Dongfeng Lituo 4100 102 hp 4X2(6 wheels) 3.8m dump truck
EXW
Export quote
Dongfeng 4100 Light-duty Truck Dump Trucks
Main model photos
30 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Lituo 4100 102 hp 4X2(6 wheels) 3.8m dump truck | 4x2 / 102hp / China IV | ||
| Dongfeng Lituo 115hp 4X2(6 wheels) 3.85m Dump Truck | 4x2 / 115hp / China III / Euro III | ||
| Dongfeng Lituo 115hp 4X2(6 wheels) 3.85m Dump Truck | 4x2 / 115hp / China III / Euro III | ||
| Dongfeng Lituo XL Series 190 hp 4X2(6 wheels) 4.75m Dump Truck | 4x2 / 190hp / China III / Euro III |
Dongfeng Lituo 115hp 4X2(6 wheels) 3.85m Dump Truck
EXW
Export quote
Dongfeng Lituo 115hp 4X2(6 wheels) 3.85m Dump Truck
EXW
Export quote
Dongfeng Lituo XL Series 190 hp 4X2(6 wheels) 4.75m Dump Truck
EXW
Export quote
Series Specs
Basic Info
Model code (announced): EQ3042GDAC / EQ3104GD4AC / EQ3051GD4AC / Z79-100
Drive type: 4X2
Wheelbase: 3400 / 3950mm
Engine Model: Yunnei PowerYN33CRD2 / YuchaiYC4BJ115-33 / YuchaiYC6J190-33
Transmission Model: WLYWLY5-speed / 145 rear auxiliary
Rear Axle Ratio: 6.33 / 6.833
Cab length: 5.998 / 6.1m
Cab width: 2.25 / 2.26m
Cab height: 2.57 / 2.68m
Front track width: 1640mm
rear track: 1650mm
Curb Weight: 2.7 / 4.92 / 3.31ton
Rated payload: 1.6 / 4.99 / 1.99ton
GVWR: 4.495 / 10.105 / 5.495ton
Origin: Xiangyang, Hubei
tonnage class: Light Truck
Approach angle: 31°
departure angle: 17°
Remarks: Transmission: 145H
Energy Type: Diesel
Engine parameters
Engine Brand: Yunnei Power / Yuchai
Number of cylinders: 4 / 6cylinder
Displacement: 3.298 / 3.983 / 6.494L
Emission standard: China IV / China III / Euro III
Max output power: 75 / 85 / 140kW
Max hp: 102 / 115 / 190Horsepower
Max torque: 265 / 345 / 630N·m
Max torque speed: 1600-2400 / 1400-1700rpm
Rated speed: 3200 / 2800 / 2500rpm
Engine Type: Electronic high-pressure common rail diesel engine / 4-cylinder / Vertical, inline, water-cooled, four-stroke, direct injection
Transmission Parameters
Transmission Brand: WLY
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Dump type / Rear-dump body
Cargo box length: 3.8 / 3.85 / 4.75m
Cargo box width: 2.1 / 2.2 / 2.3m
Cargo box height: 0.8 / 1.2m
fuel tank
Fuel tank capacity: 200L
Chassis Specs
Frame Dimensions: 230×10×800mm
rear axle description: 1098 / 457
FAQ
What kind of truck is Dongfeng Dongfeng 4100 Light-duty Truck Dump Trucks?
Dongfeng Dongfeng 4100 Light-duty Truck is an export-oriented Dump Trucks lineup with about 4 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Dongfeng 4100 Light-duty Truck Dump Trucks cover?
Dongfeng 4100 Light-duty Truck Dump Trucks mainly covers: Drive: 4x2; Horsepower: 102 hp / 115 hp / 190 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng 4100 Light-duty Truck Dump Trucks?
For Dongfeng 4100 Light-duty Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Dongfeng 4100 Light-duty Truck Dump Trucks include?
Dongfeng 4100 Light-duty Truck Dump Trucks currently lists about 4 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng 4100 Light-duty Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
