Sinotruk Warrior M1 2.4L Diesel 169hp 4X2(6 wheels) Fast Gear 10-speed 3.15m single-row dump truck
EXW
From $21,944
Export quote
Sinotruk Warrior M1 Dump Trucks
Main model photos
57 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Warrior M1 2.4L Diesel 169hp 4X2(6 wheels) Fast Gear 10-speed 3.15m single-row dump truck | 4x2 / 169hp / China VI | From $21,944 | |
| Sinotruk Yongshi M1 2.4L Diesel 169hp 4X2(6 wheels) Fast Gear 8-Speed 3.2m Single-Row Dump Truck | 4x2 / 169hp / China VI | From $21,944 | |
| Sinotruk Yongshi M1 2.5L Diesel 175hp 4X2(6 wheels) Fast Gear 10-speed 3.2m Dump Truck | 4x2 / 175hp / China VI | From $20,556 | |
| Sinotruk Warrior M1 160 hp 4X2(6 wheels) WLY 8-speed 3.2m dump truck | 4x2 / 160hp / China VI | From $19,167 | |
| Sinotruk Warrior M1 2.5L Diesel 155hp 4X2(6 wheels) WLY 8-Speed 4.15m Dump Truck | 4x2 / 155hp / China VI | From $13,611 |
Sinotruk Yongshi M1 2.4L Diesel 169hp 4X2(6 wheels) Fast Gear 8-Speed 3.2m Single-Row Dump Truck
EXW
From $21,944
Export quote
Sinotruk Yongshi M1 2.5L Diesel 175hp 4X2(6 wheels) Fast Gear 10-speed 3.2m Dump Truck
EXW
From $20,556
Export quote
Sinotruk Warrior M1 160 hp 4X2(6 wheels) WLY 8-speed 3.2m dump truck
EXW
From $19,167
Export quote
Sinotruk Warrior M1 2.5L Diesel 155hp 4X2(6 wheels) WLY 8-Speed 4.15m Dump Truck
EXW
From $13,611
Export quote
Series Specs
Basic Info
Model code (announced): ZZ3048G17FB6 / ZZ3048F17FB5 / ZZ3128F17FB2
Drive type: 4X2
Wheelbase: 2850 / 3280 / 2600mm
Engine Model: WeichaiWP2.5T180E62A / YuchaiYCF25175-66 / YuchaiYCF25160-66A / Yunnei PowerYN25PLUS160A / YuchaiYCF25160-66 / WeichaiWP2.3Q140E62 / WeichaiWP25Q151E62 / WP2.5T180E62A / YCF25175-66 / YCF25160-66A / YN25PLUS160A
Transmission Model: Fast Gear10JS90-B / Fast Gear8JS85TE-C / WLYWLY8GS60 / WLYWLY8G45 / WLYWLY8GS46B / 10JS90-B / 8JS85TE-C / WLY8GS60
Rear Axle Ratio: 5.833 / 4.875 / 5.286 / 6.833 / 6.166
Cab length: 4.995 / 5.995m
Cab width: 1.98 / 2.15 / 1.95 / 1750m
Cab height: 2.4 / 2.1 / 2.17 / 2.18 / 2.08m
Front track width: 1615 / 1530 / 1740 / 1501mm
rear track: 1540 / 1585 / 1650 / 1445mm
Curb Weight: 2.72 / 6.83ton
Rated payload: 1.58 / 4.93 / 1.645ton
GVWR: 4.495 / 11.955ton
Origin: Yong'an, Fujian
tonnage class: Light Truck
Approach angle: 20°
departure angle: 16°
Version: Underground Garage Version
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai / Yuchai / Yunnei Power
Number of cylinders: 4cylinder
Displacement: 2.445 / 2.488 / 2.499 / 2.289L
Emission standard: China VI
Max output power: 124 / 127 / 116 / 114 / 103 / 109kW
Max hp: 169 / 175 / 160 / 155 / 140 / 151Horsepower
Max torque: 420 / 320 / 340N·m
Max torque speed: 1400-2300 / 1400-2400 / 2200-2400rpm
Rated speed: 3300 / 3200rpm
Engine Type: High-pressure common rail / High-pressure common rail+Hi-SCR
Transmission Parameters
Transmission Brand: Fast Gear / WLY
shift method: Manual
Forward gears: 10 / 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type
Cargo box type: stake body / Dump type
Cargo box length: 3.15 / 3.2 / 4.15 / 3.18 / 3m
Cargo box width: 1.8 / 1.75 / 2.05m
Cargo box height: 0.8 / 0.5m
Body Parameters
Lifting type: 110 dual lift cylinders
FAQ
What kind of truck is Sinotruk Sinotruk Warrior M1 Dump Trucks?
Sinotruk Sinotruk Warrior M1 is an export-oriented Dump Trucks lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk Warrior M1 Dump Trucks?
Sinotruk Warrior M1 Dump Trucks export reference is about $13,611 – $21,944. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk Warrior M1 Dump Trucks cover?
Sinotruk Warrior M1 Dump Trucks mainly covers: Drive: 4x2; Horsepower: 155 hp / 160 hp / 169 hp / 175 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk Warrior M1 Dump Trucks?
For Sinotruk Warrior M1 Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk Warrior M1 Dump Trucks include?
Sinotruk Warrior M1 Dump Trucks currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk Warrior M1 Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
