Sinotruk V1 Series 2.5L Diesel 176hp 4X2(6 wheels) Fast Gear 10-Speed 3.15m Single Row Dump Truck
EXW
From $15,972
Export quote
SinotrukV1 Dump Trucks
Main model photos
25 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk V1 Series 2.5L Diesel 176hp 4X2(6 wheels) Fast Gear 10-Speed 3.15m Single Row Dump Truck | 4x2 / 176hp / China VI | From $15,972 | |
| Sinotruk V1 Series 2.5L Diesel 175hp 4X2(6 wheels) Fast Gear 10-Speed 3.15m Single Row Dump Truck | 4x2 / 175hp / China VI | From $15,972 | |
| Sinotruk V1 2.5L Diesel 185hp 4X2(6 wheels) Fast Gear 10-Speed 3.15m Single-Cab Dump Truck | 4x2 / 185hp / China VI | From $17,361 | |
| Sinotruk V1 2.5L Diesel 170hp 4X2(6 wheels) Fast Gear 8-Speed 3.15m Single-Cab Dump Truck | 4x2 / 170hp / China VI | From $16,667 | |
| Sinotruk V1 2.5L Diesel 155hp 4X2(6 wheels) Fast Gear 8-Speed 3.15m Single Row Dump Truck | 4x2 / 155hp / China VI | From $13,167 |
Sinotruk V1 Series 2.5L Diesel 175hp 4X2(6 wheels) Fast Gear 10-Speed 3.15m Single Row Dump Truck
EXW
From $15,972
Export quote
Sinotruk V1 2.5L Diesel 185hp 4X2(6 wheels) Fast Gear 10-Speed 3.15m Single-Cab Dump Truck
EXW
From $17,361
Export quote
Sinotruk V1 2.5L Diesel 170hp 4X2(6 wheels) Fast Gear 8-Speed 3.15m Single-Cab Dump Truck
EXW
From $16,667
Export quote
Sinotruk V1 2.5L Diesel 155hp 4X2(6 wheels) Fast Gear 8-Speed 3.15m Single Row Dump Truck
EXW
From $13,167
Export quote
Series Specs
Basic Info
Model code (announced): CDW3044G281CFH / CDW3044C281CFH / CDW3144G321BFA
Drive type: 4X2
Wheelbase: 2800 / 3200mm
Engine Model: Yunnei PowerYN25PLUS180 / YuchaiYCF25175-66 / WeichaiWP2.5NQ190E62 / Yunnei PowerYN25PLUS170 / Yunnei PowerYN25PLUS160A / YuchaiYCF25160-66A / YuchaiYCF25165-66A / WeichaiWP2.5NQ170E62 / WeichaiWP2.3Q140E62 / Yunnei Power490PLUS1 / YN25PLUS180 / YCF25175-66 / WP2.5NQ190E62 / YN25PLUS170 / YN25PLUS160A
Transmission Model: Fast Gear 10-Speed / Fast Gear 8-speed / Fast Gear8J45T / WLYWLY8GS46 / 10-speed / 8-speed / 8J45T / WLY8GS46
Rear Axle Ratio: 6.33 / 5.833 / 5.286 / 4.875 / 4.88
Cab length: 4.995 / 5.925 / 4.99m
Cab width: 1.9 / 1.97 / 2.36 / 1760m
Cab height: 2.39 / 2.215 / 2.3 / 2.58 / 2.33 / 2.115m
Front track width: 1605 / 1650mm
rear track: 1585 / 1570 / 1550 / 1580 / 1610mm
Curb Weight: 2.72 / 4.5ton
Rated payload: 1.645 / 9.17ton
GVWR: 4.495 / 13.8ton
Origin: Chengdu, Sichuan
tonnage class: Light Truck / Medium-duty truck
Approach angle: 17°
departure angle: 17°
Remarks: Standard: Cab tilt, cab suspension
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power / Yuchai / Weichai
Number of cylinders: 4cylinder
Displacement: 2.499 / 2.488 / 2.493 / 2.289L
Emission standard: China VI
Max output power: 129 / 127 / 136 / 125 / 114 / 116 / 120 / 103 / 105kW
Max hp: 176 / 175 / 185 / 170 / 155 / 160 / 165 / 140 / 143Horsepower
Max torque: 420 / 500 / 320 / 400N·m
Max torque speed: 1400-2300 / 1400-1800 / 1600-2400 / 1300-2400rpm
Rated speed: 3300 / 2900 / 3200 / 3000rpm
Engine Type: Common Rail+DOC+DPF+SCR / High-pressure common rail+Hi-SCR / High-pressure common rail
Transmission Parameters
Transmission Brand: Fast Gear / WLY
shift method: Manual
Forward gears: 10 / 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
hydraulic cylinder brand & model: 90 / Dual straight 90×900
Unloading Type: Dump type / Rear dump / Rear-dump body
Cargo box length: 3.15 / 2.9 / 3.8 / 2.7 / 3.1m
Cargo box width: 1.8 / 2.2m
Cargo box height: 0.8 / 0.6m
Body Parameters
Lifting type: Double Lift Cylinder
FAQ
What kind of truck is Sinotruk SinotrukV1 Dump Trucks?
Sinotruk SinotrukV1 is an export-oriented Dump Trucks lineup with about 17 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SinotrukV1 Dump Trucks?
SinotrukV1 Dump Trucks export reference is about $11,250 – $17,361. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SinotrukV1 Dump Trucks cover?
SinotrukV1 Dump Trucks mainly covers: Drive: 4x2; Horsepower: 155 hp / 170 hp / 175 hp / 176 hp / 185 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SinotrukV1 Dump Trucks?
For SinotrukV1 Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SinotrukV1 Dump Trucks include?
SinotrukV1 Dump Trucks currently lists about 17 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SinotrukV1 Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
