Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck

Export reference
MSRP N/A
Emission: China IV
Fuel: Diesel
Transmission: WLY
Curb Weight:: 2.6ton
Wheelbase:: 3360mm
Tire Size:: 7.50R16LT 6PR,8.25R16LT 6PR
Rated payload: 1.495ton
Drive 4X2 (6 wheels)
Horsepower 113
Cargo box type: Rear-dump body

Overview

The Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck is a Light Truck featuring 1.495t payload, 4.29t GVW, Rear-dump body cargo body and 4X2 (6 wheels) drive. On the powertrain side, it comes with a ChaochaiCY4102-CE4D engine, 113 hp, China IV emissions and WLY transmission.

China IV 113 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): ZZ3047E3415D143
Drive type: 4X2
Wheelbase: 3360mm
engine: ChaochaiCY4102-CE4D
transmission: WLYWLY1046
Rear Axle Ratio: 5.286
Cab length: 5.995m
Cab width: 2.25m
Cab height: 2.45m
Front track width: 1780mm
rear track: 1605mm
Curb Weight: 2.6ton
Rated payload: 1.495ton
GVWR: 4.29ton
Origin: Jinan, Shandong
tonnage class: Light Truck
Approach angle: 20°
departure angle: 18°
Energy Type: Diesel
Engine parameters
Engine Brand: Chaochai
Engine Model: ChaochaiCY4102-CE4D
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 3.856L
Emission standard: China IV
Max output power: 83kW
Max hp: 113Horsepower
Max torque: 300N·m
Max torque speed: 1300-1500rpm
Rated speed: 2800rpm
Engine Type: Vertical in-line, water-cooled, 4-stroke, turbocharged & intercooled, electronic high-pressure common rail
Technology route: High-pressure common rail DOC POC
Transmission Parameters
Transmission Model: WLYWLY1046
Transmission Brand: WLY
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Rear-dump body
Cargo box type: Rear-dump body
Cargo box length: 4.15m
Cargo box width: 2.05m
Cargo box height: 0.5m
fuel tank
Fuel tank capacity: 120L
Chassis Specs
Front axle allowable load: 1750kg
Frame Dimensions: 195×65×(6+4)mm
rear axle description: 1080 reinforced rear axle
rear axle allowable load: 2540kg
Axle ratio: 5.286
Leaf spring count: 11/9+7
Tire
Tire Size: 7.50R16LT 6PR,8.25R16LT 6PR
Number of tires: 6pcs

Photos

0 photos

FAQ

What emission standard does Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck?

Key specs of Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck: Drive: 4x2; Horsepower: 113 hp; Emission: China IV; Fuel: Diesel; Transmission: WLY. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck suited for?

Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck differ from other variants in the same series?

Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck belongs to Sinotruk Hanjiang Light Truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sinotruk HOWO Hanvo 113 hp 4X2(6 wheels) 4.2m dump truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
