FAW Jiefang Qingdao Hanwei (J5M) Heavy Truck 240hp 6X2(8 wheels) 6m Dump Truck
EXW
Export quote
FAW Jiefang Qingdao Hanwei J5M heavy truck Dump
Main model photos
42 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Qingdao Hanwei (J5M) Heavy Truck 240hp 6X2(8 wheels) 6m Dump Truck | 6x2 / 240hp / China III / Euro III | ||
| FAW Jiefang Qingdao Hanwei (J5M) Heavy Truck 240 hp 8X4(12 wheels) 6.5m Dump Truck | 8x4 / 240hp / China III / Euro III | ||
| FAW Jiefang Qingdao Hanwei (J5M) Medium Truck 220 hp 8X4(12 wheels) 6.8m Dump Truck | 8x4 / 220hp / China III / Euro III | ||
| FAW Jiefang Qingdao Hanwei (J5M) Heavy Truck 260 hp 8X4(12 wheels) 6.8m Dump Truck | 8x4 / 260hp / China III / Euro III | ||
| FAW Jiefang Qingdao Hanwei (J5M) Heavy Truck 260 hp 8X4(12 wheels) 5.8m Dump Truck | 8x4 / 260hp / China III / Euro III |
FAW Jiefang Qingdao Hanwei (J5M) Heavy Truck 240 hp 8X4(12 wheels) 6.5m Dump Truck
EXW
Export quote
FAW Jiefang Qingdao Hanwei (J5M) Medium Truck 220 hp 8X4(12 wheels) 6.8m Dump Truck
EXW
Export quote
FAW Jiefang Qingdao Hanwei (J5M) Heavy Truck 260 hp 8X4(12 wheels) 6.8m Dump Truck
EXW
Export quote
FAW Jiefang Qingdao Hanwei (J5M) Heavy Truck 260 hp 8X4(12 wheels) 5.8m Dump Truck
EXW
Export quote
Series Specs
Basic Info
Model code (announced): CA3250P1K2T3EA80 / CA3300P1K2T10EA80 / CA3310P1K2L2T4EA80 / CA3310P1K8L3T4EA80 / CA3300P1K2L2T4EA80 / CA3240P1K2L3T4EA80 / CA3300P1K2L5T4EA80 / CA3313P1K2L5T4EA80 / CA3122P1K2EA80 / CA3161P1K2EA80 / CA3250P1K15L2T1EA80 / CA3208P1K2L2T1EA80 / CA3200P1K15L1T1EA80 / CA3121P1K2EA80 / CA3250P1K15L3T1EA80 / CA3160P1K2T3EA80
Drive type: 6X2 / 8X4 / 4X2 / 6X4
Wheelbase: 1900+3400 / 1900+2950+1350 / 1900+3200+1350 / 1900+3450+1350 / 1900+2450+1350 / 1900+4200+1350 / 4780 / 4350 / 3450+1450 / 4080+1350 / 3250+1450 / 3650+1450 / 1900+3000mm
Engine Model: XichaiCA6DF3-24E3F / YuchaiYC6J220-33 / YuchaiYC6A260-33 / XichaiCA6DF3-26E3F / DachaiBF6M1013-30E3 / DachaiBF6M1013-28E3 / XichaiCA6DL1-28E3F / XichaiCA6DF3-24E3 / DachaiCA6DE3-24E3F / WeichaiWP10.300NE31 / WeichaiWP10.270N / WeichaiWP10.270E32 / XichaiCA6DF3-22E3 / WeichaiWP10.336NE31
Transmission Model: Fast Gear8JS118 / Fast Gear9JS119A / Fast Gear9JS119 / Fast Gear12JS160T / Fast Gear9JSD135 / Fast GearRT-11509C
Rear Axle Ratio: 5.286 / 6.166 / 5.143 / 4.875 / 6.333 / 5.833 / 5.921
Cab length: 8.69 / 9.285 / 9.805 / 8.585 / 10.125 / 8.44 / 7.74 / 8.031 / 8.705 / 7.631 / 8.263m
Cab width: 2.5 / 2.49m
Cab height: 3.25 / 3.06m
Front track width: 1914/1914 / 1922/1922 / 1914 / 2020mm
rear track: 1860 / 1847/1847 / 1847 / 1860/1860mm
Curb Weight: 11.905 / 14.1 / 14.8 / 11.98 / 13.995 / 14.995 / 5.905 / 12.3 / 10.1 / 10.09 / 6.8 / 12.5 / 8.1ton
Rated payload: 12.965 / 15.305 / 16.005 / 11.885 / 15.9 / 15.81 / 6.08 / 8.155 / 12.505 / 9.905 / 4.905 / 12.305 / 7.905ton
GVWR: 25 / 29.6 / 31 / 24.06 / 30.09 / 12.18 / 16 / 20.2 / 20.19 / 11.9 / 16.2ton
Origin: Qingdao, Shandong
tonnage class: Heavy truck / Medium-duty truck
Approach angle: 21 / 23 / 22 / 28 / 18°
departure angle: 36 / 33 / 40 / 34 / 27 / 25 / 60 / 12°
Remarks: Flat roof / Optional engine: Dachai CA6DE3-22E3F / Optional engine: Xichai CA6DF3-24E3, Xichai CA6DF3-26E3F / Optional: XichaiCA6DF3-24E3F / Body interior length/body interior height correspondence (mm): 1.5400/1200; 2.5600/1160. Dumping method: rear dump. Optional environmental top cover, causing curb weight variation less than 3%, negligible. / Optional: XichaiCA6DF3-22E3, XichaiCA6DF3-26E3F
Energy Type: Diesel
Engine parameters
Engine Brand: Xichai / Yuchai / Dachai / Weichai
Number of cylinders: 6cylinder
Displacement: 7.12 / 6.494 / 7.255 / 7.146 / 7.7 / 6.7 / 6.618 / 9.726 / 6.74L
Emission standard: China III / Euro III
Max output power: 177 / 162 / 191 / 192 / 220 / 206 / 209 / 221 / 199 / 247kW
Max hp: 240 / 220 / 260 / 300 / 280 / 270 / 336Horsepower
Max torque: 900 / 800 / 960 / 930 / 1100 / 1050 / 935 / 890 / 1390 / 1270 / 860N·m
Max torque speed: 1300-1500 / 1200-1700 / 1400-1600 / 1400 / 1100-1400 / 1500 / 1200-1500 / 1200-1600 / 1350-1500rpm
Rated speed: 2300 / 2500 / 1900 / 2200rpm
Engine Type: 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / Vertical, inline, water-cooled, four-stroke, direct injection / Vertical, inline, water-cooled, four-stroke, direct injection, EGR / 6-cylinder inline, direct injection, turbocharged intercooled, electronic unit pump / 6-cylinder inline, direct injection, turbocharged intercooled, inline pump EGR / 4-stroke, inline, water-cooled, turbocharged with intercooling / Water-cooled, four-stroke, with exhaust brake / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled / Water-cooled, 4-stroke, with exhaust brake, direct injection, turbocharged intercooled
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8 / 9 / 12Gear
Number of Reverse Gears: 1 / 2pcs
Cargo box parameters
Unloading Type: Rear-dump body / Dump type
Cargo box length: 6 / 6.5 / 6.8 / 6.83 / 5.8 / 7.5 / 5.7 / 5 / 5.2 / 6.2 / 4.8 / 5.6m
Cargo box width: 2.31 / 2.3 / 2.32m
Cargo box height: 1.13 / 1.23 / 1.22 / 1.17 / 1.37 / 0.85 / 1.11 / 1.05 / 0.8 / 0.83 / 1.26 / 0.87 / 1.09 / 1.2 / 1.5m
fuel tank
Fuel tank capacity: 200 / 400 / 600 / 300L
Chassis Specs
rear axle description: 457 cast steel axle (ratio 5.286) / 457 stamped-welded axle / Reinforced 435 stamped-welded axle / 300 cast wheel reduction axle / 300 stamped-welded wheel-reduction axle / 475 welded axle
FAQ
What kind of truck is FAW Jiefang Qingdao FAW Jiefang Qingdao Hanwei J5M heavy truck Dump Trucks?
FAW Jiefang Qingdao FAW Jiefang Qingdao Hanwei J5M heavy truck is an export-oriented Dump Trucks lineup with about 17 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does FAW Jiefang Qingdao Hanwei J5M heavy truck Dump cover?
FAW Jiefang Qingdao Hanwei J5M heavy truck Dump mainly covers: Drive: 6x2 / 8x4; Horsepower: 220 hp / 240 hp / 260 hp; Emission: China III / Euro III; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Jiefang Qingdao Hanwei J5M heavy truck Dump?
For FAW Jiefang Qingdao Hanwei J5M heavy truck Dump: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FAW Jiefang Qingdao Hanwei J5M heavy truck Dump include?
FAW Jiefang Qingdao Hanwei J5M heavy truck Dump currently lists about 17 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Jiefang Qingdao Hanwei J5M heavy truck Dump?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
