Sinotruk Steyr D5 340 hp 8X4(12 wheels) 6m dump truck
EXW
From $33,472
Export quote
Sinotruk Steyr D5 Heavy Truck Dump Trucks
Main model photos
4 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Steyr D5 340 hp 8X4(12 wheels) 6m dump truck | 8x4 / 340hp / China V | From $33,472 | |
| Sinotruk Steyr D5W 220 hp 4X2(6 wheels) 4.7m Dump Truck | 4x2 / 220hp / China VI | From $33,056 | |
| Sinotruk Steyr D5W 350 hp 8X4(12 wheels) 6.5m Dump Truck (MAN 16t) | 8x4 / 350hp / China VI | From $47,681 | |
| Sinotruk Steyr D5W 350 hp 8X4(12 wheels) 6.5 m dump truck (axle ratio 5.32) | 8x4 / 350hp / China VI | From $47,639 | |
| Sinotruk Steyr D5W 350 hp 8X4(12 wheels) 6 m dump truck (MAN 16t) | 8x4 / 350hp / China VI | From $47,569 |
Sinotruk Steyr D5W 220 hp 4X2(6 wheels) 4.7m Dump Truck
EXW
From $33,056
Export quote
Sinotruk Steyr D5W 350 hp 8X4(12 wheels) 6.5m Dump Truck (MAN 16t)
EXW
From $47,681
Export quote
Sinotruk Steyr D5W 350 hp 8X4(12 wheels) 6.5 m dump truck (axle ratio 5.32)
EXW
From $47,639
Export quote
Sinotruk Steyr D5W 350 hp 8X4(12 wheels) 6 m dump truck (MAN 16t)
EXW
From $47,569
Export quote
Series Specs
Basic Info
Model code (announced): CDW3313N3661E1BN / ZZ3184K4117F1 / ZZ3314N3667F1B
Drive type: 8X4 / 4X2
Wheelbase: 1800+3200+1350 / 3950 / 1800+3400+1350 / 1800+3050+1350 / 1800+2550+1350 / 1800+3600+1350mm
Engine Model: WeichaiWP8.340E51 / WeichaiWP4.6NQ220E61A / WeichaiWP8.350E61 / WP8.350E61 / WeichaiWP7.300E61
Transmission Model: SinotrukHW15710 / Fast Gear 10-Speed / SinotrukHW15710CL
Rear Axle Ratio: 5.143 / 4.875 / 5.32 / 5.262
Cab length: 9.3 / 7.25 / 8.8 / 8.6 / 9.8 / 8.4m
Cab width: 2.55 / 2.46 / 2.51 / 2260m
Cab height: 3.08 / 3.5m
Front track width: 2020/2020 / 1965/1965mm
rear track: 1860/1860 / 1800/1800mm
Curb Weight: 12.8 / 8.2ton
Rated payload: 18.07 / 8.805ton
GVWR: 31 / 18ton
Origin: Chengdu, Sichuan
tonnage class: Heavy truck / Light Truck
Approach angle: 17 / 15°
departure angle: 15°
Remarks: Transmission HW15710CL+HW50 direct connection; central lock + remote; A/C; air suspension seat / Transmission HW15710CL+HW50 direct connection;
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai
Number of cylinders: 6 / 4cylinder
Displacement: 7.8 / 4.58 / 7.5L
Emission standard: China V / China VI
Max output power: 250 / 162 / 257 / 220kW
Max hp: 340 / 220 / 350 / 300 / 349Horsepower
Max torque: 1400 / 850 / 1300N·m
Max torque speed: 1200-1700 / 1300-1600 / 1200-1600rpm
Rated speed: 2100 / 2300rpm
Engine Type: High-pressure common rail+EGR / Common Rail+EGR+DOC+DPF+SCR / Inline 6-cylinder, water-cooled, 4-stroke, high-pressure common rail, turbocharged intercooled, EGR / CR+EGR+DOC+DPF+SCR
Transmission Parameters
Transmission Brand: Sinotruk / Fast Gear
shift method: Manual
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Rear-dump body / Dump type
Cargo box length: 6.5 / 4.7 / 6 / 5.8 / 7 / 5.6m
Cargo box width: 2.35 / 2.3 / 2.4m
Cargo box height: 1.5 / 0.8 / 1.2m
Cab parameters
Cab suspension: Four-point air suspension
Cab tilting: Electric
FAQ
What kind of truck is Sinotruk Sinotruk Steyr D5 Heavy Truck Dump Trucks?
Sinotruk Sinotruk Steyr D5 Heavy Truck is an export-oriented Dump Trucks lineup with about 18 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk Steyr D5 Heavy Truck Dump Trucks?
Sinotruk Steyr D5 Heavy Truck Dump Trucks export reference is about $33,056 – $47,722. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk Steyr D5 Heavy Truck Dump Trucks cover?
Sinotruk Steyr D5 Heavy Truck Dump Trucks mainly covers: Drive: 4x2 / 8x4; Horsepower: 220 hp / 340 hp / 350 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk Steyr D5 Heavy Truck Dump Trucks?
For Sinotruk Steyr D5 Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk Steyr D5 Heavy Truck Dump Trucks include?
Sinotruk Steyr D5 Heavy Truck Dump Trucks currently lists about 18 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk Steyr D5 Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
