Dayun New N8E Heavy Truck Composite Type 350 hp 8X4(12 wheels) 6.8m Dump Truck (12-speed)
EXW
From $46,792
Export quote
Dayun New N8E quasi-heavy truck Dump Trucks
Main model photos
242 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dayun New N8E Heavy Truck Composite Type 350 hp 8X4(12 wheels) 6.8m Dump Truck (12-speed) | 8x4 / 350hp / China V | From $46,792 | |
| Dayun New N8E Heavy Truck 336hp 8X4(12 wheels) 6.8m LNG dump truck | 8x4 / 336hp / China V | From $51,500 | |
| Dayun New N8E Heavy Truck 350hp 8X4(12 wheels) 6.8m dump truck (12-speed) | 8x4 / 350hp / China V | From $44,528 | |
| Dayun New N8E Heavy Truck 300hp 8X4(12 wheels) 7.2m dump truck | 8x4 / 300hp / China V | From $42,444 | |
| Dayun New N8E Heavy Truck 350hp 8X4(12 wheels) 6.8m Dump Truck | 8x4 / 350hp / China V | From $44,528 |
Dayun New N8E Heavy Truck 336hp 8X4(12 wheels) 6.8m LNG dump truck
EXW
From $51,500
Export quote
Dayun New N8E Heavy Truck 350hp 8X4(12 wheels) 6.8m dump truck (12-speed)
EXW
From $44,528
Export quote
Dayun New N8E Heavy Truck 300hp 8X4(12 wheels) 7.2m dump truck
EXW
From $42,444
Export quote
Dayun New N8E Heavy Truck 350hp 8X4(12 wheels) 6.8m Dump Truck
EXW
From $44,528
Export quote
Series Specs
Basic Info
Model code (announced): CGC3310D5DDCD / CGC3313N52DA / CGC3310D5DDAD / CGC3310D5EDED / CGC3310D5DDED / CGC3313D4DD / CGC3313D4AD / CGC3313D4BD / DYX3311PA38WPD3C / 3313WD3RD
Drive type: 8X4
Wheelbase: 1800+3400+1350 / 1800+3000+1350 / 1800+3800+1350 / 1800+4600+1350 / 1800+3300+1350mm
Engine Model: WeichaiWP10.350E53 / WeichaiWP10NG336E51 / WeichaiWP7.300E51 / WeichaiWP12.375E50 / WeichaiWP10.310E53 / WeichaiWP12.375E40 / WeichaiWP10.290E41 / WeichaiWP10.350E42 / WeichaiWP10.290E32 / WP10.350E42
Transmission Model: Fast Gear12JSD180T / Fast Gear10JSD160TB / Fast Gear10JSD140B / Fast Gear12JSD200T / Fast Gear12JSD160T / Fast Gear12JSD180T+QH70 / Fast Gear10JSD160 / Fast Gear12JS200T / Fast Gear10JSD140 / Fast Gear9JS135B / Fast Gear9JS135
Rear Axle Ratio: 5.92 / 4.875 / 4.8 / 4.769 / 4.44 / 5.262 / 5.57
Cab length: 9.62 / 9.73 / 9.88 / 10.02 / 10.28 / 10.08 / 9.68 / 10.42 / 10.22 / 9.82 / 9.42 / 9.22 / 11.03 / 10.13 / 9.83 / 9.78m
Cab width: 2.5 / 2.55 / 2.49m
Cab height: 3.5 / 3.6 / 3.86 / 3.49m
Front track width: 2030/2030 / 2032/2032 / 2060/2060mm
rear track: 1860/1860mm
Curb Weight: 14.785 / 14.8 / 15.02 / 9.8ton
Rated payload: 16.02 / 16.005 / 16.085 / 16.07 / 15.85ton
GVWR: 31ton
Origin: Shanxi Yuncheng / Chengdu, Sichuan
tonnage class: Heavy truck
Approach angle: 24°
departure angle: 22 / 28°
Remarks: PTO QH70 / QH70 PTO / Rear axle ratio optional 4.875, PTO QH70 / Weichai engine, Fast Gear transmission (9JS135B+QH70), 153 front axle, 435 single-stage stamped welded dual rear axle (ratio 5.57), hydraulic power steering, pneumatic clutch, standard narrow flat-roof cab. (Optional: 457 single-stage stamped welded dual rear axle)
Version: Composite type / LNG Edition
Energy Type: Diesel / LNG (liquefied natural gas)
Engine parameters
Engine Brand: Weichai
Number of cylinders: 6cylinder
Displacement: 9.726 / 7.47 / 11.596L
Emission standard: China V / China IV / China III / Euro III
Max output power: 257 / 247 / 220 / 276 / 228 / 213kW
Max hp: 350 / 336 / 300 / 375 / 310 / 290Horsepower
Max torque: 1600 / 1450 / 1250 / 1800 / 1500 / 1160 / 1550N·m
Max torque speed: 1200-1600 / 1200-1500 / 1200-1700 / 1000-1400rpm
Rated speed: 1900 / 2300 / 2200rpm
Engine Type: Electronic high-pressure common rail + SCR / Inline 6-cylinder, 4-stroke, single-point injection + oxidation catalyst / Inline 6-cylinder, electronic high-pressure common rail, SCR / Inline, water-cooled, six-cylinder, electronically controlled high-pressure common rail SCR / Inline 6-cylinder, electronically controlled high-pressure common rail + SCR / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled, electronic high-pressure common rail + SCR
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 12 / 10 / 9Gear
Number of Reverse Gears: 2 / 1pcs
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 6.8 / 7.2 / 7.6 / 7.4 / 7 / 6.6 / 6.4 / 8 / 7.1m
Cargo box width: 2.3 / 2.35m
Cargo box height: 1.17 / 1.5 / 1.235 / 1.12 / 1.04 / 1.145 / 0.8 / 1.19m
FAQ
What kind of truck is Dayun Dayun New N8E quasi-heavy truck Dump Trucks?
Dayun Dayun New N8E quasi-heavy truck is an export-oriented Dump Trucks lineup with about 26 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dayun New N8E quasi-heavy truck Dump Trucks?
Dayun New N8E quasi-heavy truck Dump Trucks export reference is about $42,083 – $52,500. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dayun New N8E quasi-heavy truck Dump Trucks cover?
Dayun New N8E quasi-heavy truck Dump Trucks mainly covers: Drive: 8x4; Horsepower: 300 hp / 336 hp / 350 hp; Emission: China V; Fuel: Diesel / LNG (liquefied natural gas). Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dayun New N8E quasi-heavy truck Dump Trucks?
For Dayun New N8E quasi-heavy truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Dayun New N8E quasi-heavy truck Dump Trucks include?
Dayun New N8E quasi-heavy truck Dump Trucks currently lists about 26 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dayun New N8E quasi-heavy truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
