SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 5.8m Intelligent Eco Dump Truck
EXW
From $54,167
Export quote
SANY V5 heavy-duty truck Dump Trucks
Main model photos
8 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 5.8m Intelligent Eco Dump Truck | 8x4 / 380hp / China V | From $54,167 | |
| SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 5.6m Intelligent Eco Dump Truck | 8x4 / 380hp / China V | From $53,889 | |
| SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 6.5m Intelligent Eco Dump Truck | 8x4 / 380hp / China V | From $55,278 | |
| SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 5.8m Intelligent Eco Dump Truck | 8x4 / 380hp / China V | From $54,167 | |
| SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 5.6m Intelligent Eco Dump Truck | 8x4 / 380hp / China V | From $53,889 |
SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 5.6m Intelligent Eco Dump Truck
EXW
From $53,889
Export quote
SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 6.5m Intelligent Eco Dump Truck
EXW
From $55,278
Export quote
SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 5.8m Intelligent Eco Dump Truck
EXW
From $54,167
Export quote
SANY V5 Heavy Truck Longhui Edition 380hp 8X4(12 wheels) 5.6m Intelligent Eco Dump Truck
EXW
From $53,889
Export quote
Series Specs
Basic Info
Model code (announced): SYM3316ZZX1E / SYM5310ZLJ1E / HQC3250ZZX1E
Drive type: 8X4 / 6X4
Wheelbase: 1800+2750+1400 / 1800+2500+1350 / 1800+3100+1400 / 3800+1350mm
Engine Model: SANY Power D09C5-380E0 / WeichaiWP10.310E52 / YuchaiYC6L310-50
Transmission Model: Fast Gear12JSDX240TA / Fast Gear10JSD120B
Rear Axle Ratio: 6.72
Cab length: 8.9 / 8.54 / 9.48 / 8.35m
Cab width: 2.54 / 2.49 / 2490m
Cab height: 3.58 / 3.42 / 3.48 / 3.345m
Front track width: 2048/2048 / 2048mm
rear track: 1860/1860mm
Curb Weight: 15.4 / 14.77 / 12.43ton
Rated payload: 15.47 / 16.1 / 12.44ton
GVWR: 31 / 25ton
Origin: Changsha / Changsha, Hunan
tonnage class: Heavy truck
Approach angle: 17°
departure angle: 20 / 22 / 21°
Version: Longhui Edition / Urban Construction & Muck
Energy Type: Diesel
Engine parameters
Engine Brand: SANY / Weichai / Yuchai
Number of cylinders: 6cylinder
Displacement: 8.7 / 9.726 / 8.424L
Emission standard: China V
Max output power: 280 / 228kW
Max hp: 380 / 310Horsepower
Max torque: 1420 / 1150N·m
Max torque speed: 1200-1500 / 1200-1700rpm
Rated speed: 2200rpm
Engine Type: Inline 6-cylinder, electronic high-pressure common rail, SCR / Vertical, Water-cooled, Four-stroke, Inline six-cylinder
Technology route: Common Rail SCR
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 12 / 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
hydraulic cylinder brand & model: Italy PENTA
Unloading Type: Rear-dump body
Seal cover type: Hydraulic sealing cover
Cargo box thickness: 6mm base, 4mm sides
Body Parameters
Lifting type: Front lift
FAQ
What kind of truck is SANY Truck SANY V5 heavy-duty truck Dump Trucks?
SANY Truck SANY V5 heavy-duty truck is an export-oriented Dump Trucks lineup with about 7 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SANY V5 heavy-duty truck Dump Trucks?
SANY V5 heavy-duty truck Dump Trucks export reference is about $53,889 – $55,278. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SANY V5 heavy-duty truck Dump Trucks cover?
SANY V5 heavy-duty truck Dump Trucks mainly covers: Drive: 8x4; Horsepower: 380 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SANY V5 heavy-duty truck Dump Trucks?
For SANY V5 heavy-duty truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SANY V5 heavy-duty truck Dump Trucks include?
SANY V5 heavy-duty truck Dump Trucks currently lists about 7 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SANY V5 heavy-duty truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
