Dongfeng T5 270hp 6X4(10 wheels) Truck-Mounted Crane
EXW
From $53,472
Export quote
Dongfeng T5 medium truck truck-mounted crane
Main model photos
176 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng T5 270hp 6X4(10 wheels) Truck-Mounted Crane | 6x4 / 270hp / China VI | From $53,472 | |
| Dongfeng T5 270 hp 6X4(10 wheels) Truck Mounted Crane | 6x4 / 270hp / China VI | From $30,556 | |
| Dongfeng T5 190hp 4X2(6 wheels) 5.8m truck-mounted crane | 4x2 / 190hp / China V | From $39,861 | |
| Dongfeng T5 190hp 4X2(6 wheels) 5.6m truck-mounted crane (Fast Gear) | 4x2 / 190hp / China V | From $34,236 | |
| Dongfeng T5 190hp 4X2(6 wheels) 5.6m truck-mounted crane | 4x2 / 190hp / China V | From $34,653 |
Dongfeng T5 270 hp 6X4(10 wheels) Truck Mounted Crane
EXW
From $30,556
Export quote
Dongfeng T5 190hp 4X2(6 wheels) 5.8m truck-mounted crane
EXW
From $39,861
Export quote
Dongfeng T5 190hp 4X2(6 wheels) 5.6m truck-mounted crane (Fast Gear)
EXW
From $34,236
Export quote
Dongfeng T5 190hp 4X2(6 wheels) 5.6m truck-mounted crane
EXW
From $34,653
Export quote
Series Specs
Basic Info
Cab dimensions: 12×2.55×3.99 / 12×2.55×3.92 / 9×2.5×3.85 / 7.35×2.5×3.85 / 11.95×2.49×3.85 / 10.6×2.49×3.85 / 12×2.49×3.85 / 10.05×2.49×3.85 / 8.535×2.5×3.85 / 8.5×2.55×3.65 / 11.95×2.55×3.65 / 10.65×2.55×3.65 / 11.45×2.49×3.85m
Type: Truck with crane
Drive type: 6X4 / 4X2
Wheelbase: 5850+1350 / 5100 / 4500 / 4350+1300mm
Rated mass: 8.47 / 8.59 / 4.225 / 9.935 / 8.62 / 9.835 / 8.575 / 9.995 / 8.515 / 10ton
GVWR: 25 / 16 / 15.8ton
Front/rear suspension: 1.25/3.355 / 1.25/3.2 / 1.25/2.65 / 1.25/2.15 / 1.45/3.3 / 1.25/3.3 / 1.25/3.15 / 1.45/2.385 / 1.45/3.1 / 1.45/2.45m
Energy Type: Diesel
Body Parameters
Other special notes: Dude 12-ton 4-section boom, boom length 15.8 m / XCMG 14-ton G-type boom, 19.6m boom length
Crane model: SPS15800,SQ114,QYS-6.3III,SQS-6.3III,URV630,nicoleV630 / QYS-10III,SQS-10III,URV1004,SPS25000,KS2305,nicoleV1004 / QYS-10,SQS250,URV1004,SPS25000,KS2305,nicoleV1004 / SQZ300,QYS-12Z / SQS10SK3Q
Lifting capacity: 4.5 / 6 / 10 / 12ton
crane self-weight: 2.102 / 4 / 4.95 / 7.47 / 4.3ton
Vehicle certification code: HDD5251JSQ / EQ5259JSQL6D / EQ5161JSQZMB / EQ5250JSQL1 / EQ5250JSQL / EQ5168JSQLV1 / EQ5250JSQL3
Body Brand: Dongfeng
Engine parameters
Engine Brand: Yuchai / Dongfeng
Engine Model: YuchaiYCS06270-60 / DongfengISB190 50 / YuchaiYC6A270-50 / YuchaiYC6A240-50 / DongfengISB210 50 / DongfengISD245 50 / DongfengISD245 / YuchaiYC6J180-50
Displacement: 6.23 / 5.9 / 7.52 / 6.7 / 6.494L
Emission standard: China VI / China V
Max output power: 199 / 140 / 177 / 155 / 180 / 132kW
Max hp: 270 / 190 / 240 / 210 / 245 / 180Horsepower
Max torque: 1050 / 720 / 1100 / 1000 / 750 / 950 / 650N·m
Max torque speed: 1200-1700 / 1200-1800 / 1300-1700rpm
Rated speed: 2300 / 2500rpm
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Huashen T5
Chassis Model: EQ1256GL6DJ3 / EQ1259GL6DJ / EQ1250GLJ / EQ1168GLJ4
rear axle description: 10t dual rear axle / 153 / 10T
Leaf spring count: 9/13 / 9/11+8,8/10+8,8/11+8,9/10+8,3/4+3 / 9/10,9/13
Transmission Parameters
Number of gears: 9 / 6 / 8Gear
Transmission Model: 9JS119TA / Fast Gear 9-speed / Dongfeng 6-speed / Fast Gear 8-speed / Dongfeng 8-speed
Tire
Tire Size: 11.00R20 18PR / 10.00R20 16PR / 11.00-20 18PR,11.00R20 18PR / 10.00R20
Number of tires: 10 / 6pcs
FAQ
What kind of truck is Dongfeng Dongfeng T5 medium truck truck-mounted crane?
Dongfeng Dongfeng T5 medium truck is an export-oriented truck-mounted crane lineup with about 28 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng T5 medium truck truck-mounted crane?
Dongfeng T5 medium truck truck-mounted crane export reference is about $23,611 – $68,403. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng T5 medium truck truck-mounted crane cover?
Dongfeng T5 medium truck truck-mounted crane mainly covers: Drive: 4x2 / 6x4; Horsepower: 190 hp / 270 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng T5 medium truck truck-mounted crane?
For Dongfeng T5 medium truck truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng T5 medium truck truck-mounted crane include?
Dongfeng T5 medium truck truck-mounted crane currently lists about 28 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng T5 medium truck truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
