Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck

Export reference
MSRP N/A
Fuel: Diesel
Curb Weight:: 7.87ton
Wheelbase:: 3900mm
Tire Size:: 10.00-20
Cab dimensions:: 7.385×2.49×3.65m
Truck Type:: Concrete mixer truck
Rated payload: 7.9ton
Drive 4X2 (6 wheels)
Horsepower 180
Emission China III / Euro III

Overview

The Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck is a concrete mixer truck featuring 7.9t payload, 7.87ton GVW, 4X2 (6 wheels) drive and 7.385×2.49×3.65m cab. On the powertrain side, it comes with 180 hp, China III / Euro III emissions and Diesel fuel.

China III / Euro III 180 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 7.385×2.49×3.65m
Drive type: 4X2
Truck Type: Concrete mixer truck
Wheelbase: 3900mm
Front/rear track width: Front track: 2027mm; Rear track: 1820mm
Vehicle origin: Hunan
Curb Weight: 7.87ton
Rated payload: 7.9ton
Max. speed: 80km/h
Front/rear suspension: 1.42/2.065m
Body Parameters
Water tank capacity: 200L
Slump: 55mm
Mixing drum capacity: 6m³
Drum rotation speed: 6r/min
Feed rate: 3m³/min
Discharge speed: 2m³/min
Discharge residue rate: <0.7%
Filling Rate: 58.7%
water supply method: Air pressure water supply
Vehicle certification code: BJ5162V5PDB-D5
hydraulic system: Closed hydraulic circuit
Engine parameters
Engine Model: Yuchai YC6J180-33
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 6L
Emission standard: China III / Euro III
Max output power: 132kW
Max hp: 180Horsepower
Rated speed: 2500rpm
Engine Type: Inline
Chassis Specs
Chassis Series: Foton
Chassis Model: BJ1162V5PDB-D5
rear axle description: 10T
Leaf spring count: 10/12+9
Transmission Parameters
Number of gears: 8Gear
Transmission Model: Fast Gear 8JS85
Tire
Tire Size: 10.00-20
Number of tires: 6pcs

Photos

Exterior1

Body3

4 photos

FAQ

What emission standard does Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck use, and can it enter my country?

This model is listed as China III / Euro III. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck?

Key specs of Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck: Drive: 4x2; Horsepower: 180 hp; Emission: China III / Euro III; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck suited for?

Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck is a concrete mixer truck model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck differ from other variants in the same series?

Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck belongs to FotonQ5 (concrete mixer truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Foton Ruivo 3 Series 180 hp 4X2(6 wheels) Concrete Mixer Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
