SHACMAN Xuande X3 385hp 8X4(12 wheels) 5.8m Dump Truck
EXW
From $54,708
Export quote
SHACMAN Commercial Vehicle SHACMAN Xuande X3
Main model photos
184 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Xuande X3 385hp 8X4(12 wheels) 5.8m Dump Truck | 8x4 / 385hp / China V | From $54,708 | |
| SHACMAN Commercial Vehicle Xuande X3 Standard Load Edition 385 hp 6X4(10 wheels) 5.6m Dump Truck (10-speed) | 6x4 / 385hp / China V | From $47,431 | |
| SHACMAN Cummins Xuande X3 Enhanced Edition 345 hp 8X4(12 wheels) 5.6m Dump Truck | 8x4 / 345hp / China V | From $42,986 | |
| SHACMAN Commercial Vehicle Xuande X3 Enhanced Edition 385hp 8X4(12 wheels) 5.6m Dump Truck | 8x4 / 385hp / China V | From $51,264 | |
| SHACMAN Commercial Vehicle Xuande X3 Enhanced Edition 385 hp 6X4(10 wheels) 5.8m dump truck | 6x4 / 385hp / China V | From $49,667 |
SHACMAN Commercial Vehicle Xuande X3 Standard Load Edition 385 hp 6X4(10 wheels) 5.6m Dump Truck (10-speed)
EXW
From $47,431
Export quote
SHACMAN Cummins Xuande X3 Enhanced Edition 345 hp 8X4(12 wheels) 5.6m Dump Truck
EXW
From $42,986
Export quote
SHACMAN Commercial Vehicle Xuande X3 Enhanced Edition 385hp 8X4(12 wheels) 5.6m Dump Truck
EXW
From $51,264
Export quote
SHACMAN Commercial Vehicle Xuande X3 Enhanced Edition 385 hp 6X4(10 wheels) 5.8m dump truck
EXW
From $49,667
Export quote
Series Specs
Basic Info
Model code (announced): SX3310MB246 / SX3250MP5364 / SX5310ZLJMB246 / SX5310ZLJMB246B / SX5250ZLJMB3842 / SX5250ZLJMB384 / SX3250MB3841B / SX3250MB3542B / SX3310MP5326 / SX3310MB406 / SX3310MB366 / SX3310MB326 / SX3310MP5406 / SX3310MP5366 / SX3310MP53261 / SX3310MP5366N / SX3254MP5 / SX3253MP5 / SX3252MP5 / SX3312MP5 / SX3311MP4 / SX3310MP4 / SX3312MP4 / SX3314MP4 / SX3316GP4 / SX3314GP3 / SX3250MP3
Drive type: 8X4 / 6X4
Wheelbase: 1800+2375+1400 / 3575+1400 / 3975+1400 / 3775+1400 / 1800+3175+1400 / 1800+3975+1400 / 1800+3575+1400 / 1800+3575+1350 / 3975+1350 / 3575+1350 / 1800+3175+1300 / 1800+3450+1300 / 1800+3000+1300 / 1800+3600+1350 / 1800+3450+1350 / 1800+3000+1350 / 1800+2975+1350 / 1800+2975+1300 / 1800+2550+1300 / 1800+3850+1300 / 3850mm
Engine Model: Xi’an CumminsISM11E5 385 / YuchaiYC6MK385-50 / Xi’an CumminsISM11E5 345 / YuchaiYC6MK420-50 / YuchaiYC6MK375N-50 / WeichaiWP7.300E51 / YuchaiYC6MK320-40 / YuchaiYC6L310-42 / YuchaiYC6L290-42 / WeichaiWP10.336E40 / WeichaiWP10.310E41 / WeichaiWP7.270E40 / YuchaiYC6A270-46 / YuchaiYC6A260-33 / WeichaiWP10.310E32
Transmission Model: Fast Gear12JSD180T / Fast Gear10JSD180 / Fast Gear10JSD180T / Fast Gear12JSD200T / Fast Gear10JSD160B / Fast Gear10JSD140 / Fast Gear10JSD180B / Fast Gear10JSD140B / Fast Gear10JSD120B / Fast Gear9JS119B / Fast Gear9JS135
Rear Axle Ratio: 5.73 / 6.733 / 5.262 / 5.286 / 4.769 / 5.571
Cab length: 8.4 / 8.395 / 8.36 / 8.6 / 8.2 / 9.32 / 10.65 / 10.25 / 9.55 / 10.4 / 10.2 / 10 / 9.8 / 9.6 / 10.195 / 8.595 / 8.195 / 9.535 / 10.08 / 9.67 / 10.47 / 10.05 / 9.28 / 8.76 / 10.32 / 8.47m
Cab width: 2.55 / 2.5 / 2240m
Cab height: 3.45 / 1.5 / 3.6 / 3.55 / 3.2 / 3.08m
Front track width: 2070/2070 / 2023 / 2011/2011 / 2011 / 2030/2030 / 2023/2023 / 1970/1970 / 1926/1926 / 1940/1940 / 2036mm
rear track: 1860/1860 / 1900/1900mm
Curb Weight: 14.77 / 12.5 / 15.5 / 15 / 14.765 / 25ton
Rated payload: 16.1 / 12.37 / 15.37 / 15.87 / 16.105 / 16.04 / 12.94ton
GVWR: 31 / 25 / 3.1ton
Origin: Xi'an, Shaanxi / Baoji, Shaanxi
tonnage class: Heavy truck
Approach angle: 18 / 23 / 28 / 22 / 25°
departure angle: 20 / 21 / 10 / 17 / 19 / 15 / 18°
Remarks: Standard Tianxingjian Zhiya Edition BD on-board terminal; Cab color: Vitality Green; Brake: domestic 4-channel ABS; Self-adjusting arms on front and rear axles, brake lining wear alarm; Attached desert air filter, radiator underrun protection, front underrun protection, no spare tire; Overspeed alarm (100 km/h); ECU reads vehicle code; Brake test connector; Right-turn voice prompt; 180Ah battery; Downward exhaust; Cable shift; Front tow hook; Transmission with QH50 PTO. No third seat. / Standard Tianxingjian Zhiya Edition BD on-board terminal; Cab color: Vitality Green; Brake: domestic 4-channel ABS, self-adjusting arms on front and rear axles, brake lining wear alarm; Radiator underrun protection, front underrun protection, no spare tire; Overspeed alarm (100 km/h); ECU reads vehicle code; Brake test connector; Right-turn voice prompt; 180Ah battery; Downward exhaust; Cable shift; Oil bath air filter; Front tow pin; Transmission with QH50 PTO. / Standard: Sun visor, Tianxingjian Zhiyaban BD in-vehicle terminal; Cab color: Vitality Green; Front underrun protection, radiator underrun protection; Brakes: Domestic 4-channel ABS; Overspeed alarm (100 km/h); ECU reads vehicle identification code; Brake test connector; Right-turn voice alert. Optional: Cab: 4-point air suspension, electric tilt; Cab colors: Duke Yellow, Pearl Green. Brakes: Aluminum air tanks. / Standard Tianxingjian Zhiya Edition BD on-board terminal; Cab color: Vitality Green; Front underrun protection, radiator underrun protection; Brake: domestic 4-channel ABS, self-adjusting arms on front and rear axles, brake lining wear alarm; Overspeed alarm (100 km/h); ECU reads vehicle code; Brake test connector; Right-turn voice prompt; Seatbelt buckle alarm; 180Ah battery; Downward exhaust; Cable shift; Desert air filter; Front tow pin; Transmission with QH50 PTO. / Standard: Sun visor, Tianxingjian Zhiyaban BD in-vehicle terminal; Cab color: Vitality Green; Brakes: Domestic 4-channel ABS; Radiator underrun protection, front underrun protection, no spare tire; Overspeed alarm (100 km/h); ECU reads vehicle identification code; Brake test connector; Right-turn voice alert. Optional: Cab: electric tilt; Cab colors: Duke Yellow, Pearl Green / Optional STR13T+STR13T/5.73 rear axle / 1. 6.5t front axle option. 2. 12.00R20 option. 3. 13T STR rear dual axle with 5.73 ratio option. / Application: sand, gravel, coal, etc. transport; Lifting method: front lift; Road conditions: construction site and city road driving, good road conditions; Speed: 60-75km/89km; Options: 1. Optional 10JSD160B transmission / Application: sand, gravel, coal, etc. transport; Lifting method: front lift; Road conditions: construction site and city road driving, good road conditions; Speed: 60-75km/108km / Optional equipment: 1. Optional STR13T+STR13T (5.73); 2. Optional 300/8+8 double-layer frame; Application: sand, gravel, coal, mineral powder, etc. transport; Lift type: front support; Road conditions: town roads, provincial highways, national highways, some construction sites, mine dirt roads; Speed: 65-70km/94km / Optional equipment: 1. Gearbox optional 10JSD160B; 2. Optional STR13T+STR13T(5.73); 3. Optional 300/8+8 double-layer frame; Application: sand, gravel, coal, mineral powder transport; Lifting method: front support; Road conditions: urban roads, provincial roads, national highways, some construction sites, mining dirt roads; Speed: 60-75km/94km / Optional equipment: 1. Optional 300/8+8 double-layer frame; 2. Optional STR13T+STR13T(5.73) rear axle; Application: sand, gravel, coal, mineral powder transport; Lifting method: front support; Road conditions: urban roads, provincial roads, national highways, some construction sites, mining dirt roads; Speed: 60-70km/94km / Application: sand, gravel, coal, mineral powder, etc. transport; Lift type: front support; Road conditions: urban roads, provincial roads, national highways, some construction sites, mine dirt roads; Speed: 60-75 km/h / 94 km/h / Application: sand, gravel, coal, mineral powder, etc. transport; Lift type: front support; Road conditions: urban roads, provincial roads, national highways, some construction sites, mine dirt roads; Speed: 60-75 km/h / 94 km/h; Optional equipment: 1. Transmission optional 10JSD160B; 2. Optional STR13T+STR13T (5.73); 3. Optional 300/8+8 full double; / Application: sand, gravel, coal, etc. transport; Lifting method: front lift; Road conditions: construction site and city road driving, good road conditions; Speed: 60-75km/104km / This dump truck tips backward. Optional cargo bodies of different shapes. With 2-seat cab, payload 12940 kg; with 3-seat cab, payload 12875 kg. Guard material: Q235, bolted connection; rear guard ground clearance 500 mm, section size 120×60 mm. Tachograph must be installed.
Version: Standard Load Edition / reinforced version / LNG Edition / composite version / Lightweight version
Energy Type: Diesel / LNG (liquefied natural gas)
Engine parameters
Engine Brand: Xi’an Cummins / Yuchai / Weichai
Number of cylinders: 6cylinder
Displacement: 10.8 / 10.338 / 7.47 / 8.424 / 9.726 / 7.14 / 7.255L
Emission standard: China V / China IV / China III / Euro III
Max output power: 283 / 285 / 254 / 309 / 276 / 220 / 236 / 228 / 213 / 247 / 199 / 191kW
Max hp: 385 / 345 / 420 / 375 / 300 / 320 / 310 / 290 / 336 / 270 / 260Horsepower
Max torque: 1900 / 1800 / 2000 / 1500 / 1250 / 1150 / 1180 / 1100 / 1000 / 960N·m
Max torque speed: 1100-1300 / 1100-1500 / 1200-1500 / 1200-1700 / 1300-1600 / 1200-1600 / 1400-1600rpm
Rated speed: 1900 / 2100 / 2300 / 2200rpm
Engine Type: Full electronic control / Vertical, inline, water-cooled, four-stroke / Vertical, inline 6-cylinder, water-cooled, 4-stroke / Inline 6-cylinder, electronic high-pressure common rail, SCR / High-pressure common rail / Vertical, Water-cooled, Four-stroke, Inline six-cylinder, Electronically controlled direct injection / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled, electronic high-pressure common rail, SCR / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled, electronic high-pressure common rail + SCR / Electronic high-pressure common rail + SCR / Vertical, inline, water-cooled, four-stroke, electronically controlled direct injection / Vertical, inline, water-cooled, four-stroke, direct injection, EGR / Water-cooled, 4-stroke, with exhaust brake, direct injection, turbocharged intercooled
Technology route: Common Rail SCR
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 12 / 10 / 9Gear
Number of Reverse Gears: 2 / 1pcs
Housing Material: aluminum housing / Steel shell
Cargo box parameters
Cargo box thickness: floor 4mm side 3mm
Unloading Type: Rear-dump body / Dump type
Cargo box length: 5.8 / 5.6 / 5.4 / 6.5 / 7.6 / 7.2 / 7.4 / 7 / 6.8 / 5.95m
FAQ
What kind of truck is SHACMAN Commercial Vehicle SHACMAN Xuande X3 Quasi-Heavy Truck Dump Trucks?
SHACMAN Commercial Vehicle SHACMAN Xuande X3 Quasi-Heavy Truck is an export-oriented Dump Trucks lineup with about 46 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SHACMAN Commercial Vehicle SHACMAN Xuande X3?
SHACMAN Commercial Vehicle SHACMAN Xuande X3 export reference is about $36,472 – $54,708. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SHACMAN Commercial Vehicle SHACMAN Xuande X3 cover?
SHACMAN Commercial Vehicle SHACMAN Xuande X3 mainly covers: Drive: 6x4 / 8x4; Horsepower: 345 hp / 385 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SHACMAN Commercial Vehicle SHACMAN Xuande X3?
For SHACMAN Commercial Vehicle SHACMAN Xuande X3: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SHACMAN Commercial Vehicle SHACMAN Xuande X3 include?
SHACMAN Commercial Vehicle SHACMAN Xuande X3 currently lists about 46 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SHACMAN Commercial Vehicle SHACMAN Xuande X3?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
