Sinotruk Fulong H5 Heavy Truck 280 hp 8X4(12 wheels) 7.4m Dump Truck
EXW
Export quote
Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks
Main model photos
18 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Fulong H5 Heavy Truck 280 hp 8X4(12 wheels) 7.4m Dump Truck | 8x4 / 280hp / China IV | ||
| Sinotruk Fulong H5 Heavy Truck 240 hp 8X2(10 wheels) 6.5m Dump Truck (Chassis) | 8x2 / 240hp / China III / Euro III |
Sinotruk Fulong H5 Heavy Truck 240 hp 8X2(10 wheels) 6.5m Dump Truck (Chassis)
EXW
Export quote
Series Specs
Basic Info
Model code (announced): ZZ3318M60DB0 / ZZ3318KM0DK0
Drive type: 8X4 / 8X2
Wheelbase: 1800+3400+1350 / 1800+2750+1700mm
Transmission Model: SinotrukHW13710 / SinotrukHW12710C
Cab length: 10.3 / 9.36m
Cab width: 2.49 / 2.495m
Cab height: 3.45m
Front track width: 2020/2020mm
rear track: 1860/1860 / 2020/1860mm
Curb Weight: 14.82 / 14.765ton
Rated payload: 16.05 / 16.04ton
GVWR: 31ton
Origin: Fujian Haixi
tonnage class: Heavy truck
Approach angle: 18.5°
departure angle: 15 / 21°
Energy Type: Diesel
Engine parameters
Engine Brand: Sinotruk / Yuchai
Engine Model: SinotrukMC07.28-40 / YuchaiYC6A240-33
Number of cylinders: 6cylinder
Displacement: 6.87 / 7.255L
Emission standard: China IV / China III / Euro III
Max output power: 206 / 177kW
Max hp: 280 / 240Horsepower
Max torque: 1100 / 900N·m
Max torque speed: 1200-1800 / 1400-1600rpm
Rated speed: 2300rpm
Engine Type: Inline, water-cooled, 4-stroke, turbocharged with intercooler / Vertical, inline, water-cooled, four-stroke, electronically controlled direct injection
Transmission Parameters
Transmission Brand: Sinotruk
shift method: Manual
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Rear-dump body / Dump type
Cargo box length: 7.4 / 6.5m
Cargo box width: 2.3m
Cargo box height: 1.1 / 1.29m
fuel tank
Fuel tank capacity: 380L
Chassis Specs
rear axle description: EQ153/457
rear axle allowable load: 17950 / 11000kg
Leaf spring count: 12/12/10,12/12/- / 12/12/3+-/12+9
FAQ
What kind of truck is Sinotruk Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks?
Sinotruk Sinotruk Fulou H5 Quasi-Heavy Truck is an export-oriented Dump Trucks lineup with about 2 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks cover?
Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks mainly covers: Drive: 8x2 / 8x4; Horsepower: 240 hp / 280 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks?
For Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks include?
Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks currently lists about 2 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk Fulou H5 Quasi-Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
