Sinotruk HOWO A7 Series Heavy Truck 420 hp 6X4(10 wheels) Dump Truck Chassis (Export Model)
EXW
Export quote
Sinotruk HOWO A7 Heavy Truck Dump Trucks
Main model photos
83 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk HOWO A7 Series Heavy Truck 420 hp 6X4(10 wheels) Dump Truck Chassis (Export Model) | 6x4 / 420hp / China IV | ||
| Sinotruk HOWO heavy truck 380 hp 6X4(10 wheels) 7.3m dump truck | 8x4 / 380hp / China IV | ||
| Sinotruk HOWO Heavy Truck 380hp 6X4(10 wheels) 5.6m dump truck | 6x4 / 380hp / China IV | From $52,500 | |
| Sinotruk HOWO A7 Series Heavy Truck 340hp 6X4(10 wheels) 8.48m Dump Truck | 6x4 / 340hp / China III / Euro III | From $54,667 | |
| Sinotruk HOWO A7 Heavy Truck 340 hp 6X4(10 wheels) 5.4m Dump Truck | 6x4 / 340hp / China III / Euro III | From $49,278 |
Sinotruk HOWO heavy truck 380 hp 6X4(10 wheels) 7.3m dump truck
EXW
Export quote
Sinotruk HOWO Heavy Truck 380hp 6X4(10 wheels) 5.6m dump truck
EXW
From $52,500
Export quote
Sinotruk HOWO A7 Series Heavy Truck 340hp 6X4(10 wheels) 8.48m Dump Truck
EXW
From $54,667
Export quote
Sinotruk HOWO A7 Heavy Truck 340 hp 6X4(10 wheels) 5.4m Dump Truck
EXW
From $49,278
Export quote
Series Specs
Basic Info
Model code (announced): ZZ3257V3647P1 / ZZ3317N3567P1 / ZZ3257N3847P1 / ZZ1257N5847N1 / ZZ3257N3647N2 / ZZ3257M3647N2 / ZZ3257N3447N1 / ZZ3257M3447N1 / ZZ3257N3247N1 / ZZ3257M3247N1 / ZZ3257N3047N2 / ZZ3257M3047N2 / ZZ3317N4667N1 / ZZ3257N4147N1
Drive type: 6X4 / 8X4
Wheelbase: 1950+3525+1350 / 3825+1350 / 5800+1400 / 3625+1350 / 3425+1350 / 3225+1350 / 2975+1350 / 1950+4625+1350 / 4125+1350mm
Engine Model: SinotrukD12.42-40 / SinotrukD10.38-40 / SinotrukD10.34-31 / SinotrukD10.30-31 / SinotrukD10.38-30 / SinotrukD10.27-31 / SinotrukWD615.96E / SinotrukD10.34 / D10.34-31
Transmission Model: SinotrukHW19710T / SinotrukHW19710 / SinotrukHW19712 / SinotrukHW20716A / SinotrukHW15710
Rear Axle Ratio: 5.45 / 4.77
Cab length: 10.36 / 8.585 / 11.985 / 8.215 / 8.065 / 7.665 / 7.445 / 11.365 / 8.835m
Cab width: 2.496m
Cab height: 3.49 / 3.12m
Front track width: 2022/2022 / 2022 / 2022/2041 / 2022,2041mm
rear track: 1830/1830mm
Curb Weight: 15.2 / 12.3 / 11.8 / 12.27 / 12.17 / 11.95 / 11.94 / 15.5 / 12.37ton
Rated payload: 15.67 / 12.57 / 13.07 / 12.6 / 12.7 / 12.9 / 15.37 / 12.5ton
GVWR: 31 / 25ton
Origin: Jinan, Shandong
tonnage class: Heavy truck
Approach angle: 20 / 15°
departure angle: 23 / 24 / 9 / 27 / 26 / 29 / 25°
Remarks: This vehicle is optionally equipped with an A7-W cab, overall height 3640mm. / Alternate engine: D10.38. Dump type: rear dump. Cab: A7-B. Alternate vehicle length: 8.265 m. Alternate cargo body dimensions: 5.6*2.3*1.15 / Alternate engine: D10.27. Dump type: rear dump. Cab: A7-B. Alternate vehicle length: 8.265 m. Alternate cargo body dimensions: 5.6*2.3*1.15 / Alternate engine: D10.34. Dump type: rear dump. Cab: A7-W / Alternate engine: D10.30. Dump type: rear dump. Cab: A7-W / Alternate engine: D10.38. Dump type: rear dump. Cab: A7-W / Alternate engine: D10.27. Dump type: rear dump. Cab: A7-W / Alternate engine: D10.30. Dump type: rear dump. Cab: A7-B / The dumping method of this vehicle is rear dump. Vehicle length, body length, and rear overhang parameters correspond one-to-one. Body lengths of 8000mm and 8200mm correspond to a body height of 1000mm; body length of 8500mm corresponds to a body height of 950mm. Rear overhangs of 1900mm and 2000mm correspond to a departure angle of 24°, and rear overhang of 2200mm corresponds to a departure angle of 22°.
Energy Type: Diesel
Engine parameters
Engine Brand: Sinotruk
Number of cylinders: 6cylinder
Displacement: 11.596 / 9.726L
Emission standard: China IV / China III / Euro III
Max output power: 309 / 276 / 250 / 221 / 279 / 198kW
Max hp: 420 / 380 / 340 / 300 / 270 / 375Horsepower
Max torque: 1820 / 1560 / 1490 / 1340 / 1590 / 1190 / 1500N·m
Max torque speed: 1100-1400 / 1200-1500 / 1100-1600rpm
Rated speed: 2000 / 1900 / 2200rpm
Engine Type: Inline, water-cooled, 4-stroke, turbocharged with intercooler / Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail / Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, electronic fuel injection pump, EGR
Transmission Parameters
Transmission Brand: Sinotruk
shift method: Manual / AMT manual/auto
Forward gears: 10 / 12 / 16Gear
Number of Reverse Gears: 2 / 4pcs
Cargo box parameters
Seal cover type: none
Unloading Type: Dump type / Rear-dump body
Cargo box type: square box / Dump type / Rear-dump body
Cargo box length: 7.3 / 5.6 / 8.48 / 5.4 / 5.2 / 4.8 / 8.5 / 5.8m
Cargo box width: 2.3 / 2.326m
Cargo box height: 1.1 / 0.6 / 1.2 / 1.25 / 1.4 / 1m
FAQ
What kind of truck is Sinotruk HOWO Sinotruk HOWO A7 Heavy Truck Dump Trucks?
Sinotruk HOWO Sinotruk HOWO A7 Heavy Truck is an export-oriented Dump Trucks lineup with about 15 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk HOWO A7 Heavy Truck Dump Trucks?
Sinotruk HOWO A7 Heavy Truck Dump Trucks export reference is about $47,611 – $60,139. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk HOWO A7 Heavy Truck Dump Trucks cover?
Sinotruk HOWO A7 Heavy Truck Dump Trucks mainly covers: Drive: 6x4 / 8x4; Horsepower: 340 hp / 380 hp / 420 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk HOWO A7 Heavy Truck Dump Trucks?
For Sinotruk HOWO A7 Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk HOWO A7 Heavy Truck Dump Trucks include?
Sinotruk HOWO A7 Heavy Truck Dump Trucks currently lists about 15 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk HOWO A7 Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
