Sinotruk Haoman H3 160hp 4X2(6 wheels) Truck-mounted Crane
EXW
From $31,667
Export quote
Sinotruk Pioneer Light Truck truck-mounted crane
Main model photos
833 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Haoman H3 160hp 4X2(6 wheels) Truck-mounted Crane | 4x2 / 160hp / China VI | From $31,667 | |
| Sinotruk Haoman H3 170 hp 4X2(6 wheels) truck-mounted crane | 4x2 / 170hp / China V | From $30,556 | |
| Sinotruk Haoman H3 170 hp 4X2(6 wheels) truck-mounted crane | 4x2 / 170hp / China V | From $19,625 | |
| Sinotruk Haoman H3 low-spec 129 hp 4X2(6 wheels) truck-mounted crane | 4x2 / 129hp / China V | From $17,153 | |
| Sinotruk HOWO MAN H3 150 hp 4X2(6 wheels) truck-mounted crane (4500 wheelbase) | 4x2 / 150hp / China V | From $18,736 |
Sinotruk Haoman H3 170 hp 4X2(6 wheels) truck-mounted crane
EXW
From $30,556
Export quote
Sinotruk Haoman H3 170 hp 4X2(6 wheels) truck-mounted crane
EXW
From $19,625
Export quote
Sinotruk Haoman H3 low-spec 129 hp 4X2(6 wheels) truck-mounted crane
EXW
From $17,153
Export quote
Sinotruk HOWO MAN H3 150 hp 4X2(6 wheels) truck-mounted crane (4500 wheelbase)
EXW
From $18,736
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Haoman H3 170 hp 4X2(6 wheels) truck-mounted crane | 4x2 / 170hp / China V | ||
| Sinotruk HOWO MANH3 129hp 4X2(6 wheels) Truck Mounted Crane (4500mm wheelbase) | 4x2 / 140hp / China V | ||
| Sinotruk Haoman H3 129 hp 4X2(6 wheels) Truck-Mounted Crane (4200 Wheelbase) | 4x2 / 129hp / China V | ||
| Sinotruk Haoman H3 129 hp 4X2(6 wheels) Truck-Mounted Crane (Wide Body) | 4x2 / 129hp / China V |
Sinotruk Haoman H3 170 hp 4X2(6 wheels) truck-mounted crane
EXW
Export quote
Sinotruk HOWO MANH3 129hp 4X2(6 wheels) Truck Mounted Crane (4500mm wheelbase)
EXW
Export quote
Sinotruk Haoman H3 129 hp 4X2(6 wheels) Truck-Mounted Crane (4200 Wheelbase)
EXW
Export quote
Sinotruk Haoman H3 129 hp 4X2(6 wheels) Truck-Mounted Crane (Wide Body)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 7.18×2.4×3.55 / 6.68X2.3X3.37 / 7.28×2.49×3.6 / 5.995×2.52×3.2 / 8.15×2.49×3.55 / 7.85×2.49×3.55 / 7.55×2.49×3.55m
Type: truck-mounted crane
Drive type: 4X2
Wheelbase: 3900 / 3650 / 3300 / 4500 / 4200mm
Rated mass: 4.545 / 6.22 / 5.83 / 0.495 / 5.175ton
GVWR: 11.2 / 9.99 / 14.06 / 4.495 / 13.57ton
Remarks: Crane options: 5t, 6.3t, 7t / Optional ratio 5.286
Front/rear suspension: 1.175/1.625 / 1.24/1.79 / 1.24/2.01 / 1.175/1.52 / 1.26/2.39m
Energy Type: Diesel
Body Parameters
Other special notes: 120L aluminum fuel tank; PTO; double-layer frame; spare tire; full interior trim / PTO; double-layer frame; spare tire / Front axle: 145D/3.6T / Front axle: 1090N/3T
Crane model: SPS16000BF
Lifting capacity: 7ton
Vehicle certification code: ZZ5048JSQD17EB0 / ZZ5108JSQF17EB2 / ZZ5148JSQF17EB1 / ZZ5148JSQF17EB0
Body Brand: Sinotruk
Engine parameters
Injection System: Common Rail
Engine Brand: Weichai / Yunnei Power / Yuchai
Engine Model: WeichaiWP3NQ160E61 / Yunnei PowerYNF40E1 / YNF40E1 / Yunnei PowerYN38CRE1 / YuchaiYC4D150-50 / YuchaiYCD4D4S-140
Displacement: 2.97 / 3.92 / 3.76 / 4.214 / 4.156L
Emission standard: China VI / China V
Max output power: 118 / 125 / 95 / 110 / 105kW
Max hp: 160 / 170 / 129 / 150 / 140Horsepower
Max torque: 480 / 600 / 365 / 500 / 460N·m
Max torque speed: 1400-2300 / 1300-1900 / 1600-2400 / 1400-1800 / 1500-1950rpm
Rated speed: 3000 / 2600 / 2800rpm
Chassis Specs
Chassis Brand: Sinotruk
Chassis Series: HOWO MAN H3
Chassis Model: ZZ1118G17FB0 / ZZ1108F17EB2 / ZZ1148F17EB0 / ZZ1048D17EB1 / ZZ1148F17EB1
Frame Dimensions: 216(865) / 216(800) / 250/6+5/800 / 196 / 196(800)mm
rear axle description: 1080 rear axle; 7.2T / 1080 rear axle; 7.2T rear axle / 1094D rear axle / 1094D rear axle; 9T / 1061 rear axle; 4.2T / 7.2T rear axle, ratio 5.833
Axle ratio: 4.333 / 5.833 / 4.875 / 5.375
Leaf spring count: 8/9+6 / 11/11+7 / 9/11+8 / 11/9+7
Transmission Parameters
Number of gears: 8 / 10 / 5 / 6Gear
Transmission Model: 8-speed gearbox / Fast Gear8JS85T / Fast Gear8JS85TE / Changtai SC8T50C / SinotrukHW90510C / WLYWLY10H46 / WLYWLY6T50C / WLYWLY653H
Cab parameters
Cab: Single row 2080 / Day cab 2080 / Sleeper cab 2080 / Single row 1880 / Sleeper cab 1880 cab
Tire
Tire Size: 8.25R20 / 8.25R16LT 16PR / 8.25R16 / 8.25R16LT / 8.25R20 16PR / 8.250R20 / 7.50R16 / 7.50R16LT 6PR / 9.00R20
Number of tires: 6pcs
FAQ
What kind of truck is Sinotruk Sinotruk Pioneer Light Truck truck-mounted crane?
Sinotruk Sinotruk Pioneer Light Truck is an export-oriented truck-mounted crane lineup with about 16 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk Pioneer Light Truck truck-mounted crane?
Sinotruk Pioneer Light Truck truck-mounted crane export reference is about $16,375 – $31,667. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk Pioneer Light Truck truck-mounted crane cover?
Sinotruk Pioneer Light Truck truck-mounted crane mainly covers: Drive: 4x2; Horsepower: 129 hp / 140 hp / 150 hp / 160 hp / 170 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk Pioneer Light Truck truck-mounted crane?
For Sinotruk Pioneer Light Truck truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Sinotruk Pioneer Light Truck truck-mounted crane include?
Sinotruk Pioneer Light Truck truck-mounted crane currently lists about 16 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk Pioneer Light Truck truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
