Dongfeng Changxing D1 200hp 4X2(6 wheels) 6.1m Truck-mounted Crane
EXW
From $35,694
Export quote
Dongfeng Changxing truck-mounted crane
Main model photos
340 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Changxing D1 200hp 4X2(6 wheels) 6.1m Truck-mounted Crane | 4x2 / 180hp / China VI | From $35,694 | |
| Dongfeng Changxing D1 200hp 4X2(6 wheels) 6.1m Truck-mounted Crane | 4x2 / 200hp / China VI | From $42,361 | |
| Dongfeng Changxing D1 160 hp 4X2(6 wheels) 5.1m truck-mounted crane | 4x2 / 160hp / China V | From $30,556 | |
| Dongfeng Changxing 240hp 6X4(10 wheels) truck-mounted crane | 6x4 / 240hp / China V | From $51,389 | |
| Dongfeng Changxing 270hp 6X4(10 wheels) Truck Mounted Crane | 6x4 / 270hp / China V | From $46,806 |
Dongfeng Changxing D1 200hp 4X2(6 wheels) 6.1m Truck-mounted Crane
EXW
From $42,361
Export quote
Dongfeng Changxing D1 160 hp 4X2(6 wheels) 5.1m truck-mounted crane
EXW
From $30,556
Export quote
Dongfeng Changxing 240hp 6X4(10 wheels) truck-mounted crane
EXW
From $51,389
Export quote
Dongfeng Changxing 270hp 6X4(10 wheels) Truck Mounted Crane
EXW
From $46,806
Export quote
Series Specs
Basic Info
Cab dimensions: 9×2.5×3.55 / 7.995×2.4×3.35 / 11.95×2.55×3.85 / 12×2.52×3.8 / 11.95×2.5×3.85 / 12×2.5×3.8 / 8.73×2.55×3.85 / 9×2.5×3.95m
Type: Truck with crane
Drive type: 4X2 / 6X4 / 8X4 / 6X2
Wheelbase: 5100 / 4500 / 5900+1300 / 2150+4250+1300 / 2150+5150 / 5150mm
Rated mass: 6.12 / 4.135 / 7.195 / 8.295 / 13.425 / 8.805 / 10.005 / 6.37 / 4.17ton
GVWR: 16 / 13.58 / 24.49 / 31 / 25 / 18 / 15.8ton
Remarks: D1 single-row cab, heavy-duty mountain version, Shaanchi small 8-speed gearbox with PTO, 280mm straight-through triple-layer dedicated frame, 5T/10T front/rear narrow axles (ratio 6.5), 9.00R20 steel-belted tires, 200L aluminum fuel tank, FARIZON throttle, with ABS. Air-suspension seat, factory A/C, four-in-one central door lock
Front/rear suspension: 1.2/2.35 / 1.45/3.3 / 1.45/2.7 / 1.45/2.8 / 1.45/3.25 / 1.25/2.13 / 1.45/2.45m
Energy Type: Diesel
Body Parameters
Other special notes: Yunnan-Guizhou-Sichuan mountain area dedicated truck-mounted crane, short wheelbase, high horsepower. Upper body XCMG 6.3-ton four-section arm crane
Crane model: SQS125,QYS-5,SPS12500,URV504 / SQ12.0SA4 / SQS350,QYS-14,SPS35000,URV1204 / SQS350,QYS-14,SPS35000,ZLC3500 / SQS350,QYS-14,SPS35000,ZLC4000 / SQS250,QYS-10,SPS25000,ZLC2500 / SQS200,QYS-8,SPS20000,URV804 / SQS200,QYS-8,SPS20000,ZLC2000
Lifting capacity: 6.3 / 12 / 11 / 14 / 10 / 8 / 4ton
crane self-weight: 5.1 / 5.5 / 4 / 3.5 / 2.6ton
Vehicle certification code: DFV5161JSQGP6D / DFV5140JSQGD5D / DFV5240JSQGD5D / EQ5240JSQGD5D / EQ5310JSQGZ5D / EQ5250JSQGZ5D / EQ5250JSQGZ5D1 / EQ5180JSQGD5D / EQ5160JSQGZ5D
Body Brand: Dongfeng
Engine parameters
Engine Brand: Yuchai / Dongfeng
Engine Model: YuchaiYCS04180-68 / YuchaiYCS04200-68 / YuchaiYC4E160-56 / YuchaiYC6JA240-50 / YuchaiYC6A270-50 / YuchaiYC6MK340-50 / DongfengISD270 50 / YuchaiYC6JA220-50 / YuchaiYC6JA180-50 / YuchaiYC4S150-50
Displacement: 4.16 / 4.26 / 6.87 / 7.52 / 10.338 / 6.7 / 3.767L
Emission standard: China VI / China V
Max output power: 132 / 147 / 118 / 177 / 199 / 250 / 198 / 162 / 110kW
Max hp: 180 / 200 / 160 / 240 / 270 / 340 / 220 / 150Horsepower
Max torque: 650 / 720 / 600 / 950 / 1100 / 1500 / 970 / 860 / 700 / 500N·m
Max torque speed: 1200-1900 / 1200-1600 / 1300-1600 / 1200-1800 / 1100-1500 / 1200-1700 / 1300-1800rpm
Rated speed: 2300 / 2600 / 1900 / 2500rpm
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Dongfeng Changxing
Chassis Model: DFV1161GP6DJ / EQ1140GD5DJ / EQ1240GD5DJ / EQ1310GZ5DJ / EQ1250GZ5DJ1 / EQ1250GZ5DJ / EQ1180GD5DJ / EQ1160GZ5DJ
Frame Dimensions: 300(three-layer through) / 280 (3-layer) / 250 (full triple-layer)mm
rear axle description: 153 front and rear axle / 10T / 13T*2/16T*2(wheel reduction) / 10T*2 / 5T/9T / 8T
Axle ratio: 4.875
Leaf spring count: 8/10+8 / 7/9+6 / 9/13 / 9/9/9,3/3/4,9/9/13 / 8/9,8/10,9/10,8/13,9/13 / 8/13,9/10,9/13 / 9/9/10+8,3/3/4+3,3/3/10+8,9/9/4+3 / 8/9+7,8/10+7,3/4+3,9/12+10,8/10+8,7/9+6,11/11+10,9/10+8 / 9/10+8,8/10+7 / 7/9+6,8/9+7,8/9+5,8/10+8,9/10+8,11/11+10
Transmission Parameters
Number of gears: 8 / 9 / 10 / 12Gear
Transmission Model: 8-speed gearbox / Fast Gear8JS85E / Fast Gear 8-speed / Fast Gear 9-speed / Fast Gear 10-Speed / Fast Gear9JS119TA / Fast Gear12JS180TA / Fast Gear8JS118A
Cab parameters
Cab: Dongfeng Changxing D1 / D3 / D7 / D1
Tire
Tire Size: 9.00R20 16PR / 8.25-20 16PR / 11.00R20 18PR / 10.00R20-18PR / 8.25R20 16PR
Number of tires: 6 / 10 / 12 / 8pcs
FAQ
What kind of truck is Dongfeng Dongfeng Changxing truck-mounted crane?
Dongfeng Dongfeng Changxing is an export-oriented truck-mounted crane lineup with about 13 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng Changxing truck-mounted crane?
Dongfeng Changxing truck-mounted crane export reference is about $30,556 – $58,472. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng Changxing truck-mounted crane cover?
Dongfeng Changxing truck-mounted crane mainly covers: Drive: 4x2 / 6x4; Horsepower: 160 hp / 180 hp / 200 hp / 240 hp / 270 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng Changxing truck-mounted crane?
For Dongfeng Changxing truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng Changxing truck-mounted crane include?
Dongfeng Changxing truck-mounted crane currently lists about 13 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng Changxing truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
