck 310hp 6X4(10 wheels) 5.6m Dump Truck | 6x4 / 310hp / China III / Euro III | From $44,861 | |
| SAIC Hongyan King Kong Heavy Truck 336 hp 6X4(10 wheels) 6.4m dump truck | 6x4 / 336hp / China IV | From $41,361 | |
| SAIC Hongyan King Kong Heavy Truck 310 hp 6X4(10 wheels) 6.4m dump truck | 6x4 / 310hp / China IV | From $40,361 | |
| SAIC Hongyan King Kong Heavy Truck 336 hp 6X4(10 wheels) 6m dump truck | 6x4 / 336hp / China IV | From $41,333 | |
| SAIC Hongyan King Kong Heavy Truck 310 hp 6X4(10 wheels) 5.2m dump truck | 6x4 / 310hp / China IV | From $39,944 |
SAIC Hongyan King Kong Heavy Truck 336 hp 6X4(10 wheels) 6.4m dump truck
EXW
From $41,361
Export quote
SAIC Hongyan King Kong Heavy Truck 310 hp 6X4(10 wheels) 6.4m dump truck
EXW
From $40,361
Export quote
SAIC Hongyan King Kong Heavy Truck 336 hp 6X4(10 wheels) 6m dump truck
EXW
From $41,333
Export quote
SAIC Hongyan King Kong Heavy Truck 310 hp 6X4(10 wheels) 5.2m dump truck
EXW
From $39,944
Export quote
Series Specs
Basic Info
Model code (announced): CQ3254SMG384 / CQ3255TRG444 / CQ3255TRG414 / CQ3255TRG364 / CQ3255TRG334 / CQ3255TRG384B / CQ3255TRG384 / CQ3314STG426 / CQ3254STHG324 / CQ3254SRHG464 / CQ3314STG466 / CQ3314SMG396 / CQ3314SMG426 / CQ3314SMG306 / CQ3314STHG466 / CQ3314STHG426 / CQ3314SRHG306 / CQ3254STG434 / CQ3254SRG494 / CQ3254SMG434 / CQ3254STG324 / CQ3254SMHG384 / CQ3254SMHG294 / CQ3254SMHG364 / CQ3254SMG364 / CQ3253TMG324 / CQ3254TMG384 / CQ3254TPG384 / CQ3254SMG324
Drive type: 6X4 / 8X4
Wheelbase: 3825+1350 / 4400+1400 / 4125+1350 / 3600+1400 / 3300+1400 / 3800+1400 / 4425+1350 / 4100+1400 / 3325+1350 / 1800+4200+1350 / 3225+1350 / 4600+1350 / 3285+1350 / 1800+4600+1350 / 1800+3900+1350 / 1800+3000+1350 / 4325+1350 / 4975+1350 / 2925+1350 / 3600+1350 / 3240mm
Engine Model: WeichaiWP10.310E32 / WeichaiWP10.336E40 / WeichaiWP10.310E40 / WeichaiWP10.290E32 / WeichaiWP10.300E40 / WeichaiWP10.336 / SinotrukWD615.95E / SinotrukWD615.93E / WeichaiWP10.270 / WeichaiWP10.340E32 / SAIC Fiat Powertrain HongyanC9.340(F2CE0681C*B052) / SAIC Fiat Powertrain HongyanF2CE0681D*B053 / SinotrukWD615.96E / SinotrukWD615.92E / SDECSC11CB290Q2 / WeichaiWP10.340 / WeichaiWP10.290 / SDECSC9DK290Q3B1
Transmission Model: Fast Gear9JS135 / Fast Gear12JSD180T / Fast Gear10JSD140 / Fast Gear10JSD160 / Fast Gear12JS160T / Fast GearRT-11509C / Fast Gear9JS119
Rear Axle Ratio: 5.73 / 4.8
Cab length: 8.55 / 9.31 / 8.91 / 8.11 / 7.64 / 8.66 / 8.46 / 8.45 / 10.91 / 7.821 / 9.56 / 11.96 / 10.81 / 11.11 / 9.55 / 9.45 / 9.315 / 10.085 / 7.621 / 7.34 / 8.19 / 7.617 / 8.65 / 7.62m
Cab width: 2.5m
Cab height: 3.51 / 3.46 / 3.35 / 3.343 / 3.169m
Front track width: 2006 / 2006/2006mm
rear track: 1850/1850 / 1800mm
Curb Weight: 12.17 / 12.38 / 12.15 / 11.97 / 11.92 / 12.01 / 15.37 / 11.95 / 12.45 / 15.45 / 15.27 / 15 / 12.4 / 12.5 / 11.9 / 25 / 12.37 / 12.2 / 12.06ton
Rated payload: 12.7 / 12.49 / 12.72 / 12.9 / 12.95 / 12.86 / 15.5 / 12.92 / 12.42 / 15.42 / 15.6 / 15.87 / 25.5 / 12.47 / 12.37 / 12.99 / 12.5 / 12.6 / 12.8ton
GVWR: 25 / 31 / 24.95ton
Origin: Chongqing
tonnage class: Heavy truck
Approach angle: 23 / 26 / 25°
departure angle: 20 / 16 / 17 / 21 / 24 / 19 / 12 / 15 / 18 / 35°
Remarks: 1. Optional covered cargo body, cover weight corresponding to body length: 270, 290, 310, 250 kg; 2. Optional front grille; 3. Optional mining body; 4. Dump type: rear dump; 5. Without cover: body length 5400mm, max height 1200mm; length 5600mm, max height 1190mm; length 5800mm, max height 1150mm; length 6200mm, max height 1085mm. With cover: body length 5400mm, max height 1100mm; length 5600mm, max height 1100mm; length 5800mm, max height 1100mm; length 6200mm, height 1000mm. Other specs: floor 16mm, side 12mm, side plate ribs 8mm or full channel steel, four longitudinal beams, four tail seats, full welding, lift system: HYVA FC150; / ABS, 350L, mechanical seat, manual tilt, manual mirrors, four-leaf spring, rear stabilizer bar, no AC, no spare tire carrier, no central locking / Frame (mm): 940-865/317x8+8 / Frame 865/317 8+8 / 1. Optional front mask; 2. This model can also be used without a trailer / 1. Optional covered cargo body, cover weight corresponding to body length: 270, 290, 310, 250 kg; 2. Optional front grille; 3. Optional mining body; 4. Dump type: rear dump; 5. Without cover: body length 5400mm, max height 1200mm; length 5600mm, max height 1190mm; length 5800mm, max height 1150mm; length 6200mm, max height 1085mm. With cover: body length 5400mm, max height 1100mm; length 5600mm, max height 1100mm; length 5800mm, max height 1100mm; length 6200mm, height 1000mm. / 1. Optional T5 cab and cargo box inner dimensions; 2. Optional T8 cab and cargo box; 3. Optional covered cargo box; 4. Vehicle shall be fitted with rear reflective markings / Cargo body length options: 5.4 / 5.6 / 5.8 m. / Optional T-type cab; 2 Optional mining bucket body; 3 Optional eco-friendly covered body, cover weight 300 kg, body length also 8.45 m, cargo box length also 5.8 m / 1. Without optional covered cargo box, cargo box dimensions: 4800×2300×1389 (mm), 5000×2300×1300 (mm), 5200×2300×1290 (mm); with optional covered cargo box, cover weight per cargo box length: 200, 220, 240 kg; after covering, cargo box dimensions: 4800×2300×1300 (mm), 5000×2300×1300 (mm), 5200×2300×1250 (mm); 2. Optional front grille; 3. Optional mining dump body. Dump body unloading method: rear dump.
Version: Urban Construction & Muck
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai / Sinotruk / SAIC Fiat Powertrain Hongyan / SDEC
Number of cylinders: 6cylinder
Displacement: 9.726 / 8.709 / 10.5 / 8.82L
Emission standard: China III / Euro III / China IV / China II/Euro II
Max output power: 228 / 247 / 213 / 221 / 199 / 250 / 254 / 216 / 276 / 196kW
Max hp: 310 / 336 / 290 / 300 / 270 / 340 / 375 / 266Horsepower
Max torque: 1250 / 1500 / 1160 / 1390 / 1350 / 1100 / 1300N·m
Max torque speed: 1200-1600 / 1300-1600 / 1200-1500 / 1100-1600 / 1400-1600 / 1000-1800 / 1000-1600 / 1170 / 1400rpm
Rated speed: 2200 / 1900 / 2100rpm
Engine Type: Water-cooled, 4-stroke, with exhaust brake, direct injection, turbocharged intercooled / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled / Electronic high-pressure common rail + SCR / Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, electronic fuel injection pump, EGR / Electronic high-pressure common rail system / Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, electronic fuel injection pump / direct injection, inline, 6-cylinder, water-cooled, 4-stroke / Inline, mechanical pump, internal EGR, turbocharged intercooled, wet liner, front gear train
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 9 / 12 / 10Gear
Number of Reverse Gears: 1 / 2pcs
Cargo box parameters
Unloading Type: Rear-dump body / Dump type
Cargo box length: 5.6 / 6.4 / 6 / 5.2 / 4.8 / 8 / 7 / 9.5 / 8.2 / 6.7 / 6.5 / 7.3 / 5.8 / 5.4 / 6.2m
Cargo box width: 2.3m
Cargo box height: 1.8 / 1 / 1.09 / 1.25 / 1.35 / 1.1 / 1.2 / 1.3 / 0.9 / 1.19 / 0.88 / 1.24 / 0.99 / 1.4 / 1.389m
fuel tank
Fuel tank capacity: 350 / 280 / 300L
FAQ
What kind of truck is SAIC Hongyan SAIC Hongyan King Kong Heavy Truck Dump Trucks?
SAIC Hongyan SAIC Hongyan King Kong Heavy Truck is an export-oriented Dump Trucks lineup with about 39 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SAIC Hongyan King Kong Heavy Truck Dump Trucks?
SAIC Hongyan King Kong Heavy Truck Dump Trucks export reference is about $38,194 – $50,000. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SAIC Hongyan King Kong Heavy Truck Dump Trucks cover?
SAIC Hongyan King Kong Heavy Truck Dump Trucks mainly covers: Drive: 6x4; Horsepower: 310 hp / 336 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SAIC Hongyan King Kong Heavy Truck Dump Trucks?
For SAIC Hongyan King Kong Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SAIC Hongyan King Kong Heavy Truck Dump Trucks include?
SAIC Hongyan King Kong Heavy Truck Dump Trucks currently lists about 39 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SAIC Hongyan King Kong Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
