SAIC Hongyan Genlyon C6 360hp 8X4(12 wheels) 7.45m³ LNG concrete mixer truck (China VI)
EXW
From $59,722
Export quote
SAIC Hongyan Genlyon Heavy Truck concrete mixer
Main model photos
1,735 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SAIC Hongyan Genlyon C6 360hp 8X4(12 wheels) 7.45m³ LNG concrete mixer truck (China VI) | 8x4 / 360hp / China VI | From $59,722 | |
| SAIC Hongyan Genlyon H6 Composite Edition 360hp 8X4(12 wheels) 7.68m³ Concrete Mixer Truck | 8x4 / 360hp / China VI | From $54,250 | |
| SAIC Hongyan Genlyon H6 Composite Reinforced Edition 360hp 8X4(12 wheels) 7.68m³ Concrete Mixer Truck | 8x4 / 360hp / China VI | From $54,528 | |
| SAIC Hongyan Genlyon H6 Composite Lightweight Edition 360hp 8X4(12 wheels) 7.68m³ Concrete Mixer Truck | 8x4 / 360hp / China VI | From $54,250 | |
| SAIC Hongyan Genlyon H6 Standard Edition 360hp 8X4(12 wheels) 7.68m³ Concrete Mixer Truck | 8x4 / 360hp / China VI | From $52,833 |
SAIC Hongyan Genlyon H6 Composite Edition 360hp 8X4(12 wheels) 7.68m³ Concrete Mixer Truck
EXW
From $54,250
Export quote
SAIC Hongyan Genlyon H6 Composite Reinforced Edition 360hp 8X4(12 wheels) 7.68m³ Concrete Mixer Truck
EXW
From $54,528
Export quote
SAIC Hongyan Genlyon H6 Composite Lightweight Edition 360hp 8X4(12 wheels) 7.68m³ Concrete Mixer Truck
EXW
From $54,250
Export quote
SAIC Hongyan Genlyon H6 Standard Edition 360hp 8X4(12 wheels) 7.68m³ Concrete Mixer Truck
EXW
From $52,833
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SAIC Hongyan Genlyon H6 350 hp 8X4(12 wheels) Concrete Mixer Truck | 8x4 / 350hp / China VI | ||
| SAIC Hongyan Genlyon M500 320 hp 8X4(12 wheels) 7.75 m³ Concrete Mixer Truck (10-speed) | 8x4 / 320hp / China V | ||
| SAIC Hongyan Genlyon M500 320 hp 8X4(12 wheels) 7.75 m³ concrete mixer truck (HY300S rear axle) | 8x4 / 320hp / China V | ||
| SAIC Hongyan Genlyon 390hp 6X4(10 wheels) 4.2m³ Concrete Mixer Truck | 6x4 / 390hp / China V | ||
| SAIC Hongyan Genlyon M500 Lightweight Version 320 hp 8X4(12 wheels) 7.75 m³ Concrete Mixer Truck | 8x4 / 320hp / China V |
SAIC Hongyan Genlyon H6 350 hp 8X4(12 wheels) Concrete Mixer Truck
EXW
Export quote
SAIC Hongyan Genlyon M500 320 hp 8X4(12 wheels) 7.75 m³ Concrete Mixer Truck (10-speed)
EXW
Export quote
SAIC Hongyan Genlyon M500 320 hp 8X4(12 wheels) 7.75 m³ concrete mixer truck (HY300S rear axle)
EXW
Export quote
SAIC Hongyan Genlyon 390hp 6X4(10 wheels) 4.2m³ Concrete Mixer Truck
EXW
Export quote
SAIC Hongyan Genlyon M500 Lightweight Version 320 hp 8X4(12 wheels) 7.75 m³ Concrete Mixer Truck
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 10.2×2.55×3.99 / 10.225×2.55×4 / 9.385×2.55×3.995 / 9.04×2.55×3.99 / 9.385×2.5×3.995 / 10.15×2.525×3.995 / 11X2.5X3.995 / 10.45×2.5×3.95 / 8.365×2.5×3.995 / 11.435×2.5×3.995 / 10.11×2.5×3.95 / 11.0×2.5×3.995m
Truck Type: Concrete mixer truck / Concrete mixing
Drive type: 8X4 / 6X4
Vehicle origin: Chongqing
Wheelbase: 2000+2800+1400 / 1800+3000+1400 / 3800+1400 / 2000+3000+1400 / 1800+3000+1350 / 1800+3600+1400 / 4400+1400 / 3300+1400 / 4200+1400 / 1800+3300+1400mm
Front/rear track width: Front: 2040/2040mm; Rear: 1858/1858 / Front: 2020; Rear: 1858/1858 / Front: 2020mm; Rear: 1858/1858 / Front track: 2006/2006mm; Rear track: 1850/1850mm / Front: 2006/2006mm; Rear: 1850/1850 / Front track: 2006mm; Rear track: 1850/1850mm / Front track: 2006mm; Rear track: 1850/1850 / Front track: 2006; Rear track: 1850mm; Rear track: 1850mm
Curb Weight: 14.6 / 14.1 / 14.25 / 15.2 / 16.91 / 13.96 / 17.27 / 15.6 / 12.26 / 16.87 / 15 / 14.8ton
Rated payload: 16.27 / 16.77 / 16.62 / 9.67 / 13.96 / 16.91 / 13.6 / 9.27 / 12.61 / 13.71 / 9.87 / 14 / 10.07ton
Max. speed: 80 / 89 / 100km/h
Front/rear suspension: 1.435/2.365 / 1.46/2.565 / 1.435/2.565 / 1.435/2.405 / 1.435/1.75 / 1.435/21.75 / 1.435/2.7 / 1.435/3.215 / 1.435/2.23 / 1.435/3.075 / 1.435/3.065m
Body Parameters
Mixing drum capacity: 7.45 / 7.68 / 7.65 / 7.6 / 4.43 / 7.75 / 6 / 4.2 / 5.77 / 4.5 / 6.4 / 4.8m³
Vehicle certification code: CQ5317GJBHD10306T / CQ5317GJBSV09286 / CQ5317GJBHD10286 / CQ5317GJBHV09286 / CQ5257GJBHD10384T / CQ5316GJBHMVG306 / CQ5316GJBHTVG336H / CQ5256GJBHTVG444H / CQ5256GJBHMVG334 / CQ5316GJBHTVG366H / CQ5256GJBHTVG424H / CQ5315GJBHXG366 / CQ5315GJBHXG336 / CQ5255GJBHTG424
Body Brand: SAIC Hongyan / Hongyan brand
Others: ABS, auto AC, 400L, manual mirrors, mechanical seat, manual tilt, spare tire carrier, FARIZON throttle, four-leaf springs, rear stabilizer bar, rear tow pin bracket, no central locking; options: body color, axle ratio, tires / Available ratio: 4.44/4.875 / Optional ratios: 4.625/5.286 / Transmission model optional Fast Gear 12JSD160T / Auto AC; electric tilt cab
Engine parameters
Engine Model: SDECSC10ET360Q6 / SAIC Fiat Powertrain HongyanF2CCE611H*M / SDECSC10E370Q6 / SDECSC10E330Q6 / SDECSC10E300Q6 / SAIC Fiat Powertrain HongyanF2CCE611G*M / SAIC Fiat Powertrain HongyanF2CCE611J*M / SDECSC10ET320Q6 / SDECSC10ET340Q6 / SDECSC10ET380Q6 / SDECSC10E420Q6 / SDECSC10E400Q6 / SAIC Fiat Powertrain HongyanF2CCE611B*M / SAIC Fiat Powertrain HongyanF2CCE611C*L / SAIC Fiat Powertrain HongyanF2CCE611A*L / SAIC Fiat Powertrain HongyanF2CCE611D*L / F2CCE611C*L / SAIC Fiat Powertrain HongyanF2CCE611B*L / SAIC Fiat Powertrain HongyanC9.390 C4(F2CE3681E*P)
Number of cylinders: 6cylinder
fuel type: LNG (liquefied natural gas) / Diesel
Displacement: 10.42 / 8.709 / 10.4 / 8.7L
Emission standard: China VI / China V / China IV
Max output power: 265 / 272 / 243 / 221 / 287 / 234 / 250 / 280 / 309 / 294 / 257 / 235 / 215kW
Max hp: 360 / 370 / 330 / 300 / 390 / 320 / 340 / 380 / 420 / 400 / 350 / 290Horsepower
Rated speed: 1900 / 2000 / 2100rpm
Engine Type: Inline 6-cylinder, electronically controlled premix, TWC / Compression ignition, direct injection, inline six-cylinder, water-cooled / EGR+DOC+DPF+SCR+ASC / Electronic high-pressure common rail system / Inline 6-cylinder, water-cooled, turbocharged, high-pressure common rail
Chassis Specs
Chassis Series: GENLYON C6 / Genlyon H6 / Hongyan Jieshi / SAIC IVECO Hongyan / Hongyan Jieshi C100
Chassis Model: CQ3317HL6T / CQ1317SL6Z / CQ1317HL6Z / CQ3257HL4T / CQ1316HMVG27-366 / CQ1316HTVG27-366 / CQ1256HTVG40-474 / CQ1256HMVG33-384 / CQ3315HXG33-366 / CQ3315HTG30-336 / CQ3255HTG40-504
Front axle description: 7.5T / 6.5T / 5.5T
Frame Dimensions: 980_865/280×8+4 / 980_865/280×8 / 980/865/280×8+4 / 980_865/280×80×(8+4) / 940-865/317 8+8mm
rear axle description: HY300(S) / HY300(H) / HY440 / HY300S / HY300H / HY469 / MHY300S / HY320 / 457 rear axle / H8A rear axle / HY300M
Axle ratio: 5.13 / 4.8 / 4.677 / 5.214 / 4.111
Leaf spring count: 9/9/12 / 8/8/12 / 2/4 / 10/10/12 / 3/3/6 / 2/4,3/6,8/12 / 3/3/4,3/3/6,9/9/12,3/3/12,5/5/6 / 3/3/4,3/3/6,9/9/12,3/3/12 / 3/4,3/6,3/12,9/12 / 9/12
Transmission Parameters
Number of gears: 12 / 10 / 9 / 16Gear
Transmission Model: Fast Gear12JSD180T / Fast Gear12JSD160T / Fast Gear10JSD160T / Fast Gear10JSD140A / Fast Gear12JSD160TA / Fast Gear10JSD160A / Fast Gear 12-speed / Fast Gear12JSD180TA / Fast Gear10JSD140 / Fast Gear9JSD150T-B / Fast Gear gearbox / Fast Gear10JSD160
Cab parameters
Cab: Flat roof long / Flat roof standard length / C6 / Flat roof
Tire
Tire Size: 11.00R20 18PR / 11R22.5 18PR295/80R22.5 18PR / 12.00R20 18PR / 11.00R20 / 12R22.5 / 11.00-20,11.00R20,12.00-20 18PR,12.00R20 18PR,295/80R22.5,315/80R22.5 18PR,12R22.5,315/60R22.5 18PR / 11.00R20,12.00R20 16PR / 12.00R20 16PR / 11.00R20 18PR,12.00R20 16PR / 11.00R20 16PR20,12.00R20 14PR / 12.00R20 14PR / 12.00 R20
Number of tires: 12 / 10pcs
FAQ
What kind of truck is SAIC Hongyan SAIC Hongyan Genlyon Heavy Truck concrete mixer truck?
SAIC Hongyan SAIC Hongyan Genlyon Heavy Truck is an export-oriented concrete mixer truck lineup with about 107 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SAIC Hongyan Genlyon Heavy Truck concrete mixer?
SAIC Hongyan Genlyon Heavy Truck concrete mixer export reference is about $43,417 – $69,444. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SAIC Hongyan Genlyon Heavy Truck concrete mixer cover?
SAIC Hongyan Genlyon Heavy Truck concrete mixer mainly covers: Drive: 6x4 / 8x4; Horsepower: 320 hp / 350 hp / 360 hp / 390 hp; Emission: China V / China VI; Fuel: Diesel / LNG (liquefied natural gas). Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SAIC Hongyan Genlyon Heavy Truck concrete mixer?
For SAIC Hongyan Genlyon Heavy Truck concrete mixer: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SAIC Hongyan Genlyon Heavy Truck concrete mixer include?
SAIC Hongyan Genlyon Heavy Truck concrete mixer currently lists about 107 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SAIC Hongyan Genlyon Heavy Truck concrete mixer?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
