FAW Jiefang Junwei J5K medium truck 180 hp 4X2(6 wheels) 4.9m dump truck
EXW
From $30,556
Export quote
FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks
Main model photos
72 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Junwei J5K medium truck 180 hp 4X2(6 wheels) 4.9m dump truck | 4x2 / 180hp / China IV | From $30,556 | |
| FAW Jiefang Junwei J5K medium truck 220 hp 4X2(6 wheels) 5.7m dump truck | 4x2 / 220hp / China IV | From $29,167 | |
| FAW Jiefang Junwei J5K medium truck 180 hp 4X2(6 wheels) 4.9m dump truck | 4x2 / 180hp / China IV | From $30,556 | |
| FAW Jiefang Junwei J5K light truck 160 hp 4X2(6 wheels) 4.5m dump truck | 4x2 / 160hp / China IV | From $31,944 | |
| FAW Jiefang Junwei (J5K) Medium Truck 180 hp 4X2(6 wheels) 4.9m Dump Truck | 4x2 / 180hp / China III / Euro III | From $18,889 |
FAW Jiefang Junwei J5K medium truck 220 hp 4X2(6 wheels) 5.7m dump truck
EXW
From $29,167
Export quote
FAW Jiefang Junwei J5K medium truck 180 hp 4X2(6 wheels) 4.9m dump truck
EXW
From $30,556
Export quote
FAW Jiefang Junwei J5K light truck 160 hp 4X2(6 wheels) 4.5m dump truck
EXW
From $31,944
Export quote
FAW Jiefang Junwei (J5K) Medium Truck 180 hp 4X2(6 wheels) 4.9m Dump Truck
EXW
From $18,889
Export quote
Series Specs
Basic Info
Model code (announced): CA3160P10K1E4 / CA3160P10K1BAE4 / CA3120P10K1BE4 / CA3161P10K1BE4 / CA3120P9K2E / CA3071P9K2AE / CA3208P9K2T3E
Drive type: 4X2 / 6X2
Wheelbase: 4090 / 4350 / 3750 / 1800+3800mm
Engine Model: DachaiBF6M2012-18E4 / DachaiBF6M2012-22E4 / DachaiBF4M1013-16E4 / XichaiCA6DE3-18E3F / XichaiCA4DF3-14E3F / DachaiCA6DE3-22E3 / BF6M2012-18E4 / BF4M1013-16E4
Transmission Model: Fast Gear8JS85E / Fast Gear 8JS100B transmission / Fast Gear 8JS85E transmission / Shaochi SC6J53F / Fast Gear8JS100B
Rear Axle Ratio: 6.333 / 5.286 / 5.769 / 6.33 / 6.166
Cab length: 7.45 / 8.14 / 6.92 / 7.1 / 6.667 / 8.8m
Cab width: 2.49 / 2.5m
Cab height: 3 / 2.87 / 2.84 / 3.1m
Front track width: 1914 / 1928/1928mm
rear track: 1847mm
Curb Weight: 7.9 / 7.995 / 6.74 / 7.65 / 6.64 / 3.84 / 10.1ton
Rated payload: 7.96 / 7.865 / 4.99 / 7.965 / 5 / 3.13 / 10.17ton
GVWR: 15.99 / 11.86 / 15.745 / 11.835 / 7.165 / 20.4ton
Origin: Changchun, Jilin
tonnage class: Medium-duty truck
Approach angle: 28 / 18 / 29°
departure angle: 20 / 23 / 22 / 18 / 32 / 15 / 19°
Remarks: J5K flat roof cab, facelift, Beidou-compatible onboard system / J5K flat roof cab, facelift. Semi-auto AC, 150Ah battery, rear overhang 1128mm / J5K flat roof cab, facelift. No AC / J5K flat roof cab, facelift, semi-automatic AC / Engine optional Xichai CA6DF3-18E3 / Exhaust brake, no A/C, 150L fuel tank, chassis stamped with vehicle code/EGR / Cargo box size 6200×2300×890mm corresponds to rated payload 10170kg;
Energy Type: Diesel
Engine parameters
Engine Brand: Dachai / Xichai
Number of cylinders: 6 / 4cylinder
Displacement: 6.06 / 4.764 / 6.618 / 4.75L
Emission standard: China IV / China III / Euro III
Max output power: 139 / 165 / 118 / 136 / 103 / 162kW
Max hp: 180 / 220 / 160 / 140Horsepower
Max torque: 660 / 770 / 650 / 490N·m
Max torque speed: 1500 / 1400rpm
Rated speed: 2500 / 2300rpm
Engine Type: Electronically controlled / 6-cylinder inline, turbocharged intercooled, electronic unit pump / Turbocharged Air-to-Air Intercooling / 4-cylinder inline, direct injection, turbocharged & intercooled, inline pump EGR
Transmission Parameters
Transmission Brand: Fast Gear / Fast Gear transmission / Shaochi
shift method: Manual
Forward gears: 8 / 6Gear
Number of Reverse Gears: 2 / 1pcs
Cargo box parameters
Unloading Type: Dump type / Rear-dump body
Cargo box length: 4.9 / 5.7 / 4.5 / 6.2m
Cargo box width: 2.28 / 2.26 / 2.3m
Cargo box height: 0.8 / 0.89m
fuel tank
Fuel tank capacity: 200L
Chassis Specs
rear axle description: Axle Ф457 bridge (domestic ABS) / Axle Ф457 bridge (manual adjust arm) / Axle φ300 wheel reduction axle (manual adjustment arm) / ф457 / ф435 / 457
FAQ
What kind of truck is FAW Jiefang FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks?
FAW Jiefang FAW Jiefang Junwei J5K Medium-duty Truck is an export-oriented Dump Trucks lineup with about 7 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks?
FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks export reference is about $18,056 – $31,944. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks cover?
FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks mainly covers: Drive: 4x2; Horsepower: 160 hp / 180 hp / 220 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks?
For FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks include?
FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks currently lists about 7 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Jiefang Junwei J5K Medium-duty Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
