SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version)

Export reference
From $41,500
MSRP ¥29.88M CNY
Emission: China III / Euro III
Fuel: Diesel
Transmission: Fast Gear
Curb Weight:: 13.87ton
Wheelbase:: 1800+2800+1350mm
Tire Size:: 11.00-20
Rated payload: 17ton
Drive 8X4 (12 wheels)
Horsepower 336
Cargo box type: Dump type

Overview

The SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version) is a Heavy truck featuring 17t payload, 31t GVW, Dump type cargo body and 8X4 (12 wheels) drive. On the powertrain side, it comes with a WeichaiWP10.336N engine, 336 hp, China III / Euro III emissions and Fast Gear transmission.

China III / Euro III 336 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SX3315BM286
Drive type: 8X4
Wheelbase: 1800+2800+1350mm
engine: WeichaiWP10.336N
transmission: Fast Gear9JS135
Rear Axle Ratio: 5.919
Cab length: 9.206m
Cab width: 2.49m
Cab height: 3.45m
Front track width: 1939/1939mm
rear track: 1860/1860mm
Curb Weight: 13.87ton
Rated payload: 17ton
GVWR: 31ton
Origin: Xi'an, Shaanxi
tonnage class: Heavy truck
Approach angle: 28°
departure angle: 45°
Remarks: Tire specification also available: 11.00R20, 12.00-20, 12.00R20
Version: Standard Load Edition
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai
Engine Model: WeichaiWP10.336N
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 9.726L
Emission standard: China III / Euro III
Max output power: 247kW
Max hp: 336Horsepower
Max torque: 1250N·m
Max torque speed: 1350-1500rpm
Rated speed: 1900rpm
Engine Type: Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled
Transmission Parameters
Transmission Model: Fast Gear9JS135
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 9Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 6.5m
Cargo box width: 2.3m
Cargo box height: 1.3m
fuel tank
Fuel tank capacity: 400L
Chassis Specs
rear axle allowable load: 18000kg
Axle ratio: 5.919
Leaf spring count: Left 14 Right 13/Left 14 Right 13/12
Tire
Tire Size: 11.00-20
Number of tires: 12pcs

Photos

0 photos

FAQ

What is the export price of SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version), and what does it include?

SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version) export reference is about From $41,500; MSRP is ¥29.88M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version) use, and can it enter my country?

This model is listed as China III / Euro III. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version)?

Key specs of SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version): Drive: 8x4; Horsepower: 336 hp; Emission: China III / Euro III; Fuel: Diesel; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version) suited for?

SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version) is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version) differ from other variants in the same series?

SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version) belongs to SHACMAN Aolong Heavy Truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SHACMAN Aolong Heavy Truck 336 hp 8X4(12 wheels) 6.5m Dump Truck (Standard Version)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
