FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose)

Export reference
From $18,889
MSRP ¥13.6M CNY
Emission: China III / Euro III
Fuel: Diesel
Transmission: FAW Jiefang
Curb Weight:: 7.54ton
Wheelbase:: 4600mm
Tire Size:: 10.00-20
Rated payload: 7.805ton
Drive 4X2 (6 wheels)
Horsepower 220
Cargo box type: Dump type

Overview

The FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose) is a Medium-duty truck featuring 7.805t payload, 15.54t GVW, Dump type cargo body and 4X2 (6 wheels) drive. On the powertrain side, it comes with a DachaiCA6DE3-22E3 engine, 220 hp, China III / Euro III emissions and FAW Jiefang transmission.

China III / Euro III 220 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): CA3165K2E
Drive type: 4X2
Wheelbase: 4600mm
engine: DachaiCA6DE3-22E3
transmission: FAW JiefangCA7T156
Rear Axle Ratio: 5.833
Cab length: 7.68m
Cab width: 2.46m
Cab height: 2.79m
Front track width: 1914mm
rear track: 1847mm
Curb Weight: 7.54ton
Rated payload: 7.805ton
GVWR: 15.54ton
Origin: Changchun, Jilin
tonnage class: Medium-duty truck
Approach angle: 29°
departure angle: 16°
Remarks: no A/C, power steering, spring brake, exhaust brake, front-view mirror
Energy Type: Diesel
Engine parameters
Engine Brand: Dachai
Engine Model: DachaiCA6DE3-22E3
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 6.618L
Emission standard: China III / Euro III
Max output power: 162kW
Max hp: 220Horsepower
Max torque: 770N·m
Max torque speed: 1400rpm
Rated speed: 2300rpm
Engine Type: Turbocharged Air-to-Air Intercooling
Transmission Parameters
Transmission Model: FAW JiefangCA7T156
Transmission Brand: FAW Jiefang
shift method: Manual
Forward gears: 7Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 4.5m
Cargo box width: 2.3m
Cargo box height: 0.8m
fuel tank
Fuel tank capacity: 400L
Chassis Specs
rear axle description: ф457
rear axle allowable load: 9960kg
Axle ratio: 5.833
Leaf spring count: 12/11+10
Tire
Tire Size: 10.00-20
Number of tires: 6pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose), and what does it include?

FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose) export reference is about From $18,889; MSRP is ¥13.6M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose) use, and can it enter my country?

This model is listed as China III / Euro III. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose)?

Key specs of FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose): Drive: 4x2; Horsepower: 220 hp; Emission: China III / Euro III; Fuel: Diesel; Transmission: FAW Jiefang. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose) suited for?

FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose) is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose) differ from other variants in the same series?

FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose) belongs to FAW Jiefang J4R Medium-duty Truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export FAW Jiefang J4R Medium Truck 220 hp 4X2(6 wheels) 4.5m Dump Truck (Long Nose)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
