Dayun F Series Medium Truck 220 hp 6X2(8 wheels) 5.2m Dump Truck
EXW
From $31,806
Export quote
Dayun F-series medium-duty truck Dump Trucks
Main model photos
9 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dayun F Series Medium Truck 220 hp 6X2(8 wheels) 5.2m Dump Truck | 6x2 / 220hp / China V | From $31,806 | |
| Dayun F-Series Medium Truck 180 hp 4X2(6 wheels) 4.2m Dump Truck | 4x2 / 180hp / China V | ||
| Dayun F Series Medium Truck 180hp 6X2(8 wheels) 4.8m Dump Truck | 6x2 / 180hp / China V | From $29,167 | |
| Dayun F-Series Medium Truck 185 hp 6X2(8 wheels) 4.8m Dump Truck | 6x2 / 185hp / China V | ||
| Dayun F-Series Medium Truck 180 hp 4X2(6 wheels) 4.2m Dump Truck | 4x2 / 180hp / China V |
Dayun F-Series Medium Truck 180 hp 4X2(6 wheels) 4.2m Dump Truck
EXW
Export quote
Dayun F Series Medium Truck 180hp 6X2(8 wheels) 4.8m Dump Truck
EXW
From $29,167
Export quote
Dayun F-Series Medium Truck 185 hp 6X2(8 wheels) 4.8m Dump Truck
EXW
Export quote
Dayun F-Series Medium Truck 180 hp 4X2(6 wheels) 4.2m Dump Truck
EXW
Export quote
Series Specs
Basic Info
Model code (announced): DYQ3252D5CB / DYQ3182D5AB / DYQ3251D5CB / DYQ3162D5AB / DYQ3122D5AB
Drive type: 6X2 / 4X2
Wheelbase: 1800+3000 / 3600 / 1800+2700 / 3750mm
Engine Model: YuchaiYC4EG220-50 / YuchaiYC6JA180-50 / YuchaiYC4EG185-50 / YuchaiYC4E160-56
Transmission Model: Fast Gear 10-Speed / Fast Gear8JS85E / Fast Gear10JS90A / Fast Gear8JS85F
Rear Axle Ratio: 6.333 / 4.875 / 6.833
Cab length: 7.9 / 6.65 / 7.5 / 7.65 / 6.8 / 6.9 / 7.05m
Cab width: 2.45 / 2.35 / 2.55 / 2.4m
Cab height: 2.95 / 3.3 / 3.05m
Front track width: 1825/1825 / 1825 / 1875/1875 / 1800 / 1875mm
rear track: 1750 / 1700 / 1800 / 1860mm
Curb Weight: 9.3 / 7.81 / 9.2 / 8.5 / 7.95 / 6.805ton
Rated payload: 15.005 / 9.995 / 15.605 / 15.805 / 7.855 / 4.99ton
GVWR: 24.5 / 18 / 25 / 16 / 11.99ton
Origin: Chengdu, Sichuan / Shiyan, Hubei
tonnage class: Light Truck / Medium-duty truck
Approach angle: 24 / 13 / 22 / 18°
departure angle: 23 / 25 / 27 / 18 / 19°
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Number of cylinders: 4 / 6cylinder
Displacement: 4.73 / 6.87 / 4.26L
Emission standard: China V
Max output power: 160 / 132 / 136 / 118kW
Max hp: 220 / 180 / 185 / 160Horsepower
Max torque: 800 / 700 / 600N·m
Max torque speed: 1300-1700 / 1200-1800 / 1300-1800 / 1300-1600rpm
Rated speed: 2500 / 2300 / 2600rpm
Engine Type: Vertical, inline, water-cooled, four-stroke, high-pressure common rail / Vertical, inline, water-cooled, four-stroke
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 10 / 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
hydraulic cylinder brand & model: 160
Unloading Type: Rear-dump body / Dump type
Cargo box length: 5.2 / 4.2 / 4.8 / 4.45m
Cargo box width: 2.3 / 2.2m
Cargo box height: 1.5 / 0.8 / 1.3m
Cab parameters
Cab: Fengjing / New Fengjing / Dayun Fengjing
fuel tank
Fuel tank material: aluminum alloy / Iron
FAQ
What kind of truck is Dayun Dayun F-series medium-duty truck Dump Trucks?
Dayun Dayun F-series medium-duty truck is an export-oriented Dump Trucks lineup with about 7 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dayun F-series medium-duty truck Dump Trucks?
Dayun F-series medium-duty truck Dump Trucks export reference is about $26,111 – $31,806. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dayun F-series medium-duty truck Dump Trucks cover?
Dayun F-series medium-duty truck Dump Trucks mainly covers: Drive: 4x2 / 6x2; Horsepower: 180 hp / 185 hp / 220 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dayun F-series medium-duty truck Dump Trucks?
For Dayun F-series medium-duty truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Dayun F-series medium-duty truck Dump Trucks include?
Dayun F-series medium-duty truck Dump Trucks currently lists about 7 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dayun F-series medium-duty truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
