Sinotruk Wangpai W1 88 hp 4X2(6 wheels) 3.1m Dump Truck (WLY)
EXW
From $9,375
Export quote
Sinotruk Wangpai W1 micro truck Dump Trucks
Main model photos
223 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Wangpai W1 88 hp 4X2(6 wheels) 3.1m Dump Truck (WLY) | 4x2 / 88hp / China V | From $9,375 | |
| Sinotruk Wangpai W1 88hp 4X2(6 wheels) 3.1m Dump Mini Truck | 4x2 / 88hp / China V | From $10,528 | |
| Sinotruk Wangpai W1 2.2L 112hp Gasoline/CNG 4X2(6 wheels) 2.6m Dump Truck | 4x2 / 112hp / China V | From $7,431 | |
| Sinotruk Wangpai W1 90 hp 4X2(6 wheels) 2.6m dump micro truck (Mengwo MR85SH transmission) | 4x2 / 90hp / China V | From $9,444 | |
| Sinotruk Ace W1 90hp 4X2(6 wheels) 3.1m dump mini truck (Mengwo MR85SH transmission) | 4x2 / 90hp / China V | From $9,278 |
Sinotruk Wangpai W1 88hp 4X2(6 wheels) 3.1m Dump Mini Truck
EXW
From $10,528
Export quote
Sinotruk Wangpai W1 2.2L 112hp Gasoline/CNG 4X2(6 wheels) 2.6m Dump Truck
EXW
From $7,431
Export quote
Sinotruk Wangpai W1 90 hp 4X2(6 wheels) 2.6m dump micro truck (Mengwo MR85SH transmission)
EXW
From $9,444
Export quote
Sinotruk Ace W1 90hp 4X2(6 wheels) 3.1m dump mini truck (Mengwo MR85SH transmission)
EXW
From $9,278
Export quote
Series Specs
Basic Info
Model code (announced): CDW3040N1M5 / CDW3030S4M5D / CDW3030S2M5C / CDW3030N3M5C / CDW3032N3M5C / CDW3031N3M5C / CDW3030S1M5C / CDW3030N1M5C / CDW3030S3M4 / CDW3030N1M4 / CDW3030S2M5 / CDW3030N2M5 / CDW3030N2M4
Drive type: 4X2
Wheelbase: 3050 / 3360 / 2850 / 3500mm
Engine Model: Quanchai4A2-88C50 / Xinchen PowerV22 / Huayuan Laidong4K22V / Huayuan LaidongK15 / Huayuan Laidong4L18CF / Quanchai4A1-62C43 / K15
Transmission Model: WLY 6-speed / MengwoMR85SH / MengwoMT78Q-WP11 / MengwoMR85SH-10C-03 / MengwoMR78Q / MengwoMR85SZ-WP1 / MengwoMG523-WP / MengwoMT78Q / 5-speed transmission / MengwoMW520GAHQWP-1 / MG523
Rear Axle Ratio: 4.44 / 5.375 / 4.875 / 4.785
Cab length: 5.165 / 5.57 / 5.54 / 5.16 / 5.56 / 5.51 / 5.59 / 5.47 / 5.17 / 4.87 / 5.525 / 4.89 / 5.09m
Cab width: 1.75 / 1.85 / 1650m
Cab height: 2.12 / 2.135 / 2.2 / 2.07m
Front track width: 1380 / 1410 / 1400 / 1380,1400 / 1375mm
rear track: 1310 / 1280 / 1370 / 1310,1370mm
Curb Weight: 2.37 / 1.945 / 1.83 / 1.805 / 2 / 2.03 / 1.8 / 1.67 / 1.7 / 1.745 / 1.715ton
Rated payload: 1.995 / 0.745 / 0.995 / 1.665ton
GVWR: 4.495 / 3.015 / 2.9 / 2.93 / 2.955 / 3.125 / 3.155 / 2.87 / 2.99 / 3.495 / 2.815 / 2.84 / 2.825ton
Origin: Chengdu, Sichuan
tonnage class: mini truck
Approach angle: 34 / 38 / 43°
departure angle: 15 / 28°
Remarks: Hydraulic brake / Body height optional: 0.4
Version: Dual-fuel (LPG/gasoline) version
Energy Type: Diesel / gasoline / Gasoline-CNG Dual Fuel
Engine parameters
Engine Brand: Quanchai / Xinchen Power / Huayuan Laidong
Number of cylinders: 4cylinder
Displacement: 2.27 / 2.237 / 2.156 / 1.461 / 1.809L
Emission standard: China V / China IV
Max output power: 65 / 82 / 66 / 58 / 52 / 50 / 45kW
Max hp: 88 / 112 / 90 / 79 / 71 / 68 / 62Horsepower
Max torque: 240 / 180 / 170 / 150N·m
Max torque speed: 2000 / 1800-2200 / 2000-2400rpm
Rated speed: 3200 / 3600rpm
Engine Type: Turbocharged intercooled, electronic high-pressure common rail / Vertical, inline, water-cooled, four-stroke, direct injection, turbocharged intercooled / High-pressure common rail, turbocharged intercooled / Direct injection high-pressure common rail, turbocharged & intercooled, EGR (intercooled), aftertreatment (DOC) / Inline, vertical, water-cooled, four-stroke, turbocharged intercooled, high-pressure common rail
Transmission Parameters
Transmission Brand: WLY / Mengwo
shift method: Manual
Forward gears: 6 / 5Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Dump type / Rear-dump body
Cargo box length: 3.1 / 2.6 / 3.5 / 2.5 / 2.8m
Cargo box width: 1.75 / 1.65m
Cargo box height: 0.4 / 0.37 / 0.37/0.4m
Cab parameters
Cab: Single Row / Double cab / Single Row Flat Roof / 1650 single row / 1650 double row / Flat roof
FAQ
What kind of truck is Sinotruk Sinotruk Wangpai W1 micro truck Dump Trucks?
Sinotruk Sinotruk Wangpai W1 micro truck is an export-oriented Dump Trucks lineup with about 24 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk Wangpai W1 micro truck Dump Trucks?
Sinotruk Wangpai W1 micro truck Dump Trucks export reference is about $7,083 – $10,528. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk Wangpai W1 micro truck Dump Trucks cover?
Sinotruk Wangpai W1 micro truck Dump Trucks mainly covers: Drive: 4x2; Horsepower: 88 hp / 90 hp / 112 hp; Emission: China V; Fuel: Diesel / gasoline. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk Wangpai W1 micro truck Dump Trucks?
For Sinotruk Wangpai W1 micro truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk Wangpai W1 micro truck Dump Trucks include?
Sinotruk Wangpai W1 micro truck Dump Trucks currently lists about 24 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk Wangpai W1 micro truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
